Rear seat entertainment circuit for BMW X5 E70 facelift (2010-2013)
Rear seat entertainment circuit
AUX-IN CONNECTION
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CCC/M-ASK
COMPUTER DATA LINES SYSTEM
FUSE FUSE DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT)
GRN WIRE
HEADSET CONNECTION MODULE
INFRARED INTERFACE
MOST-BUS CONNECTOR
NCA WIRE
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
REAR COMPARTMENT DISPLAY
REAR POWER
REAR SEAT ENTERTAINMENT
RED/GRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
VIDEO MODULE (BEHIND LEFT QUARTERPANEL)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
