Starting/charging — Charging circuit BMW X5 E70 facelift
All systems — 44 systems
- Air conditioning 6
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Cruise control 3.0l twin turbo
- Cruise control 3.0l twin turbo diesel
- Cruise control 4.4l twin turbo
- Defoggers 3
- Electronic power steering 2
- Electronic suspension 3
- Engine performance 3.0l twin turbo
- Engine performance 3.0l twin turbo diesel
- Engine performance 4.4l twin turbo
- Exterior lights 2
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 6
- Navigation 9
- Power distribution
- Power door locks
- Power mirrors
- Power seats 10
- Power top/sunroof
- Power windows
- Radio 7
- Shift interlock 2
- Starting/charging 2
- Starting/charging 3.0l twin turbo 2
- Starting/charging 3.0l twin turbo diesel 2
- Starting/charging 4.4l twin turbo 2
- Supplemental restraints
- Transmission 3
- Transmission 3.0l twin turbo 3
- Transmission 3.0l twin turbo diesel 3
- Transmission 4.4l twin turbo 3
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer
Components on these wiring diagrams 8
Click a component to highlight it on every diagram it appears on.
