Seats - Repair BMW X5 E70

52 13 .. Removing and Installing/Replacing All Trims On Left Or Right Seat Rails

Operation is identical to

Replacing all trims on left or right seat rail (comfort). See 52 17 .. Removing and installing/replacing all trims on left or right seat rails .

52 13 .. Removing and Installing/Replacing Guide For Front Left Or Right Head Restraint

Necessary preliminary tasks

1. Remove head restraint. See «52 13 390 Removing and installing or replacing front left or right head restraint (normal/semielectric)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-13-390-removing-and-installing) .
2. Remove rear panel on front seat. See «52 14 198 Removing and installing/replacing rear panel on left or right front seat backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-198-removing-and-installingreplacing) .

Press catches together and feed guide upwards out of cover and padding.

Scheme 1

52 13 000 Removing and Installing Left Or Right Front Seat (Normal/Semi-Electric)

Operation is identical to

Replacing left or right front seat (normal/electric). See 52 14 000 Removing and installing left or right front seat .

52 13 010 Removing and Installing/Replacing Both Seat Rails On Left Or Right Front Seat (Normal/Semi-Electric)

Operation is identical to

Replacing both seat rails on left or right front seat (normal/electric). See 52 14 010 Removing and installing/replacing both seat rails on left or right front seat (normal/electric) .

52 13 015 Removing and Installing/Replacing Actuating Unit On Left Or Right Front Seat (Normal/Semi-Electric)

Necessary preliminary tasks

1. Remove outer cover on front seat. See «52 13 040 Removing and installing/replacing outer cover on left or right front seat (normal/semi-electric)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-13-040-removing-and-installingreplacing) .

Pull lever and release screw (1).

Note. Protect seat rails (mechanism) by covering against chips/swarf.

Drill out rivets (2) with 4.2 mm dia. drill bit.

Remove actuating unit.

Scheme 2

Unclip Bowden cable sleeve (1).

Feed Bowden cable nipple (2) out of fixture (3).

Scheme 3

52 13 020 Removing and Installing/Replacing Seat Frame On Left Or Right Front Seat (Normal/Semi-Electric)

Operation is identical to

Replacing seat frame on left or right front seat (normal/electric). See 52 14 020 Removing and installing/replacing seat frame on left or right front seat (normal/electric) .

52 13 030 Removing and Installing/Replacing Backrest Frame On Left Or Right Front Seat (Normal/Semi-Electric)

This operation is identical to

Replacing backrest frame on front seat (comfort). See 52 17 030 Removing and installing/replacing backrest frame on left or right seat (comfort) .

52 13 040 Removing and Installing/Replacing Outer Cover On Left Or Right Front Seat (Normal/Semi-Electric)

Pull lever forward to remove

1. If necessary, lever out lower locking point (1) from rear with a screwdriver.

Release screw (2).

If necessary, move seat fully forwards and upwards.

Scheme 4

Remove trim

1. Unclip at top edge
2. Unclip at rear towards top side
3. Pull on belt opening
4. Unlock lugs
5. Carefully remove trim towards front

Unfasten plug connection.

Replacement only

Remove switch. See 61 31 203 REPLACING SWITCH COMBINATION FOR SEAT ADJUSTMENT .

Scheme 5

Installation

Retaining clips and tabs must not be damaged.

Scheme 6

52 13 041 Removing and Installing Inner Cover On Left Or Right Front Seat (Normal/Semielectric)

Operation is identical to

Replacing inner cover on left or right front seat (normal/electric). See 52 13 050 Replacing left or right lumbar cushion on front seat (normal/semi-electric) .

52 13 050 Replacing Left Or Right Lumbar Cushion On Front Seat (Normal/Semi-Electric)

Operation is identical to

Replacing lumbar cushion on front left or right seat (normal/electric). See 52 14 050 Replacing lumbar cushion on front left or right seat .

52 13 060 Removing and Installing/Replacing Valve Housing For Left Or Right Front Lumbar Support (Normal/Semi-Electric)

Operation is identical to

Replacing valve housing for left or right front lumbar support (normal/electric). See 52 14 060 Removing and installing/replacing valve housing for left or right front lumbar support (normal/electric) .

52 13 198 Removing and Installing/Replacing Rear Panel On Left Or Right Front Seat Backrest (Normal/Semi-Electric)

Operation is identical to

Replacing rear panel on left or right front seat backrest (normal/electric). See 52 14 198 Removing and installing/replacing rear panel on left or right front seat backrest .

52 13 385 Replacing gas cartridge (pyroactivator) for crash-active head restraint on front seat

Switch off ignition!

Necessary preliminary tasks

1. Disconnect battery negative lead. See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove «crash-active head restraint»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-16-392-removing-and-installingreplacing) .

Starting situation: Head restraint is in the crash position after being triggered.

Scheme 7

Note. Pyroactivator can only be removed in the triggered state. The complete crash-active head restraint must be replaced if the event of a head restraint fault signal and an untriggered pyroactivator.

Removing cover: Raise cover (1) and pull towards rear.

Scheme 8

Removing pyrotechnical device: Press together retainer (1) for pyrotechnical device at lugs. Feed out pyrotechnical device.

Scheme 9

Removing pyroactivator: Pull pyroactivator (2) out of mounting (1) for pyrotechnical device. Unlock plug connection (3) and disconnect.

Scheme 10

Note. Dispose of plastic element and pyroactivator.

Procedure for installing pyrotechnical device

Bringing head restraint together - version without button (MFS): Pull spring catches apart and push head restraint together. Maintain position.

Scheme 11

Bringing head restraint together - version with button (Basic): Press button (1) and push head restraint together. Maintain position.

Scheme 12

Locking release plate: Hold pushed-together head restraint in position and push release plate (1) upwards up to stop. Release plate (1) must audibly snap into place.

Scheme 13

Checking head restraint lock: Check end position of release plate (1). All four springs must be engaged (snapped into place).

Scheme 14

Replacing pyrotechnical device: Connect plug (1) to new pyroactivator (2) and lock. Clip pyroactivator (2) into new mounting (3).

Scheme 15

Installing pyrotechnical device: Press together retainer for pyrotechnical device at lugs. Insert retainer for pyrotechnical device into release plate and tilt in upward direction. Retainer for pyrotechnical device must audibly snap into place.

Note. Check seating of retaining lugs in retainer.

Scheme 16

Laying wiring harness: Secure wiring harness in carrier section with strain relief.

Scheme 17

Mounting cover: Clip cover onto carrier section. Cover must audibly snap into place.

Scheme 18

52 13 390 Removing and Installing Or Replacing Front Left Or Right Head Restraint (Normal/Semielectric)

Operation is identical to

Replacing front left or right head restraint (normal/electric). See 52 14 390 Removing and installing or replacing front left or right head restraint .

52 13 393 Removing and Installing/Replacing Front Left Or Right Crash-Active Head Restraint

Switch off ignition!

Necessary preliminary tasks

1. Disconnect battery negative lead. See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove rear panel. See «52 13 198 Removing and Installing/Replacing Rear Panel On Left Or Right Front Seat Backrest (Normal/Semi-Electric)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-13-198-removing-and-installingreplacing) .

Unfasten plug connection (1) and disconnect.

Feed wiring harness out of backrest frame.

Lift out head restraint.

52 13 400 Replacing Seat Cover For Left Or Right Front Seat (Normal/Semi-Electric)

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers) .

Necessary preliminary tasks

1. Remove front seat. See «52 14 000 Removing and installing left or right front seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-000-removing-and-installing)
2. Remove rear panel on front seat backrest. See «52 14 198 Removing and installing/replacing rear panel on left or right front seat backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-198-removing-and-installingreplacing) .
3. Remove inner cover on front seat. See «52 14 041 Removing and installing inner cover on left or right front seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-041-removing-and-installing) .

When replacing seat cover

If seat cover is defective, seat cover and padding with OC3 mat must be replaced together.

New seat cover is supplied with padding, OC3 mat and if necessary seat heating.

When replacing padding with OC3 mat

If OC3 mat or padding is defective, both parts may only be replaced together.

These must be fitted with the seat cover from the car.

After fitting seat cover, enable OC3 mat with BMW diagnosis system.

Enabling seat occupancy detector (OC3 mat)

1. Connect BMW diagnosis system
2. Release seat occupancy detector
3. Clear fault memory if necessary

Unhook seat cover (2) at all retaining points.

Lever out left and right clips (1).

Installation

If necessary, replace faulty clips (1).

Remove seat cover (2) with support.

If necessary, disconnect all plug connections.

Scheme 19

Version with OC3 mat

1. OC3 mat must not be kinked under any circumstances.

Detach all retainers in side area from longitudinal wires (1).

Pull trim wires (1) forward out of seat cover.

Carefully fold back seat cover and release retainers from cross - wires (2).

Remove seat cover from padding.

Scheme 20

Padding (1) with OC3 mat (2).

Scheme 21

Installation

Bend new retainer (2) closed with pliers 52 0 050. See 52 0 050 PLIERS

Scheme 22

1. Padding
2. Clips
3. Trim wire in seat cover
4. Trim wire in padding
5. Seat cover

Remove trim threads (1) from seat cover (2).

1. (3) If necessary, cable for seat heating

Installation

Slide trim threads (1) into new seat cover (2). If necessary, cut mounting for trim threads.

Scheme 23

52 13 405 Replacing Backrest Cover For Left Or Right Front Seat (Normal/Semi-Electric)

Special tools required

1. 00 9 317. See «00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE)»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-special-tools__00-9-310-assembly-wedges-set)
2. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

1. Remove front seat. See «52 14 000 Removing and installing left or right front seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-000-removing-and-installing) .
2. Remove rear panel on front seat backrest. See «52 14 198 Removing and installing/replacing rear panel on left or right front seat backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-198-removing-and-installingreplacing) .

Detach plug connection (1) by twisting from backrest frame.

Disconnect plug-in connection.

Scheme 24

Release all retainers (1) on cover.

Remove cover.

Scheme 25

For A/C optional extra only

Disconnect cable strap (1) on wiring harness for fan.

Disconnect plug connections (2).

Scheme 26

Unhook backrest cover at retaining points in area (1).

Scheme 27

Unhook backrest cover (1) at bottom and sides towards front.

Pull off backrest cover (1) with padding towards top from backrest frame (2).

Scheme 28

Release all retainers.

Remove backrest cover (1) from padding.

Remove all remnants of clips from backrest cover (1) and padding.

Scheme 29

Installation

Bend new retainer (2) closed with pliers 52 0 050. See 52 0 050 PLIERS .

Scheme 30

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim wire in backrest cover
5. Backrest cover

Remove trim threads (1) from backrest cover.

1. (2) Seat heater cable

Installation

Push trim threads (1) into new backrest cover.

If necessary, cut into new component.

Scheme 31

Lever out locking strip of head restraint guide with special tool 00 9 317. See 00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE) .

Installation

Mount straight front face of head restraint guide towards front.

Scheme 32

52 13 415 Replacing Support For Left Or Right Front Seat (Normal/Semi-Electric)

The operation for removing the padding with/without OC3 mat is described in

1. Replacing seat cover for front seat. See «52 13 400 Replacing Seat Cover For Left Or Right Front Seat (Normal/Semi-Electric)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-13-400-replacing-seat-cover) .

Enabling seat occupancy detector (OC3 mat)

1. Connect BMW diagnosis system
2. Release seat occupancy detector
3. Clear fault memory if necessary

52 13 420 Replacing Padding For Left Or Right Front Seat Backrest (Normal/Semi-Electric)

Operation is described in

Remove backrest cover for front seat. See 52 13 405 Replacing Backrest Cover For Left Or Right Front Seat (Normal/Semi-Electric) .

52 14 .. Removing and Installing Outer Upper Rail Trim With Electric Anchor Fitting Tensioner (from 04/2004)

Driver's seat only

Note. Version with anchor fitting tensioner from 04/2004.

Lever trim (3) out of seat mechanism

1. upwards
2. slide towards rear

and feed out of anchor fitting tensioner.

Installation

Secure plug connection with felt strip against unlocking.

Lock on plug connection to anchor fitting tensioner can be unlocked when trim is fitted.

Scheme 33

52 14 .. Removing and Installing/Replacing Guide For Front Left Or Right Head Restraint

Necessary preliminary tasks

1. Remove head restraint. See «52 14 390 Removing and installing or replacing front left or right head restraint»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-390-removing-and-installing) .
2. Remove rear panel on front seat backrest. See «52 14 198 Removing and installing/replacing rear panel on left or right front seat backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-198-removing-and-installingreplacing) .

Pull backrest cover (1) in direction of arrow over metal lugs (2) and detach.

If necessary, detach backrest cover on both sides from backrest frame.

Scheme 34

Unlock catches (1) and remove guide (2) towards top.

Scheme 35

52 14 000 Removing and Installing Left Or Right Front Seat

Necessary preliminary tasks

1. Remove front head restraint. See «52 13 390 Removing and Installing Or Replacing Front Left Or Right Head Restraint (Normal/Semielectric)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-13-390-removing-and-installing) .

Switch off ignition!

Move front seat upwards.

Release screw (1) on front seat.

Installation

Replace screw.

Tightening torque 72 11 02AZ. See 72 11 SEAT BELTS .

Feed out belt anchor fitting (2).

Scheme 36

Move front seat forwards.

Release screws.

Installation

Replace screws.

Tightening torques 52 10 01AZ. See 52 10 FRONT SEATS .

Scheme 37

Removing cover on left and right

Move front seat towards rear.

Carefully raise lug (1).

At same time, unlock inner side (2) in direction of arrow.

Remove cover in direction of arrow towards front.

Scheme 38

Release bolts (1).

Installation

Replace screws.

Tightening torque 52 10 01AZ. See 52 10 FRONT SEATS .

Scheme 39

Installation

Carpet must not project between seat rail and floor board in area of screw-down points (grinding noises).

Unclip cover (1) towards front.

Unfasten plug connection (2) and disconnect.

Unclip wiring harness from seat mechanism.

Lift out front seat.

Scheme 40

Installation

Make sure wiring harness is correctly routed in order to avoid grating noises, jamming or collisions.

Clip in cable holder for wiring harness.

Lay wiring harness only in area (1) of cover.

Fitting the wiring harness between the carpet and the cover in control unit area (2) will result in grating noises.

Carry out a complete longitudinal adjustment (forward/back) with front seat.

Scheme 41

52 14 010 Removing and Installing/Replacing Both Seat Rails On Left Or Right Front Seat (Normal/Electric)

Necessary preliminary tasks

1. Remove front seat. See «52 14 000 Removing and Installing Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-000-removing-and-installing) .
2. Remove lower strap (belt tensioner). See «72 11 041 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT LOWER BELT FITTING (SEAT BELT TENSIONER)»(/bmw/x5/e70-2006-2010/remont/airbag/#parts-and-accessories-repair__72-11-041-removing-and-installingreplacing) .
3. Remove drive unit for longitudinal seat adjustment. See «67 31 500 REMOVING AND INSTALLING/REPLACING DRIVE UNIT FOR LONGITUDINAL SEAT ADJUSTMENT»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#electrical-drives-repair__67-31-500-removing-and-installingreplacing) .

Switch off ignition!

Unlock all plug connections and disconnect.

Scheme 42

Press catches (1).

Slide adjusting unit (2) for active head restraint adjustment in direction of arrow and remove.

Scheme 43

Release left and right screws (1).

Tightening torque 52 10 6AZ. See 52 10 FRONT SEATS .

Remove seat rails (4) with carrier plate (3).

Release fastening elements (2) on left and right.

Remove carrier plate (3).

Scheme 44

Release screws (1).

Remove holder (2) for lower strap (belt tensioner).

Scheme 45

52 14 020 Removing and Installing/Replacing Seat Frame On Left Or Right Front Seat (Normal/Electric)

Necessary preliminary tasks

1. Remove front seat. See «52 14 000 Removing and Installing Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-000-removing-and-installing) .
2. Remove backrest frame. See «52 14 030 Removing and installing/replacing backrest frame on left or right front seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-030-removing-and-installingreplacing) .
3. Remove both seat rails on front seat. See «52 14 010 Removing and Installing/Replacing Both Seat Rails On Left Or Right Front Seat (Normal/Electric)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-010-removing-and-installingreplacing) .
4. Remove seat cover for front seat. See «52 14 000 Removing and Installing Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-000-removing-and-installing) .

Release fastening elements (1) on left and right.

Remove component (2) on left and right.

Remove complete seat wiring harness.

Scheme 46

Installation

When replacing backrest or seat frame, break off centering hooks (1) from seat frame.

Scheme 47

Note. The new seat frame part contains all the drives.

52 14 023 Removing and Installing / Replacing Drive For Left Or Right Active Seat

Necessary preliminary tasks

1. Remove front seat. See «52 17 000 Removing and installing left or right front seat (comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-000-removing-and-installing) .
2. Remove seat cover with padding for front seat. See «52 17 400 Removing and installing/replacing seat cover for left or right front seat (comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-400-removing-and-installingreplacing) .

Release screws (1).

Tip seat towards rear.

Installation

Tightening torque 52 10 6AZ. See 52 10 FRONT SEATS .

Scheme 48

Unclip hydraulic pockets (1) with supports on left and right from flex mat.

Note. If necessary, release clips (2). Remove hydraulic pockets (1) from supports (3).

Feed hydraulic pockets (1) through flex mat towards bottom.

Detach retaining points for drive in area (4).

Scheme 49

Disconnect plug connection.

Remove drive (1).

Note. Drive and hydraulic pockets form a single unit and can only be replaced completely.

Scheme 50

52 14 030 Removing and Installing/Replacing Backrest Frame On Left Or Right Front Seat

This operation is identical to

Replace backrest frame on front seat (comfort). See 52 17 030 Removing and installing/replacing backrest frame on left or right seat (comfort) .

52 14 040 Removing and Installing/Replacing Outer Cover On Left Or Right Front Seat

If necessary, move seat fully forwards and upwards.

Remove trim

Scheme 51

1. Unclip at rear towards top side
2. Pull on belt opening to one side
3. Bend trim open slightly at top and bottom on actuating unit
4. Bend open slightly at top and bottom and pull outwards a little

Installation

Retaining clips must not be damaged.

Scheme 52

52 14 041 Removing and Installing Inner Cover On Left Or Right Front Seat

Necessary preliminary tasks

1. Remove front seat.

Release screw (1).

Scheme 53

Installation

Cover is secured by guide (2) in hole (1).

Scheme 54

52 14 050 Replacing Lumbar Cushion On Front Left Or Right Seat

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

Scheme 55

1. Remove rear panel on front seat backrest. See «52 14 198 Removing and installing/replacing rear panel on left or right front seat backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-198-removing-and-installingreplacing) .

Detach backrest cover (1) at bottom from backrest frame.

Remove valve housing. See 52 13 060 Removing and Installing/Replacing Valve Housing For Left Or Right Front Lumbar Support (Normal/Semi-Electric) .

Disconnect air hoses (2) from valve housing.

Note. Heat air hoses gently if they are firmly seated on valve housing. Housing of valve block must not be unclipped (leakage). If necessary, release mounting and clip housing together.

If necessary, cut all retainers on lumbar cushion (3) and spring wire.

Note. Remove all remnants of retainers. Lock new retainers by bending with special tool 52 0 050. See 52 0 050 PLIERS

Detach lumbar cushion (3) from spring wire.

Remove lumbar cushion (3) downwards between backrest frame and seat mechanism.

Installation

Make sure air hoses are correctly connected to valve block (colour coding).

Air hoses must be laid without kinks.

Check lumbar cushion for damage.

52 14 060 Removing and Installing/Replacing Valve Housing For Left Or Right Front Lumbar Support (Normal/Electric)

Necessary preliminary tasks

1. Remove rear panel on front seat backrest. See «52 14 198 Removing and installing/replacing rear panel on left or right front seat backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-198-removing-and-installingreplacing) .

Release retaining screw (1).

Disconnect electrical plug connection.

Scheme 56

Disconnect air hoses (1) and (2).

Installation

Make sure air hoses (2) are correctly connected to valve block (colour coding: red/blue).

Housing on valve block must not be unclipped (leakage). If necessary, clip housing together.

Scheme 57

52 14 198 Removing and Installing/Replacing Rear Panel On Left Or Right Front Seat Backrest

Operation is shown on the left seat. When removing from the right seat, transpose the pull and striking sides accordingly.

Scheme 58

1. Grip between rear panel and backrest cover on door side until clip can be felt (do not pull).
2. At same time, firmly punch towards middle of seat on inner side (tunnel side) at top. Upper retainers spring out of seat guide.
3. Pull rear panel up out of lower guides.

Installation

Rear panel and clips must not be damaged.

Scheme 59

1. Upper clips
2. Lower clips

52 14 380 Removing and Installing/Replacing Head Restraint Mount On Left Or Right Front Seat

Operation is identical to

Replacing drive for head restraint adjustment on left or right front seat. See 67 31 570 REMOVING AND INSTALLING/REPLACING DRIVE UNIT FOR HEAD RESTRAINT HEIGHT ADJUSTMENT ON LEFT OR RIGHT FRONT SEAT .

52 14 390 Removing and Installing Or Replacing Front Left Or Right Head Restraint

Move headrest up as far as possible.

Pull out forcefully.

Installation

Press in head restraint until it can be heard to snap into place.

Scheme 60

52 14 400 Replacing Cover For Left Or Right Front Seat

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers) .

Necessary preliminary tasks

1. Remove front seat. See «52 14 000 Removing and Installing Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-000-removing-and-installing) .
2. Remove rear panel on front seat backrest. See «52 14 198 Removing and Installing/Replacing Rear Panel On Left Or Right Front Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-198-removing-and-installingreplacing) .
3. Remove inner cover on front seat. See «52 14 041 Removing and Installing Inner Cover On Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-041-removing-and-installing) .

When replacing seat cover

If seat cover is defective, seat cover and padding with OC3 mat must be replaced together.

New seat cover is supplied with padding, OC3 mat and if necessary seat heating.

When replacing padding with OC3 mat

If OC3 mat or padding is defective, both parts may only be replaced together.

Both parts must be fitted with the seat cover from the vehicle.

Enabling seat occupancy detector (OC3 mat)

1. Connect BMW diagnosis system
2. Release seat occupancy detector
3. Clear fault memory if necessary

Remove cover (1) on front seat

Scheme 61

1. Press clip on door side outwards
2. Press clip on tunnel side upwards
3. Pull cover (1) forwards out of seat mechanism

Unhook seat cover on at all retaining points (1).

Scheme 62

Unhook seat cover (1) in area (2).

If necessary, detach plug connections (3).

Remove seat cover (1) complete with support.

Scheme 63

Replacing seat cover

Version with OC3 mat

1. OC3 mat must not be kinked under any circumstances.

Detach all retainers in side area from longitudinal wires (1).

Pull trim wires (1) forward out of seat cover.

Carefully fold back seat cover and release retainers from cross - wires (2).

Remove seat cover from padding.

Padding (1) with OC3 mat (2).

Installation

Bend new retainer (2) closed with pliers 52 0 050. . See 52 0 050 PLIERS

1. Padding
2. Clips
3. Trim wire in seat cover
4. Trim wire in padding
5. Seat cover

Remove trim threads (1) from seat cover (2).

(3) If necessary, cable for seat heating

Installation

Slide trim threads (1) into new seat cover (2). If necessary, cut mounting for trim threads.

52 16 .. Removing and Installing/Replacing All Trims On Left Or Right Seat Rails

Operation is identical to

Removing all trims on left or right seat rail. See 52 17 .. Removing and installing/replacing all trims on left or right seat rails .

52 16 .. Removing and Installing/Replacing Guide For Front Left Or Right Head Restraint

Operation is identical to

1. Removing guide for front head restraint. See «52 14 .. Removing and Installing/Replacing Guide For Front Left Or Right Head Restraint»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-removing-and-installingreplacing) .

52 16 .. Replacing Padding For Front Seat Thigh Support

Release screws (1).

Installation

Insert screws (1) with Loctite.

Scheme 64

Unhook seat cover (1) from marked area.

Remove carrier (2) for thigh support.

Scheme 65

For seat heating optional extra only

Carefully detach felt (1) from thigh support.

Unfasten plug connection (2) and disconnect.

Installation

Ensure correct cable routing.

Remove padding from cover.

Scheme 66

52 16 000 Removing and Installing Left Or Right Front Seat

Operation is identical to

Replacing left or right front seat (normal/electric). See 52 14 000 Removing and Installing Left Or Right Front Seat .

52 16 010 Removing and Installing/Replacing Both Seat Rails On Left Or Right Front Seat

Operation is identical to

Replacing both seat rails on left or right front seat (normal/electric). See 52 14 010 Removing and Installing/Replacing Both Seat Rails On Left Or Right Front Seat (Normal/Electric) .

52 16 020 Removing and Installing/Replacing Seat Frame On Left Or Right Front Seat

Operation is identical to

Replacing seat frame on left or right front seat (normal/electric). See 52 14 020 Removing and Installing/Replacing Seat Frame On Left Or Right Front Seat (Normal/Electric) .

52 16 023 Removing and Installing/Replacing Adjusting Unit For Thigh Support On Left Or Right Front Seat

Necessary preliminary tasks

1. Remove front seat. See «52 14 000 Removing and Installing Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-000-removing-and-installing) .

Move thigh support forwards as far as possible.

Unfasten plug connection (1) and disconnect.

Release screws (2).

Installation

Insert screws (2) with Loctite.

Scheme 67

Release screws in areas (1).

Feed out adjusting unit (2) complete with drive in direction of arrow and remove.

Scheme 68

52 16 030 Removing and Installing/Replacing Backrest Frame On Left Or Right Front Seat

Operation is identical to

Replacing backrest frame on front seat (comfort). See 52 17 030 Removing and installing/replacing backrest frame on left or right seat (comfort) .

52 16 040 Removing and Installing/Replacing Outer Cover On Left Or Right Front Seat

Operation is identical to

1. Removing and installing/replacing outer cover on left or right front seat. See «52 14 040 Removing and Installing/Replacing Outer Cover On Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-040-removing-and-installingreplacing) .

52 16 041 Removing and Installing Inner Cover On Left Or Right Front Seat

Operation is identical to

Replacing inner cover on left or right front seat (normal/electric). See 52 14 041 Removing and Installing Inner Cover On Left Or Right Front Seat .

52 16 050 Replacing Lumbar Cushion On Front Left Or Right Seat

Operation is identical to

Replacing lumbar cushion on front left or right seat (normal/electric). See 52 14 050 Replacing Lumbar Cushion On Front Left Or Right Seat .

52 16 060 Removing and Installing/Replacing Valve Housing For Left Or Right Front Lumbar Support

Operation is identical to

Replacing valve housing for left or right front lumbar support (normal/electric). See 52 14 060 Removing and Installing/Replacing Valve Housing For Left Or Right Front Lumbar Support (Normal/Electric) .

52 16 095 Removing and Installing/Replacing Thigh Support Holder On Front Left Or Right Seat (Sports/Electric)

Necessary preliminary tasks

1. Move thigh support forwards fully

Unfasten plug connection (1) and disconnect.

Release screws (2).

Installation

Insert screws (2) with Loctite.

Detach seat cover (1) in marked area from carrier (2) for thigh support.

Feed plug out of carrier (2) for thigh support.

Remove carrier (2) for thigh support.

Scheme 69

52 16 198 Removing and Installing Or Replacing Rear Panel On Left Or Right Front Seat Backrest

Operation is identical to

Replacing rear panel on left or right front seat backrest (normal/electric). See 52 14 198 Removing and Installing/Replacing Rear Panel On Left Or Right Front Seat Backrest .

52 16 380 Removing and Installing/Replacing Head Restraint Mount On Left Or Right Front Seat

Operation is identical to

Replacing drive for head restraint adjustment on left or right front seat. See 67 31 570 REMOVING AND INSTALLING/REPLACING DRIVE UNIT FOR HEAD RESTRAINT HEIGHT ADJUSTMENT ON LEFT OR RIGHT FRONT SEAT .

52 16 390 Removing and Installing Or Replacing Front Left Or Right Head Restraint

Operation is identical to

Replacing front left or right head restraint (normal/electric). See 52 14 390 Removing and Installing Or Replacing Front Left Or Right Head Restraint .

52 16 392 Removing and installing/replacing front left or right crash-active head restraint

Switch off ignition!

Necessary preliminary tasks

1. Disconnect battery negative lead. See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove rear panel. See «52 13 198 Removing and Installing/Replacing Rear Panel On Left Or Right Front Seat Backrest (Normal/Semi-Electric)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-13-198-removing-and-installingreplacing) .

Unlock plug connection (1) and disconnect. Feed out wiring harness from head restraint height adjustment and foam material.

Scheme 70

Lever out locking clamps (1)

Scheme 71

Lift out head restraint.

Scheme 72

52 16 400 Removing and Installing/Replacing Seat Cover For Left Or Right Front Seat (Sport/Electric)

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

1. Remove front seat. See «52 14 000 Removing and Installing Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-000-removing-and-installing) .
2. Remove rear panel on front seat backrest. See «52 16 198 Removing and Installing Or Replacing Rear Panel On Left Or Right Front Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-16-198-removing-and-installing) .
3. Remove inner cover on front seat. See «52 14 041 Removing and Installing Inner Cover On Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-041-removing-and-installing) .
4. Remove switch combination for seat adjustment. See «61 31 203 REPLACING SWITCH COMBINATION FOR SEAT ADJUSTMENT»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-203-replacing-switch-combination) .

When replacing seat cover

If seat cover is defective, seat cover and padding with OC3 mat must be replaced together.

New seat cover is supplied with padding, OC3 mat and if necessary seat heating.

When replacing padding with OC3 mat

If OC3 mat or padding is defective, both parts may only be replaced together.

Both parts must be fitted with the seat cover from the vehicle.

Enabling seat occupancy detector (OC3 mat)

1. Connect BMW diagnosis system
2. Release seat occupancy detector
3. Clear fault memory if necessary

Unclip cover (1) on front seat.

Release screws (1).

Disconnect plug connections (2) and detach cable.

Remove thigh support (3) towards top.

Scheme 73

Detach seat cover (1) in marked area on left and right.

Lever out left and right clips (2).

Installation

If necessary, replace faulty clips.

Scheme 74

Unhook seat cover (1) in area (2).

Disconnect plug connection (3).

Remove seat cover (1) complete with support.

Version with OC3 mat

1. OC3 mat must not be kinked under any circumstances.

Detach all retainers in side area from longitudinal wires (1).

Pull trim wires (1) forward out of seat cover.

Carefully fold back seat cover and release retainers from cross - wires (2).

Remove seat cover from padding.

Scheme 75

Detach cable strap (3).

Unlock plug connection (4) and disconnect.

Detach seat cover (2) in marked area from thigh support (1).

Scheme 76

Padding (1) with OC3 mat (2).

Installation

Bend new retainers closed with pliers 52 0 050. See 52 0 050 PLIERS .

Scheme 77

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim thread in cover
5. Seat cover

Replacing seat cover

Pull trim threads (1) out of seat cover (2).

Installation

Slide trim threads (1) into new seat cover (2). If necessary, cut mounting for trim threads.

1. (3) Seat heater cable

Scheme 78

52 16 405 Replacing Backrest Cover For Left Or Right Front Seat

Special tools required

1. 00 9 317. See «00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE)»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-special-tools__00-9-310-assembly-wedges-set) .
2. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers) .

Necessary preliminary tasks

1. Remove front seat. See «52 16 000 Removing and Installing Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-16-000-removing-and-installing) .
2. Remove rear panel on front seat backrest. See «52 16 198 Removing and Installing Or Replacing Rear Panel On Left Or Right Front Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-16-198-removing-and-installing) .

Detach plug connection (1) by twisting from backrest frame.

Disconnect plug-in connection.

Scheme 79

Release all retainers (1) on cover.

Remove cover.

For A/C optional extra only

Disconnect cable strap (1) on wiring harness for fan.

Disconnect plug connections (2).

Unhook backrest cover at retaining points in area (1).

Unhook backrest cover (1) at bottom and sides towards front.

Pull off backrest cover (1) with padding towards top from backrest frame (2).

Release all retainers.

Remove backrest cover (1) from padding.

Remove all remnants of clips from backrest cover (1) and padding.

Installation

Bend new retainer (2) closed with pliers 52 0 050. See 52 0 050 PLIERS

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim wire in backrest cover
5. Backrest cover

Remove trim threads (1) from backrest cover.

1. (2) Seat heater cable

Installation

Push trim threads (1) into new backrest cover.

If necessary, cut into new component.

Lever out locking strip of head restraint guide with special tool 00 9 317. See 00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE) .

Installation

Mount straight front face of head restraint guide towards front.

52 16 415 Replacing Padding For Left Or Right Front Seat

The operation for removing the padding with/without OC3 mat is described in

1. Replacing seat cover for front seat. See «52 16 400 Removing and Installing/Replacing Seat Cover For Left Or Right Front Seat (Sport/Electric)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-16-400-removing-and-installingreplacing) .

Enabling seat occupancy detector (OC3 mat)

1. Connect BMW diagnosis system
2. Release seat occupancy detector
3. Clear fault memory if necessary

52 16 420 Replacing Padding For Left Or Right Front Seat Backrest (Normal/Semi-Electric)

Operation is described in

Remove backrest cover for front seat. See 52 13 405 Replacing Backrest Cover For Left Or Right Front Seat (Normal/Semi-Electric) .

Driver's seat only

Note. Version with anchor fitting tensioner from 04/2004.

Lever trim (3) out of seat mechanism

1. upwards
2. slide towards rear

and feed out of anchor fitting tensioner.

Installation

Secure plug connection with felt strip against unlocking.

Lock on plug connection to anchor fitting tensioner can be unlocked when trim is fitted.

52 17 .. Removing and Installing/Replacing All Trims On Left Or Right Seat Rails

Trim, top rail, front

Scheme 80

1. Move seat backwards and upwards
2. Unclip front trim (1) towards top and detach towards top

Trim, top rail, outer

Scheme 81

1. Move seat forwards and upwards
2. Unclip front trim towards top and detach towards rear

Trim, bottom rail, front

1. Move seat backwards
2. Unclip trim tongue towards top, sliding trim towards front slightly
3. Pull inside surface of trim inwards slightly and unclip
4. Detach trim towards front from bottom rail

Installation

Place trim on bottom rail and slide towards rear to engage, feeding in below trim, top rail, outer.

Scheme 82

Trim, bottom rail, rear

Scheme 83

1. Move seat forwards
2. Unclip trim tongue towards top
3. Pull inside surface of trim inwards
4. Detach trim towards rear from bottom rail

Installation

Clips and hooks must not be damaged.

Make sure trims are exactly seated.

After completing tasks, move seat and make sure that trim does not move.

52 17 .. Removing and Installing/Replacing Left Or Right Thigh Support

Release screws (1).

Disconnect plug connections (2).

Remove thigh support (3) towards top.

If necessary, unclip trim (1) towards top and remove.

Installation

Secure guide pins (2) in seat frame and clip trim (1) into place.

Scheme 84

52 17 .. Replacing Padding For Front Seat Thigh Support

Necessary preliminary tasks

Scheme 85

1. Remove thigh support. See «52 17 .. Removing and Installing/Replacing Left Or Right Thigh Support»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-removing-and-installingreplacing) .

Note. Picture shows versions with air conditioning and seat heating.

Feed out seat cover (1) in area (2).

Installation

Seat cover (1) is fastened by hooks in trim (3).

Remove plug connections (4) and feed out through trim (3).

Remove trim (3); if necessary, remove padding or cover.

Version with seat heating or air conditioning

Feed out cable (1) and remove padding (2).

Installation

Ensure correct cable routing (1).

Scheme 86

Version with air conditioning

Scheme 87

1. Remove separating net (1).
2. Lift out fan (2).

52 17 000 Removing and Installing Left Or Right Front Seat (Comfort)

This operation is identical to

Removing and installing front seat (normal/electric), left or right. See 52 14 000 Removing and Installing Left Or Right Front Seat .

52 17 020 Removing and Installing/Replacing Seat Frame On Left Or Right Front Seat (Comfort)

Necessary preliminary tasks

1. Remove front seat. See «52 17 000 Removing and Installing Left Or Right Front Seat (Comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-000-removing-and-installing) .
2. Remove seat cover. See «61 31 203 REPLACING SWITCH COMBINATION FOR SEAT ADJUSTMENT»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-203-replacing-switch-combination) .
3. Remove backrest frame on front seat. See «52 17 030 Removing and installing/replacing backrest frame on left or right seat (comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-030-removing-and-installingreplacing) .
4. If necessary, remove drive unit for active seat. See «52 14 023 Removing and Installing / Replacing Drive For Left Or Right Active Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-023-removing-and-installing) .

Remove wiring harness (1) from seat frame (2).

Scheme 88

Release rivets (1) on left and right, remove fastening strips (2) on left and right.

Release screws (3).

Tightening torque 52 10 6AZ. See 52 10 FRONT SEATS .

Remove seat frame.

Scheme 89

Installation

When replacing backrest or seat frame, break off centering hooks (1) from seat frame.

The new seat frame part contains all the drives.

52 17 023 Removing and Installing/Replacing Adjusting Unit For Thigh Support On Left Or Right Front Seat

Necessary preliminary tasks

1. Remove front seat. See «52 17 000 Removing and Installing Left Or Right Front Seat (Comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-000-removing-and-installing) .
2. Remove thigh support. See «52 17 .. Removing and Installing/Replacing Left Or Right Thigh Support»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-removing-and-installingreplacing) .

Move thigh support forwards as far as possible.

Release screws (1).

Detach compressor (2) complete with holder (3) in direction of arrow.

Installation

Attach holder (3) in area (5).

Disconnect plug connection (4) on drive.

Scheme 90

Release screws in areas (1).

Feed out adjusting unit (2) complete with drive in direction of arrow and remove.

52 17 030 Removing and Installing/Replacing Backrest Frame On Left Or Right Seat (Comfort)

Necessary preliminary tasks

1. Remove front seat. See «52 17 000 Removing and Installing Left Or Right Front Seat (Comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-000-removing-and-installing) .
2. Remove backrest cover for front seat. See «52 17 405 Replacing backrest cover for left or right front seat (comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-405-replacing-backrest-cover) .
3. Remove head restraint support on front seat. See «52 17 380 Removing and installing/replacing head restraint mount on left or right front seat (comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-380-removing-and-installingreplacing) .

Release all cable ties on wiring harness (1).

Disconnect all marked plug connections.

Feed through wiring harness (1) at bottom right on backrest frame.

Scheme 91

Unclip left and right clips (1).

Unhook seat covers (2) on left and right.

Release left and right screws (3).

Tightening torque 52 10 2AZ. See 52 10 FRONT SEATS

If necessary, remove lumbar cushion with drive and valve block.

Remove backrest frame.

Scheme 92

Installation

When replacing backrest or seat frame, break off centering hooks (1) from seat frame.

Note. The new backrest frame part contains all the drives. Before installing, check whether backrest frame has a date of manufacture after September 2004.

52 17 034 Removing and Installing/Replacing Shaft For Head Restraint Adjustment

Necessary preliminary tasks

1. Remove front seat. See «52 17 000 Removing and Installing Left Or Right Front Seat (Comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-000-removing-and-installing) .
2. Remove both rear panels. See «52 17 205 Removing and installing/replacing both rear panels on left or right front seat backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-205-removing-and-installingreplacing) .
3. Remove inner cover. See «52 17 041 Removing and installing/replacing inner cover on left or right front seat (comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-041-removing-and-installingreplacing) .
4. Remove active head restraint support. See «52 17 380 Removing and installing/replacing head restraint mount on left or right front seat (comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-380-removing-and-installingreplacing) .

Bend shaft (1) in direction of arrow.

Pull shaft (1) out of gear (2) and remove.

Scheme 93

52 17 035 Removing and Installing/Replacing Gearing For Head Restraint Adjustment

Necessary preliminary tasks

1. Remove shaft for head restraint adjustment. See «52 17 034 Removing and Installing/Replacing Shaft For Head Restraint Adjustment»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-034-removing-and-installingreplacing) .

Remove retainer (1) on left and right.

Remove gearing (2) on left and right straight towards front.

Installation

To ensure identical adjustment of gearings (2), carry out following work step on both gearings

Scheme 94

1. Unscrew component (4) until threaded rod (5) is flush with edge (3).

52 17 040 Removing and Installing/Replacing Outer Cover On Left Or Right Front Seat

Note. Operation is identical to: Removing and installing/replacing outer cover on left or right front seat. See 52 14 040 Removing and Installing/Replacing Outer Cover On Left Or Right Front Seat .

52 17 041 Removing and Installing/Replacing Inner Cover On Left Or Right Front Seat (Comfort)

This operation is identical to

Replacing cover on inner front seat (normal/electric). See 52 14 041 Removing and Installing Inner Cover On Left Or Right Front Seat .

52 17 050 Replacing Lumbar Cushion On Left Or Right Front Seat (Comfort)

This operation is identical to

Replacing lumbar cushion on front seat (normal/electric). See 52 14 050 Replacing Lumbar Cushion On Front Left Or Right Seat .

52 17 054 Removing and Installing/Replacing Adjusting Unit For Backrest Width Adjustment On Left Or Right Front Seat

Necessary preliminary tasks

1. Remove front seat. See «52 17 000 Removing and Installing Left Or Right Front Seat (Comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-000-removing-and-installing) .
2. Remove both rear panels on front seat backrest. See «52 17 205 Removing and installing/replacing both rear panels on left or right front seat backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-205-removing-and-installingreplacing) .
3. Remove inner cover on front seat. See «52 17 041 Removing and Installing/Replacing Inner Cover On Left Or Right Front Seat (Comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-041-removing-and-installingreplacing) .
4. Remove backrest cover for front seat. See «52 17 405 Replacing backrest cover for left or right front seat (comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-405-replacing-backrest-cover) .

Release cable tie (1).

Installation

Lay cables (3) without kinks.

Disconnect plug connection (2) on drive.

Scheme 95

Release rivets (1) on left and right and remove adjusting elements (3).

Release rivets (2) for drive.

Remove complete adjusting unit.

Note. Adjusting element (3), cables and drive form a single unit and can only be replaced completely.

Scheme 96

52 17 060 Removing and Installing/Replacing Valve Housing For Lumbar Cushion (Comfort)

This operation is identical to

Replacing valve housing for lumbar cushion (normal/electric). See 52 14 060 Removing and Installing/Replacing Valve Housing For Left Or Right Front Lumbar Support (Normal/Electric) .

52 17 200 Removing and Installing/Replacing Upper Rear Panel On Left Or Right Front Seat Backrest

This operation is described in

Remove both rear panels on front seat backrest. See 52 17 205 Removing and installing/replacing both rear panels on left or right front seat backrest .

52 17 202 Removing and Installing/Replacing Lower Rear Panel On Left Or Right Front Seat Backrest

This operation is described in

Remove both rear panels on front seat backrest. See 52 17 205 Removing and installing/replacing both rear panels on left or right front seat backrest .

52 17 205 Removing and Installing/Replacing Both Rear Panels On Left Or Right Front Seat Backrest

Operation is shown on the left seat. When removing from the right seat, transpose the pull and striking sides accordingly.

Rear panel upper section

Scheme 97

1. Grip between rear panel and backrest cover on door side until clip can be felt (do not pull).
2. At same time, firmly punch towards middle of seat on inner side (tunnel side) at top. Upper retainers spring out of seat guide.
3. Pull upper rear panel up out of lower guides.

Note. Retainer Guide Upper rear panel

Rear panel trim lower section

Scheme 98

1. Grip between rear panel and backrest cover on door side until clip can be felt (do not pull).
2. At same time, firmly punch towards middle of seat on inner side (tunnel side) at top. Upper retainers spring out of seat guide.
3. Pull lower rear panel up out of lower guides

Unclip springs (1) on left and right.

Remove lower rear panel (3) upwards out of guide (2).

Scheme 99

52 17 380 Removing and Installing/Replacing Head Restraint Mount On Left Or Right Front Seat (Comfort)

Necessary preliminary tasks

1. Remove head restraint. See «52 17 390 Removing and installing/replacing front left or right head restraint (comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-390-removing-and-installingreplacing) .
2. Remove both rear panels on front seat backrest. See «52 17 205 Removing and Installing/Replacing Both Rear Panels On Left Or Right Front Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-205-removing-and-installingreplacing) .

Detach retaining points (1).

Scheme 100

Release cable tie (1).

Disconnect plug connections (2).

Feed out AKS carrier (3) towards bottom.

Scheme 101

Release screws (1).

Installation

Guide pins (2) of head restraint mount must engage in openings on AKS carrier.

Feed out head restraint mount (3) sideways.

Scheme 102

52 17 385 Replacing Gas Cartridge For Active Head Restraint On Left Or Right Front Seat

Switch off ignition!

Necessary preliminary tasks

1. Remove head restraint. See «52 17 390 Removing and installing/replacing front left or right head restraint (comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-390-removing-and-installingreplacing) .
2. Remove rear panel on front seat backrest. See «52 17 205 Removing and Installing/Replacing Both Rear Panels On Left Or Right Front Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-205-removing-and-installingreplacing) .

Disconnect plug connection on gas cartridge.

Detach retaining points (1).

Slide active head restraint carrier downwards.

Scheme 103

Release spring clips (1) and (2).

Scheme 104

Release screws (1).

Remove gas cartridge complete with holder (2).

Scheme 105

Release screws (1) on left and right.

Installation

Insert screws (1) with Loctite.

Tightening torque 52 12 03AZ. See 52 10 FRONT SEATS .

Slide top rail (3) off bottom rail (2).

Remove gas cartridge (4).

Scheme 106

Installation

Gas cartridge (1) is secured in holder by guide lug (2).

Scheme 107

Procedure after triggered active head restraint

1. Push head restraint back into original position.
2. Insert new gas cartridge with spring clips.

Note. The gas cartridge may be replaced up to 5 times. Then the backrest must be replaced. Number of triggerings are stored in the control unit.

52 17 390 Removing and Installing/Replacing Front Left Or Right Head Restraint (Comfort)

Move headrest up as far as possible.

Pull out forcefully.

Installation

Position adjustment drive briefly before upper stop.

Press in head restraint until it clicks audibly into place (on right and left).

Scheme 108

52 17 400 Removing and Installing/Replacing Seat Cover For Left Or Right Front Seat (Comfort)

Special tools required

1. 00 9 317. See «00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE)»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-special-tools__00-9-310-assembly-wedges-set)
2. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

1. Remove front seat. See «52 14 000 Removing and Installing Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-000-removing-and-installing) .
2. Remove both rear panels on front seat backrest. See «52 17 205 Removing and Installing/Replacing Both Rear Panels On Left Or Right Front Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-205-removing-and-installingreplacing) .
3. Remove inner cover on front seat. See «52 14 041 Removing and Installing Inner Cover On Left Or Right Front Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-14-041-removing-and-installing) .
4. Remove thigh support. See «52 17 .. Removing and Installing/Replacing Left Or Right Thigh Support»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-removing-and-installingreplacing) .
5. Remove switch combination for seat adjustment. See «61 31 203 REPLACING SWITCH COMBINATION FOR SEAT ADJUSTMENT»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-203-replacing-switch-combination) .

When replacing seat cover

If seat cover is defective, seat cover and padding with OC3 mat must be replaced together.

New seat cover is supplied with padding, OC3 mat and if necessary seat heating.

When replacing padding with OC3 mat

If OC3 mat or padding is defective, both parts may only be replaced together.

Both parts must be fitted with the seat cover from the vehicle.

Enabling seat occupancy detector (OC3 mat)

1. Connect BMW diagnosis system
2. Release seat occupancy detector
3. Clear fault memory if necessary

Unclip cover (1) on front seat.

Unclip trim (1) for thigh support carrier with special tool 00 9 317. See 00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE) .

Scheme 109

Release retainers in area (1).

Detach seat cover in area (2) on left and right.

Remove cable (3).

Scheme 110

Unhook seat cover (1) in area (2).

Disconnect plug connection (3).

Remove seat cover (1) complete with support.

Version with OC3 mat

1. OC3 mat must not be kinked under any circumstances.

Detach all retainers in side area from longitudinal wires (1).

Pull trim wires (1) forward out of seat cover.

Carefully fold back seat cover and release retainers from cross - wires (2).

Remove seat cover from padding.

Padding (1) with OC3 mat (2).

Scheme 111

Installation

Bend new retainers closed with pliers 52 0 050. See 52 0 050 PLIERS

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim thread in cover
5. Seat cover

Replacing seat cover

Pull trim threads (1) out of seat cover.

Installation

Slide trim threads (1) into new seat cover. If necessary, cut mounting for trim threads.

Scheme 112

52 17 405 Replacing Backrest Cover For Left Or Right Front Seat (Comfort)

Special tools required

1. 00 9 317. See «00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE)»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-special-tools__00-9-310-assembly-wedges-set) .
2. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers) .

Necessary preliminary tasks

1. Remove front seat. See «52 17 000 Removing and Installing Left Or Right Front Seat (Comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-000-removing-and-installing) .
2. Remove both rear panels on front seat backrest. See «52 17 205 Removing and Installing/Replacing Both Rear Panels On Left Or Right Front Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-205-removing-and-installingreplacing) .
3. Remove inner cover on front seat. See «52 17 041 Removing and Installing/Replacing Inner Cover On Left Or Right Front Seat (Comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-041-removing-and-installingreplacing) .

Detach plug connection (1) by twisting from backrest frame.

Disconnect plug connection (1).

Unhook backrest cover (3) in areas (1).

Detach all retainers in areas (2).

Installation

Bend new retainers closed with pliers 52 0 050. See 52 0 050 PLIERS .

Scheme 113

Release all cable ties (1).

Disconnect all plug connections (2).

Scheme 114

Remove backrest cover (2) complete with padding towards front.

Installation

Adjusting unit (1) must be secured on left and right in opening of padding.

Scheme 115

Detach all retainers in areas (1).

Scheme 116

Release all retainers.

Installation

Bend new retainers closed with pliers 52 0 050. See 52 0 050 PLIERS

Remove backrest cover (1) from padding.

Remove all remnants of clips from backrest cover (1) and padding.

Scheme 117

Pull trim threads (1) out of backrest cover.

Installation

Push trim threads (1) into new backrest cover.

If necessary, cut into new component.

Scheme 118

Lever out locking strip of head restraint guide with plastic wedge 00 9 317. See 00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE) .

Installation

Mount straight front face of head restraint guide towards front.

52 17 415 Replacing Padding For Left Or Right Front Seat (Comfort)

The operation for removing the padding with/without OC3 mat is described in

1. Replacing seat cover for front seat. See «52 17 400 Removing and Installing/Replacing Seat Cover For Left Or Right Front Seat (Comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-400-removing-and-installingreplacing) .
2. Removing sensor mat

Enabling seat occupancy detector (OC3 mat)

1. Connect BMW diagnosis system
2. Release seat occupancy detector
3. Clear fault memory if necessary

Remove sensor mat (1).

Seat with air conditioning

Remove dividing net (2).

Remove fan (3) from support (4).

Scheme 119

Installation

Make sure fans have correct cable routing (1).

Scheme 120

52 17 420 Replacing Padding For Left Or Right Front Seat Backrest (Comfort)

Necessary preliminary tasks

1. Remove backrest cover. See «52 17 405 Replacing Backrest Cover For Left Or Right Front Seat (Comfort)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-405-replacing-backrest-cover) .

Remove dividing net (1) towards top.

Scheme 121

Remove fan (1) towards top.

Installation

Make sure fans have correct cable routing (2) (cables point to each other).

Scheme 122

52 26 .. Overview of Microswitches

1. LOCK microswitches, inner, on seat frame on left and right. See «52 26 .. Removing and Installing/Replacing Left Or Right LOCK Microswitch»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing) .
2. FOLD microswitch on backrest frame, outer. See «52 26 .. Removing and Installing/Replacing FOLD Microswitch»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing) .
3. CF microswitch on seat frame, outer. See «52 26 .. Removing and installing/replacing CF microswitch»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing) .

52 26 .. Overview of Trims, Rear Seat

1. Seatbelt outlet trim. See «52 26 .. Removing and Installing Belt Outlet Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing)
2. Trim, CF release unit. See «52 26 .. Removing and Installing Release Unit Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
3. Trim, fold, inner. See «52 26 .. Removing and Installing Inner Fold Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
4. Trim, seat screw fastening. See «52 26 .. Removing and Installing Seat Screw Fastening Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
5. Trim, follower, outer. See «52 26 .. Removing and Installing Inner Follower Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
6. Trim, fold, outer. See «52 26 .. Removing and Installing Outer Fold Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
7. Trim, fold adapter, outer.
8. Trim, cross-member. See «52 26 .. Removing and Installing Cross-Member Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
9. Trim, seat screw fastening. See «52 26 .. Removing and Installing Seat Screw Fastening Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
10. Trim, fold adapter, middle (60 %) Trim, pivot bearing lower section (40 %). See «52 26 .. Removing and Installing Middle Slide Trim (60 % Rear Seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) , «52 26 .. Removing and Installing Pivot Bearing Lower Section Trim (40 % Rear Seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
11. Trim, follower, inner. See «52 26 .. Removing and Installing Inner Follower Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
12. Trim, slide, middle. See «52 26 .. Removing and Installing Middle Slide Trim (40 % Rear Seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
13. Trim, fold, middle (60 %) Trim, pivot bearing (40 %). See «52 26 .. Removing and Installing Middle Fold Trim (60 % Rear Seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) or «52 26 .. Removing and Installing Pivot Bearing Trim (40 % rear seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
14. Trim, slide, outer. See «52 26 .. Removing and Installing Outer Slide Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .

52 26 .. Checks on Rear Seat (Through-Loading)

The rear seats must be checked for damage following an accident. This measure is applicable above all in the event of structural damage (engine carriers, luggage compartment floor side members) but also if large pieces of luggage were stowed in the luggage compartment. The most important checks are set out below.

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

1. Rear seat frame: Check complete frame for damage (cracking, breakage, etc.), paying particular attention to the marked areas.
2. ISOFIX cover strip Check marked areas for damage (cracking, breakage, etc.).
3. Side section: Check side section for tight seating if it is loosely seated: Check retaining lugs and snap-in fixtures for damage (wear, breakage, cracking, etc.), replace if necessary. Check marked guide lugs for damage (cracking, breakage, etc.). Also check corresponding counter-supports on body (bending open, etc.).
4. Rear seat backrest: Carry out function check (easy folding and snapping into place). Check center mount for damage (cracking, breakage, bending, bending open, etc.). If damage is identified at one of the following points, the center mount must also be replaced. Check backrest mount (oval head screw, bushing) for damage (cracking, breakage, bending, etc.), replace if necessary. Check mounting bracket for damage (breakage, cracking, bending, etc.). Check backrest head for parallelism to rear parcel shelf. Check whether there is deformation at backrest head and backrest moulding. Check mount of center armrest for damage (breakage, cracking, bending, etc.). Check gap for parallelism and uniform distance. Check mount of backrest lock for damage (breakage, cracking, bending, etc.). If damage is identified at the backrest supporting points, the mounting points on the body must also be checked (bending open, function, etc.).
5. Center armrest: Carry out function check (easy folding and snapping into place). Check armrest shafts for damage (cracking, breakage, etc.). Check armrest vertically and diagonally for deformation. Check folding cover for exact operation. Check armrest buckle for damage (cracking, breakage, bending etc.). If the backrest structure is damaged, the center armrest must also be replaced.
6. Ski bag: Carry out function check (easy snapping into place). Check marked areas for damage (cracking, breakage, etc.).
7. Head restraints: Check head restraint cushion for distortion. If the cushion is loose in relation to the tubes, replace head restraint. Check tubes for damage and parallelism to each other. Check guides on backrest. Carry out function check on new rear seat or reference vehicle.

52 26 .. Removing and Installing Backrest Lock Adapter Plate

Necessary preliminary tasks

1. Remove luggage compartment wheel arch trim on left or right. See «51 47 151 REMOVING AND INSTALLING/REPLACING LEFT LUGGAGE COMPARTMENT WHEEL ARCH TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-151-removing-and-installingreplacing)

Release screw.

Tightening torque 52 26 06AZ. . See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM)

Remove adapter plate for backrest lock (1).

Scheme 131

Version with 3rd seat row

Unfasten screws.

Tightening torque 52 26 06AZ. . See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM)

Remove adapter plate for backrest lock (1).

Scheme 132

52 26 .. Removing and Installing Belt Outlet Trim

Release screws (1).

Feed out trim (2) for strap outlet.

52 26 .. Removing and Installing Cross-Member Trim

Release screws (1).

Remove trim (2) towards front.

52 26 .. Removing and Installing Inner Fold Trim

Necessary preliminary tasks

1. Remove backrest cover
2. Remove outer slide trim

Trim, fold, inner

Release screws (1).

Unclip trim (2) in direction of arrow.

Unclip Bowden cable from trim.

52 26 .. Removing and Installing Inner Follower Trim

Necessary preliminary tasks

1. Partially detach seat cover

Trim, fold, inner

Release screw.

Unclip trim (1) in direction of arrow and remove.

52 26 .. Removing and Installing Left Or Right Rear Panel Trim

Pull out pins and lever out expander rivets.

Remove rear panel trim (1).

52 26 .. Removing and Installing Longitudinal Seat Adjustment Handle

Disengage spring in marked area.

Release screws (1).

Remove handle upper section (2) with handle lower section.

52 26 .. Removing and Installing Middle Fold Adapter Trim

Necessary preliminary tasks

1. Remover middle fold trim. See «52 26 .. Removing and Installing Middle Fold Trim (60 % Rear Seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
2. Remove rear panel trim. See «52 26 .. Removing and Installing Left Or Right Rear Panel Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
3. Partially remove seat cover. See «52 26 400 REPLACING SEAT COVER FOR LEFT & Right Rear»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-400-replacing-seat-cover) .

Release screw (1).

Release screw (1).

Unclip trim in marked area.

Release screw (1).

Feed trim (2) in upward direction out of seat mechanism.

52 26 .. Removing and Installing Middle Fold Trim (60 % Rear Seat)

Necessary preliminary tasks

1. Remove middle slide trim at top only. See «52 26 .. Removing and Installing Middle Slide Trim (40 % Rear Seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) or «52 26 .. Removing and Installing Middle Slide Trim (60 % Rear Seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
2. trim for center armrest. See «52 26 .. Removing and Installing/Replacing Trim For Centre Armrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing) .
3. Remove inner follower trim. See «52 26 .. Removing and Installing Inner Follower Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .

Release screw (1).

Release screw (1).

Tightening torque: 52 26 27AZ. See BODY EQUIPMENT - TIGHTENING TORQUES .

Release screw (2).

Carefully tighten follower (2) on seat cushion frame.

Remove trim (1) in direction of arrow and feed out of seat mechanism.

52 26 .. Removing and Installing Middle Slide Trim (40 % Rear Seat)

Necessary preliminary tasks

1. Partially remove backrest cover

Carefully unclip trim (1) at bottom and top.

52 26 .. Removing and Installing Middle Slide Trim (60 % Rear Seat)

Note. Picture shows seat and backrest covers removed for purposes of clarity.

Trim, slide, middle

Carefully unclip trim (1) at bottom and top.

52 26 .. Removing and Installing Outer Fold Adapter

Necessary preliminary tasks

1. Remove outer fold trim. See «52 26 .. Removing and Installing Outer Fold Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
2. Remove rear panel trim. See «52 26 .. Removing and Installing Left Or Right Rear Panel Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
3. Partially remove seat cover with padding. See «52 26 400 REPLACING SEAT COVER FOR LEFT & Right Rear»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-400-replacing-seat-cover) .

Release screw.

Release screw (1).

Unclip trim (2) at top.

Carefully tighten follower (2) on seat cushion frame.

Feed trim (2) out of seat mechanism.

52 26 .. Removing and Installing Outer Fold Trim

Necessary preliminary tasks

1. Remover inner fold trim. See «52 26 .. Removing and Installing Inner Fold Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
2. Remove outer follower trim. See «52 26 .. Removing and Installing Outer Follower Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .

Trim, fold, inner

Release screw (2).

Tightening torque: 52 26 25AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM) .

Pull off release handle (1).

Release screw.

Only for seat backrest frame, left (60 %)

Push on locking clip (1).

Pull off ball socket.

Installation

Gas-filled strut (1) is under tension.

Lever ball socket with screwdriver on pin.

Release screw (1).

Tightening torque: 52 26 27AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM) .

Carefully tighten follower (2) on seat cushion frame.

Feed trim (1) out of seat mechanism.

52 26 .. Removing and Installing Outer Follower Trim

Necessary preliminary tasks

1. Partially disengage seat cover. See «52 26 400 REPLACING SEAT COVER FOR LEFT & Right Rear»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-400-replacing-seat-cover) .

Trim, follower, outer

Release screw.

Unclip trim (1) in direction of arrow and remove.

52 26 .. Removing and Installing Outer Slide Trim

Necessary preliminary tasks

1. Remove backrest cover. See «52 26 411 Replacing Backrest Cover For Left Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-411-replacing-backrest-cover) or «52 26 412 Replacing Backrest Cover For Right Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-412-replacing-backrest-cover) .

Trim, slide

Carefully unclip trim (1) at top and bottom.

52 26 .. Removing and Installing Pivot Bearing Lower Section Trim (40 % Rear Seat)

Necessary preliminary tasks

1. Remove pivot bearing trim. See «52 26 .. Removing and Installing Pivot Bearing Trim (40 % rear seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
2. Partially remove seat cover. See «52 26 400 Replacing Seat Cover For Left & Right Rear»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-400-replacing-seat-cover) .

Release screw (1).

Release screw (1).

Disengage trim (2) in marked area.

Feed trim (2) out of seat mechanism.

52 26 .. Removing and Installing Pivot Bearing Trim (40 % rear seat)

Necessary preliminary tasks

1. Remove middle slide trim at top only. See «52 26 .. Removing and Installing Middle Slide Trim (40 % Rear Seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) or «52 26 .. Removing and Installing Middle Slide Trim (60 % Rear Seat)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
2. Remove inner follower trim. See «52 26 .. Removing and Installing Outer Follower Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .
3. Partially remove backrest cover. See «52 26 412 Replacing Backrest Cover For Right Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-412-replacing-backrest-cover) .

Release screw (1).

Release screw (1).

Tightening torque: 52 26 27AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM)

Unclip trim (2) in marked area.

Carefully tighten follower (3) on seat cushion frame.

Feed trim (2) out of seat mechanism.

52 26 .. Removing and Installing Release Unit Trim

Access to screw (1) behind release lever.

Release screw (1).

Unclip trim towards top.

Installation

Retaining lugs must not be damaged.

If necessary, replace trim.

52 26 .. Removing and Installing Seat Screw Fastening Trim

Unclip trim (1) on left and right in direction of arrow.

Installation

Replace faulty cover.

Release screw (1).

Remove trim (2) in direction of arrow.

52 26 .. Removing and Installing/Replacing Bowden Cable For Left Or Right Seat Back Release

Necessary preliminary tasks

1. Remove backrest cover. See «52 26 411 Replacing Backrest Cover For Left Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-411-replacing-backrest-cover) or «52 26 412 Replacing Backrest Cover For Right Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-412-replacing-backrest-cover) .
2. Remove release unit. See «52 26 .. Removing and Installing Release Unit Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .

Unclip Bowden cable sleeve.

Unclip Bowden cable sleeve from backrest frame.

Disengage Bowden cable nipple.

52 26 .. Removing and Installing/Replacing CF Microswitch

Necessary preliminary tasks

1. Remove left rear seat. See «52 26 000 Removing and Installing/Replacing Left Or Right Rear Seat (For 3Rd Seat Row)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-000-removing-and-installingreplacing) .

Unfasten plug connection (1) and disconnect.

Unlock microswitch (1) with screwdriver (2) and remove towards top.

52 26 .. Removing and Installing/Replacing FOLD Microswitch

Necessary preliminary tasks

1. Remove backrest cover. See «52 26 411 Replacing Backrest Cover For Left Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-411-replacing-backrest-cover) or «52 26 412 Replacing Backrest Cover For Right Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-412-replacing-backrest-cover) .
2. Remove trims from backrest frame, outer. See «52 26 .. Removing and Installing Outer Follower Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing) .

Unclip microswitch (1) from seat backrest frame.

Installation

Make sure contact sensor (2) is fitted correctly on pin (1).

Unfasten plug connection (1) and disconnect.

52 26 .. Removing and Installing/Replacing Gas-Filled Strut On Left Rear Seat

Slide retaining clips (1) upwards.

Detach ball sockets at sides.

Installation

Gas-filled strut (1) is under tension.

Lever ball socket with screwdriver on pin.

52 26 .. Removing and Installing/Replacing Left Or Right Easy Entry Bowden Cable

Necessary preliminary tasks

1. Remove backrest cover. See «52 26 411 Replacing Backrest Cover For Left Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-411-replacing-backrest-cover) or «52 26 412 Replacing Backrest Cover For Right Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-412-replacing-backrest-cover) .
2. Removing seat fabric. See «52 26 400 Replacing Seat Cover For Left & Right Rear»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-400-replacing-seat-cover) .

Unclip Bowden cable sleeve.

Feed Bowden cable nipple out of actuating mechanism.

Unclip Bowden cable sleeve.

Feed Bowden cable nipple out of release unit.

Cut open cable tie (1).

Installation

If necessary, replace faulty cable ties (1).

Unclip Bowden cable from metal retainer.

Feed Bowden cable out of seat backrest frame.

52 26 .. Removing and Installing/Replacing Left Or Right Easy Entry Damper

Necessary preliminary tasks

1. Remove left or right rear seat. See «52 26 000 Removing and Installing/Replacing Left Or Right Rear Seat (For 3Rd Seat Row)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-000-removing-and-installingreplacing) .

Remove toothed lock washers (1).

Installation

Replace defective toothed lock washer.

Remove damper (2).

52 26 .. Removing and Installing/Replacing Left Or Right LOCK Microswitch

Necessary preliminary tasks

1. Remove left or right rear seat. See «52 26 000 Removing and Installing/Replacing Left Or Right Rear Seat (For 3Rd Seat Row)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-000-removing-and-installingreplacing) .

Unclip left or right microswitch (1) from seat backrest frame.

Unfasten plug connection (1) and disconnect.

52 26 .. Removing and Installing/Replacing Rear Head Restraint Locator

Necessary preliminary tasks

1. Remove head restraint. See «52 26 388 Removing and Installing/Replacing Rear Middle Head Restraint»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-388-removing-and-installingreplacing) or «52 26 390 Removing and Installing Or Replacing Left Or Right Rear Head Restraint»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-390-removing-and-installing) .

Press backrest cover with padding next to guide downwards to expose detent lugs

Unlock detent lugs on left and right with screwdriver and remove guide towards top.

52 26 .. Removing and Installing/Replacing Rear Left Or Right Head Restraint Mount (Through-Loading)

Necessary preliminary tasks

1. Remove head restraint. See «52 26 388 Removing and Installing/Replacing Rear Middle Head Restraint»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-388-removing-and-installingreplacing) or «52 26 390 Removing and Installing Or Replacing Left Or Right Rear Head Restraint»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-390-removing-and-installing) .

Press backrest cover with padding next to guide downwards to expose detent lugs

Unlock detent lugs on left and right with screwdriver and remove guide towards top.

52 26 .. Removing and Installing/Replacing Rear Left Seat Backrest Frame

Necessary preliminary tasks

1. Remove all microswitches. See «52 26 .. Removing and Installing/Replacing CF Microswitch»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing) , «52 26 .. Removing and Installing/Replacing FOLD Microswitch»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing) or «52 26 .. Removing and Installing/Replacing Left Or Right LOCK Microswitch»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing) .
2. Remove all rear seat trims. See «52 26 .. Overview of Trims, Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-overview-of-trims) .
3. Remove backrest cover. See «52 26 411 Replacing Backrest Cover For Left Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-411-replacing-backrest-cover) .
4. Remove rear panel . See «52 26 199 Removing and Installing/Replacing Rear Panel On Left Rear Seat Back»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-199-removing-and-installingreplacing) .
5. Remove release unit. See «52 26 301 Removing and Installing/Replacing Release Unit For Left Or Right Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-301-removing-and-installingreplacing) .
6. Remove Bowden cables. See «52 26 .. Removing and Installing/Replacing Bowden Cable For Left Or Right Seat Back Release»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing) .
7. Remove Easy Entry damper. See «52 26 .. Removing and Installing/Replacing Left Or Right Easy Entry Damper»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing) .

52 26 .. Removing and Installing/Replacing Ski Bag On Rear Seat (Through-Loading System)

Special tools required

1. 00 9 317. See «00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE)»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-special-tools__00-9-310-assembly-wedges-set) .

Necessary preliminary tasks

1. Remove armrest. See «52 26 030 Removing and installing/replacing armrest for rear seat backrest (through-loading system)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-030-removing-and-installingreplacing) .

Release screws (1).

Tightening torque 52 26 09AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM) .

Scheme 133

Release screws (1).

Tightening torque 52 26 09AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM) .

Release screw (2).

Tightening torque 52 26 08AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM) .

Remove Top Tether eyelet.

Scheme 134

Lever out rear ski bag frame (1) with special tool 00 9 317. See 00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE)

Scheme 135

Lever out pins.

Remove front ski bag trim (1) in direction of arrow.

Scheme 136

52 26 .. Removing and Installing/Replacing Trim And Frame For Ski Bag

Special tools required

1. 00 9 317. See «00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE)»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-special-tools__00-9-310-assembly-wedges-set) .

Release screws (1).

Tightening torque 52 26 23AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM) .

Lever out caps (1).

Release screws underneath.

Tightening torque 52 26 23AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM) .

Release screw (1).

Tightening torque 52 26 21AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM) .

Remove Top Tether eyelet.

Lever out frame (1) for ski bag with special tool 00 9 317. See 00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE) .

Remove front ski bag trim (1) in direction of arrow.

52 26 .. Removing and Installing/Replacing Trim For Centre Armrest

Carefully unclip channel cover strip (1).

Installation

Risk of damage! Plastic eyelets of front trim can break.

If necessary, replace defective trim or channel cover.

Unclip trim for center armrest.

Installation

If necessary, replace faulty clips.

52 26 .. Replacing Cover On Backrest Side Section

Necessary preliminary tasks

1. Remove rest side section. See «52 26 008 Removing and installing/replacing left/right sides of backrest on rear seat backrest (through-loading)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-008-removing-and-installingreplacing) .

Disengage cover in marked area from rest side section.

Scheme 137

52 26 000 Removing and Installing/Replacing Left Or Right Rear Seat (For 3Rd Seat Row)

Right rear seat is removed in the same way as the left rear seat depicted here.

Unclip cover (1) on left and right and remove in direction of arrow.

Installation

Replace faulty cover.

Release screws (1) on left and right.

Tightening torque 52 26 10AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM)

Release screw (1).

Remove cover (2) in direction of arrow.

Fold rear seat backwards forwards.

Release screws (1).

Tightening torque 52 26 10AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM)

Unlock plug connection (1) and disconnect.

Slide rear seat forwards (guide pin out of guide).

Lift rear seat with a 2nd person helping out of vehicle.

52 26 005 Removing and Installing / Replacing Rear Seat

Unclip rear seat on left and right towards top.

Installation

Feed seat belt buckles (1) into openings in rear seat.

Scheme 138

Release screw (1) on seat belt (middle).

Tightening torque 72 11 22AZ. See 72 11 SEAT BELTS

Installation

Seat belt is coded against incorrect installation.

Feed out anchor fitting (2) through rear seat.

If necessary, unlock and disconnect plug connection for seat heating.

Lift out rear seat.

Scheme 139

52 26 008 Removing and Installing/Replacing Left/Right Sides Of Backrest On Rear Seat Backrest (Through-Loading)

Pull seat belt to middle and place behind head restraint.

Unclip backrest side section in direction of arrow (1) towards front and pull out in direction of arrow (2).

Scheme 140

If necessary, pull out clip (1) towards front.

Scheme 141

Check clip (1) and locator (2) for damage.

Snap clip (1) into locator (2) of backrest side section.

Scheme 142

Insert guides (1) into locators.

Clip backrest side section at top into place.

Installation

Make sure backrest side section is correctly seated in locators.

Scheme 143

52 26 015 Removing and Installing/Replacing Left/Right Rear Seat Backrest (Throughloading)

Necessary preliminary tasks

1. Remove backrest side section. See «52 26 008 Removing and Installing/Replacing Left/Right Sides Of Backrest On Rear Seat Backrest (Through-Loading)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-008-removing-and-installingreplacing)
2. If necessary, remove rear seat (only with seat heating optional extra)

Left backrest

Scheme 144

1. Release screw (1). Tightening torque 52 26 04AZ. See «52 26 REAR SEATS (THROUGH-LOADING SYSTEM)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-tightening-torques)
2. With automatic center belt optional extra only: Lay belt (2) around center armrest
3. Fold backrest forwards slightly (3)
4. Pull backrest forwards and outwards out of center mount (4)

Right backrest

Scheme 145

1. Release screw (1). Tightening torque 52 26 04AZ. See «52 26 REAR SEATS (THROUGH-LOADING SYSTEM)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-tightening-torques)
2. Fold backrest forwards slightly (2)
3. Pull backrest forwards and outwards out of center mount (3)

52 26 030 Removing and Installing/Replacing Armrest For Rear Seat Backrest (Through-Loading System)

Release screw (1).

Tightening torque 52 26 03AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM)

Twist out armrest in direction of arrow from backrest frame.

Scheme 146

52 26 032 Removing and Installing/Replacing Cup Holders In Centre Armrest

Unclip trim (1) with plastic wedge.

Installation

Replace trim (1) if retaining lugs are faulty.

Lever cup holders on left and right out of center armrest with plastic wedge.

Remove cup holders from center armrest.

52 26 080 Removing and Installing/Replacing Backrest Frame For Left Rear Seat (Through - Loading System)

Necessary preliminary tasks

1. Remove backrest cover. See «52 26 411 Replacing backrest cover for rear seat (through-loading system) on left»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-411-replacing-backrest-cover)
2. Remove retractor mechanism. See «72 11 101 REMOVING AND INSTALLING/REPLACING REAR CENTER SEAT BELT»(/bmw/x5/e70-2006-2010/remont/airbag/#parts-and-accessories-repair__72-11-101-removing-and-installingreplacing)
3. Remove lock. See «52 26 311 Removing and installing/replacing lock for left or right rear seat backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-311-removing-and-installingreplacing)

Release screws (1).

Installation

Replace screws and insert with Loctite.

Tightening torque 52 26 07AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM)

Remove lock for center armrest.

Scheme 147

52 26 085 Removing and Installing/Replacing Backrest Frame For Right Rear Seat (Through-Loading System)

Necessary preliminary tasks

1. Remove backrest cover. See «52 26 412 Replacing backrest cover for rear seat (through-loading system) on right»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-412-replacing-backrest-cover)
2. Removing lock for rear seat backrest. See «52 26 311 Removing and installing/replacing lock for left or right rear seat backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-311-removing-and-installingreplacing)

52 26 199 Removing and Installing/Replacing Rear Panel On Left Rear Seat Back

Necessary preliminary tasks

1. Remove rear seat back. See «52 26 015 Removing and Installing/Replacing Left/Right Rear Seat Backrest (Throughloading)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-015-removing-and-installingreplacing)
2. If necessary, remove rear frame for ski bag. See «52 26 .. Removing and Installing/Replacing Ski Bag On Rear Seat (Through-Loading System)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing)

Unclip lock trim on backrest edge in direction of arrow (1).

Slide back of lock trim in outward direction and remove in direction of arrow (2).

Installation

Retaining lugs on trim must not be damaged.

Version without ski bag

Lever backrest cover all round out of backrest frame.

Version with ski bag

Lever backrest cover all round out of backrest frame.

Detach rear panel (2) with flat scraper (1) from rear seat back.

Installation

Comply with instructions issued by manufacturer of universal spray adhesive.

Apply universal spray adhesive to rear panel and rear seat back.

Fit and align rear panel within the air drying time (See manufacturer's instructions).

Observe and adhere to curing time to prevent rear panels from slipping.

52 26 200 Removing and Installing/Replacing Rear Panel On Right Rear Seat Back

Necessary preliminary tasks

1. Remove rear seat back. See «52 26 015 Removing and Installing/Replacing Left/Right Rear Seat Backrest (Throughloading)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-015-removing-and-installingreplacing)

Unclip lock trim on backrest edge in direction of arrow (1).

Slide back of lock trim in outward direction and remove in direction of arrow (2).

Installation

Retaining lugs on trim must not be damaged.

Lever backrest cover all round out of backrest frame.

Detach rear panel (2) with flat scraper (1) from rear seat back.

Installation

Comply with instructions issued by manufacturer of universal spray adhesive.

Apply universal spray adhesive to rear panel and rear seat back.

Fit and align rear panel within the air drying time (See manufacturer's instructions).

Observe and adhere to curing time to prevent rear panels from slipping.

52 26 301 Removing and Installing/Replacing Release Unit For Left Or Right Backrest

Necessary preliminary tasks

1. Remove trim for release unit. See «52 26 .. Removing and Installing Release Unit Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing)

Release screw (1).

Remove release unit (1) in direction of arrow.

Disengage Bowden cable from release unit.

52 26 311 Removing and Installing/Replacing Lock For Left Or Right Rear Seat Backrest

Unclip lock trim on backrest edge in direction of arrow (1).

Slide back of lock trim in outward direction and remove in direction of arrow (2).

Scheme 148

Installation

Retaining lugs on trim must not be damaged.

Scheme 149

Insert plastic wedge from outside between trim (1) and lock.

Carefully lever outer side of trim (1) with plastic wedge upwards out of catch.

Lever inner side of trim (1) with plastic wedge out of catch.

Remove trim upwards.

Scheme 150

Lever out backrest cover (1) in working area.

Scheme 151

Release screws and feed lock (1) out of rear seat backrest.

Tightening torque 52 26 05AZ. See 52 26 REAR SEATS (THROUGH-LOADING SYSTEM)

Scheme 152

52 26 388 Removing and Installing/Replacing Rear Middle Head Restraint

Press lock (2) and move head restraint upwards to maximum extent.

Pull out head restraint (1) firmly.

Scheme 153

52 26 390 Removing and Installing Or Replacing Left Or Right Rear Head Restraint

Press lock (2) and move head restraint upwards to maximum extent.

Pull out head restraint (1) firmly.

52 26 400 Replacing Seat Cover For Left & Right Rear

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

1. Remove rear seat. See «52 26 000 Removing and Installing/Replacing Left Or Right Rear Seat (For 3Rd Seat Row)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-000-removing-and-installingreplacing)
2. Remove rear panel trim. See «52 26 .. Removing and Installing Left Or Right Rear Panel Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing)

Disengage welt in marked area from seat mechanism.

Disengage welt in marked area from seat mechanism.

Installation

Make sure metal lugs in welt are correctly engaged.

Version with seat heating only

Unfasten plug connection and disconnect.

Release retainers in marked area.

Note. Remove all remnants of clips from cover and support.

Installation

Insert new retainer (2) with special tool 52 0 050 and bend closed. See 52 0 050 PLIERS

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim wire in seat cover
5. Seat cover

Replacing seat cover

Pull trim threads out of seat cover.

Cut new seat cover to size and insert trim wires.

52 26 400 Replacing Seat Cover For Rear Seat (Through-Loading System)

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

1. Remove rear seat

Open tension cable (1).

Remove tension cable from wire eyelets (2).

Scheme 154

Disconnect retainers in marked area

Remove all remnants of clips from cover and support.

Scheme 155

Installation

Insert new retainer (2) with special tool 52 0 050 and bend closed. See 52 0 050 PLIERS

Scheme 156

1. Padding
2. Retainer
3. Trim thread in padding
4. Trim thread in seat cover
5. Seat cover

52 26 411 Replacing Backrest Cover For Left Rear Seat

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

1. Remove rear seat. See «52 26 000 Removing and Installing/Replacing Left Or Right Rear Seat (For 3Rd Seat Row)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-000-removing-and-installingreplacing)
2. Remove rear panel trim. See «52 26 .. Removing and Installing Left Or Right Rear Panel Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing)

Disengage welt in marked area from seat mechanism.

Remove rear panel trim (1).

Installation

Make sure metal lugs in welt are correctly engaged.

Scheme 157

Version with seat heating only

Unfasten plug connection and disconnect.

Release all retainers in marked area.

Scheme 158

Note. Remove all remnants of clips from cover and support.

Installation

Insert new retainer (2) with special tool 52 0 050 and bend closed. See 52 0 050 PLIERS

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim wire in seat cover
5. Seat cover

Replacing seat cover

1. Pull trim threads out of seat cover.
2. Cut new seat cover to size and insert trim wires.

Scheme 159

52 26 411 Replacing Backrest Cover For Rear Seat (Through-Loading System) On Left

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

1. Remove left backrest cover. See «52 26 015 Removing and Installing/Replacing Left/Right Rear Seat Backrest (Throughloading)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-015-removing-and-installingreplacing)
2. Remove head restraint locators. See «52 26 .. Removing and Installing/Replacing Rear Left Or Right Head Restraint Mount (Through-Loading)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing)
3. Remove ski bag. See «52 26 .. Removing and Installing/Replacing Ski Bag On Rear Seat (Through-Loading System)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing)
4. Remove backrest actuator trim and lock trim. See «52 26 311 Removing and Installing/Replacing Lock For Left Or Right Rear Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-311-removing-and-installingreplacing)

Release screws (1).

Feed trim (2) out of seat belt outlet.

Scheme 160

Lever out cover welt in marked area (1).

Lever trim wire (2) out of metal clasps (3).

Scheme 161

Lever out welt in marked area (1) from rear panel.

Lever out welt in marked area of rear panel.

Remove backrest cover with padding.

Detaching cover and padding

1. Release all retainers in marked area.
2. Remove cover from padding
3. Remove remaining retainers from cover and padding

Installation

Insert new retainer (2) with special tool 52 0 050 and bend closed. See 52 0 050 PLIERS

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim wire in seat cover
5. Back-rest cover

Replacing cover

1. Pull all trim wires out of cover
2. If necessary, cut pockets in new cover for trim wires
3. Push trim wires into cover pockets

52 26 412 Replacing Backrest Cover For Rear Seat (Through-Loading System) On Right

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

1. Remove right backrest cover. See «52 26 015 Removing and Installing/Replacing Left/Right Rear Seat Backrest (Throughloading)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-015-removing-and-installingreplacing)
2. Remove head restraint guides. See «52 26 .. Removing and Installing/Replacing Rear Left Or Right Head Restraint Mount (Through-Loading)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing)
3. Remove backrest actuator trim and lock trim. See «52 26 311 Removing and Installing/Replacing Lock For Left Or Right Rear Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-311-removing-and-installingreplacing)

Lever out welt in marked area.

Scheme 162

Detaching cover and padding

Scheme 163

1. Release all retainers in marked area
2. Remove cover from padding
3. Remove remaining retainers from cover and padding

Installation

Insert new retainer (2) with special tool 52 0 050 and bend closed. See 52 0 050 PLIERS

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim wire in seat cover
5. Back-rest cover

Replacing cover

Scheme 164

1. Pull all trim wires out of cover
2. If necessary, cut pockets in new cover for trim wires
3. Push trim wires into cover pockets

52 26 412 Replacing Backrest Cover For Right Rear Seat

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

1. Remove right rear seat. See «52 26 085 Removing and Installing/Replacing Backrest Frame For Right Rear Seat (Through-Loading System)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-085-removing-and-installingreplacing)
2. Remove head restraint locators. See «52 26 .. Removing and Installing/Replacing Rear Head Restraint Locator»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installingreplacing)
3. Remove trim for rear seat back actuator. See «52 26 .. Removing and Installing Release Unit Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing)
4. Remove rear panel trim. See «52 26 .. Removing and Installing Left Or Right Rear Panel Trim»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-removing-and-installing)

Lever welt in marked area (1) out of backrest frame.

Remove backrest cover with padding.

Detaching cover and padding

1. Release all retainers in marked area
2. Remove cover from padding
3. Remove remaining retainers from cover and padding

Installation

Insert new retainer (2) with special tool 52 0 050 and bend closed. See 52 0 050 PLIERS

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim wire in seat cover
5. Backrest cover

Replacing cover

1. Pull all trim wires out of cover
2. If necessary, cut pockets in new cover for trim wires
3. Push trim wires into cover pockets

52 26 450 Replacing Padding For Rear Seat (Through - Loading System)

Operation is identical to

Replacing seat cover for rear seat. See 52 26 400 Replacing Seat Cover For Rear Seat (Through-Loading System) .

52 30 .. Removing and Installing All Ventilation Grilles On Centre Console

Version with rear cabin fan only

Unclip ventilation grille (1).

Unclip operating unit (1).

Unclip lever (1) from operating unit.

Unclip air outlet grille (1) on left and right with plastic wedge.

52 30 .. Removing and Installing Middle Trim For 3rd Seat Row

Necessary preliminary tasks

1. Remove center console. See «52 30 010 Removing and Installing/Replacing Centre Console For 3Rd Seat Row»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-010-removing-and-installingreplacing)

Release screws (1).

Remove trim from assembly frame.

Installation

Make sure guides are correctly seated in assembly frame.

52 30 .. Removing and Installing Outer Trim For 3rd Seat Row

Necessary preliminary tasks

1. Remove lashing rail in luggage compartment floor. See «51 47 135 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT LASHING RAIL IN LUGGAGE COMPARTMENT FLOOR»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-135-removing-and-installingreplacing) Unclip trim (1) and remove from assembly frame.

52 30 .. Removing and Installing/Replacing Rear Left Or Right Head Restraint Guide

Necessary preliminary tasks

1. Remove head restraint. See «52 30 390 Removing and Installing Or Replacing Left Or Right Rear Head Restraint»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-390-removing-and-installing)

Press backrest cover with padding next to guide downwards to expose detent lugs.

Unlock detent lugs on left and right with screwdriver and remove guide towards top.

52 30 .. Replacing Assembly Frame For 3rd Seat Row

Necessary preliminary tasks

1. Remove gap cover. See «52 30 020 Removing and Installing Gap Cover For Floor Panel On Left Or Right»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-020-removing-and-installing)
2. Remove seat backrest frame on left and right. See «52 30 080 Removing and Installing/Replacing Left Seat Backrest Frame»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-080-removing-and-installingreplacing) or «52 30 085 Removing and Installing/Replacing Right Seat Backrest Frame»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-085-removing-and-installingreplacing) .
3. Remove center lower strap fitting.
4. Remove belt lock on left and right
5. If necessary, remove rear cabin fan
6. Remove control units for seat heating

Overview of assembly frame

52 30 000 Removing and Installing Complete 3rd Seat Row

Necessary preliminary tasks

1. Remove lashing rail in luggage compartment floor. See «51 47 135 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT LASHING RAIL IN LUGGAGE COMPARTMENT FLOOR»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-135-removing-and-installingreplacing)
2. Remove panel for luggage compartment at bottom. See «51 47 .. REMOVING AND INSTALLING/REPLACING BOTTOM LEFT OR RIGHT TRIM PANEL FOR LUGGAGE COMPARTMENT (WITH 3RD SEAT ROW)»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-removing-and-installingreplacing)

Unclip cover (1) on left and right and remove in direction of arrow.

Installation

Replace faulty cover.

Release screws (1).

Tightening torque 52 30 01AZ. See 52 30 3RD SEAT ROW

Access to front screw (2) concealed by trim (1).

Unclip trim (1) towards top.

Release screws (2) and (3).

Tightening torque 52 30 01AZ. . See 52 30 3RD SEAT ROW

Fold rear seat backwards forwards.

Release screws (1).

Tightening torque 52 30 01AZ. See 52 30 3RD SEAT ROW

Unlock plug connection (1) and disconnect. See 72 12 .. UNLOCKING/LOCKING AIRBAG PLUG CONNECTIONS

Unlock plug connection (1) and disconnect. Important! Risk of damage! Cover sill and entrance area with protective covers. Lift rear seat with a 2nd person helping out of vehicle.

52 30 010 Removing and Installing/Replacing Centre Console For 3rd Seat Row

Release screws (1).

Remove center console (1) towards top.

Installation

Feed center console (1) with guides into trim (2).

Version with rear cabin fan only

Unclip ventilation grille (1).

Unclip operating unit (1).

Set down operating unit (1) in downward direction in center console.

Lift center console (1) on left and right over air outlet. Remove center console (1) towards top.

Installation

Feed center console (1) with guides into trim (2).

52 30 020 Removing and Installing Gap Cover For Floor Panel On Left Or Right

Necessary preliminary tasks

1. Remove luggage compartment floor panel

Release screws (1).

Remove gap cover (2).

52 30 030 Removing and Installing Front Trim For 3rd Seat Row On Left Or Right

Release screws (1).

Remove trim (2).

52 30 080 Removing and Installing/Replacing Left Seat Backrest Frame

Necessary preliminary tasks

1. Remove 3rd seat row. See «52 30 000 Removing and Installing Complete 3Rd Seat Row»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-000-removing-and-installing) .
2. Remove backrest cover. See «52 30 413 Removing and installing/replacing backrest cover for left or right rear seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-413-removing-and-installingreplacing) .
3. Removing actuating mechanism for rear seat backrest. See «52 30 303 Removing and Installing/Replacing Actuating Mechanism For Rear Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-303-removing-and-installingreplacing) .
4. Remove outer trim. See «52 30 .. Removing and Installing Outer Trim For 3Rd Seat Row»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-removing-and-installing) .

Detach Starlock washer (1) from shaft.

Remove shaft.

Installation

Detach Starlock washer (1) from shaft. Remove shaft. Installation: Fit left and right plastic sleeves on shaft.

Release fitting screws (1).

Tightening torque: 52 30 02AZ. . See 52 30 3RD SEAT ROW

Release outer bearing screw (1).

Tightening torque: 52 30 03AZ. See 52 30 3RD SEAT ROW

Remove seat backrest frame (2) from assembly frame.

Replacement only

1. Removing seat fabric. See «52 30 405 Removing and Installing/Replacing Seat Cover For Left Or Right Rear Seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-405-removing-and-installingreplacing) .

52 30 085 Removing and Installing/Replacing Right Seat Backrest Frame

Operation is identical to

1. Removing right seat backrest frame. See «52 26 412 Replacing Backrest Cover For Rear Seat (Through-Loading System) On Right»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-412-replacing-backrest-cover) .

52 30 201 Removing and Installing/Replacing Rear Panel On Left Or Right Rear Seat Backrest

Necessary preliminary tasks

1. Remove trim for release unit. See «52 30 303 Removing and Installing/Replacing Actuating Mechanism For Rear Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-303-removing-and-installingreplacing) .

Note. The right side is removed in the same way as the left side.

Unclip rear panel from backrest frame.

Installation

Replace faulty clips.

Insert rear panel with guide at bottom into backrest.

52 30 251 Replacing Bowden Cable For Left Or Right Rear Seat Backrest

Necessary preliminary tasks

1. Disengage Bowden cable nipple from actuating unit. See «52 30 303 Removing and Installing/Replacing Actuating Mechanism For Rear Seat Backrest»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-303-removing-and-installingreplacing) .

Unclip Bowden cable (1) from backrest frame.

Unhook Bowden cable nipple (2).

Feed out Bowden cable from backrest frame.

52 30 303 Removing and Installing/Replacing Actuating Mechanism For Rear Seat Backrest

Necessary preliminary tasks

1. Remove backrest cover. See «52 30 413 Removing and installing/replacing backrest cover for left or right rear seat»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-413-removing-and-installingreplacing) .

Unclip trim (1) and feed out from release lever (2).

Installation

Retaining lugs must not be damaged.

If necessary, replace faulty trim (1).

Press in detent lugs and remove release unit (1).

Disengage Bowden cable sleeve (1) from actuating unit (2).

Carefully press retaining lug (1) back with screwdriver and feed Bowden cable nipple (2) out of actuating unit.

52 30 390 Removing and Installing Or Replacing Left Or Right Rear Head Restraint

Move head restraint (1) upwards to maximum extent.

Press lock (2) and pull out head restraint.

52 30 405 Removing and Installing/Replacing Seat Cover For Left Or Right Rear Seat

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers)

Necessary preliminary tasks

1. Remove front trim. See «52 30 030 Removing and Installing Front Trim For 3Rd Seat Row On Left Or Right»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-030-removing-and-installing) .

Open tension cable (1).

Disengage welt (2) from seat frame.

Disengage tensioning cable over wire eyelets.

Remove seat cover with padding from seat frame.

Release all retainers in marked area.

Remove seat cover from padding.

Note. Remove all remnants of retainers from seat cover and support.

Installation

Insert new retainer (2) with special tool 52 0 050 and bend closed. See 52 0 050 PLIERS .

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim wire in seat cover
5. Seat cover

Replacing seat cover

Pull trim wires out of seat cover.

Cut new seat cover to size and insert trim wires.

52 30 413 Removing and Installing/Replacing Backrest Cover For Left Or Right Rear Seat

Special tools required

1. 52 0 050. See «52 0 050 PLIERS»(/bmw/x5/e70-2006-2010/remont/seats/#seats-special-tools__52-0-050-pliers) .

Necessary preliminary tasks

1. Remove rear panel
2. Remove head restraint guide. See «52 30 .. Removing and Installing/Replacing Rear Left Or Right Head Restraint Guide»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-30-removing-and-installingreplacing) .

Disengage welt in marked area from backrest frame.

Move backrest back.

Lever out welt in marked area from backrest frame.

Remove backrest cover with padding.

Open Velcro-type fastener in marked area.

Detaching cover and padding

1. Release all retainers in marked area
2. Remove cover from padding
3. Remove all remnants of retainers from cover and padding

Installation

Insert new retainer (2) with special tool 52 0 050 and bend closed. See 52 0 050 PLIERS

1. Padding
2. Retainer
3. Trim wire in padding
4. Trim wire in seat cover
5. Backrest cover

Replacing seat cover

1. Pull all trim wires out of backrest cover
2. If necessary, cut pockets for trim wires in new backrest cover
3. Push trim wires into backrest cover pockets

See also:
• 61 31 203 REPLACING SWITCH COMBINATION FOR SEAT ADJUSTMENT
• 72 00 .. SAFETY REGULATIONS FOR HANDLING COMPONENTS WITH GAS GENERATORS
• 61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD
• 52 0 050 PLIERS
• 00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE)
• 72 SAFETY PRECAUTIONS AND GENERAL INFORMATION
• 72 11 SEAT BELTS
• 52 10 FRONT SEATS
• 72 11 041 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT LOWER BELT FITTING (SEAT BELT TENSIONER)
• 67 31 500 REMOVING AND INSTALLING/REPLACING DRIVE UNIT FOR LONGITUDINAL SEAT ADJUSTMENT
• 67 31 570 REMOVING AND INSTALLING/REPLACING DRIVE UNIT FOR HEAD RESTRAINT HEIGHT ADJUSTMENT ON LEFT OR RIGHT FRONT SEAT
• 51 47 151 REMOVING AND INSTALLING/REPLACING LEFT LUGGAGE COMPARTMENT WHEEL ARCH TRIM
• 52 26 REAR SEATS (THROUGH-LOADING SYSTEM)
• 72 11 101 REMOVING AND INSTALLING/REPLACING REAR CENTER SEAT BELT
• 51 47 135 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT LASHING RAIL IN LUGGAGE COMPARTMENT FLOOR
• 51 47 .. REMOVING AND INSTALLING/REPLACING BOTTOM LEFT OR RIGHT TRIM PANEL FOR LUGGAGE COMPARTMENT (WITH 3RD SEAT ROW)
• 52 30 3RD SEAT ROW
• 72 12 .. UNLOCKING/LOCKING AIRBAG PLUG CONNECTIONS
• 52 17 .. Removing and installing/replacing all trims on left or right seat rails
• 52 13 390 Removing and installing or replacing front left or right head restraint (normal/semielectric)
• 52 14 198 Removing and installing/replacing rear panel on left or right front seat backrest
• 52 14 000 Removing and installing left or right front seat
• 52 14 010 Removing and installing/replacing both seat rails on left or right front seat (normal/electric)
• 52 13 040 Removing and installing/replacing outer cover on left or right front seat (normal/semi-electric)
• 52 14 020 Removing and installing/replacing seat frame on left or right front seat (normal/electric)
• 52 17 030 Removing and installing/replacing backrest frame on left or right seat (comfort)
• 52 13 050 Replacing left or right lumbar cushion on front seat (normal/semi-electric)
• 52 14 050 Replacing lumbar cushion on front left or right seat
• 52 14 060 Removing and installing/replacing valve housing for left or right front lumbar support (normal/electric)
• crash-active head restraint
• 52 14 390 Removing and installing or replacing front left or right head restraint
• 52 13 198 Removing and Installing/Replacing Rear Panel On Left Or Right Front Seat Backrest (Normal/Semi-Electric)
• 52 14 041 Removing and installing inner cover on left or right front seat
• 52 13 400 Replacing Seat Cover For Left Or Right Front Seat (Normal/Semi-Electric)
• 52 13 405 Replacing Backrest Cover For Left Or Right Front Seat (Normal/Semi-Electric)
• 52 14 030 Removing and installing/replacing backrest frame on left or right front seat
• 52 17 000 Removing and installing left or right front seat (comfort)
• 52 17 400 Removing and installing/replacing seat cover for left or right front seat (comfort)
• 52 13 060 Removing and Installing/Replacing Valve Housing For Left Or Right Front Lumbar Support (Normal/Semi-Electric)
• 52 14 .. Removing and Installing/Replacing Guide For Front Left Or Right Head Restraint
• 52 14 040 Removing and Installing/Replacing Outer Cover On Left Or Right Front Seat
• 52 16 198 Removing and Installing Or Replacing Rear Panel On Left Or Right Front Seat Backrest
• 52 16 000 Removing and Installing Left Or Right Front Seat
• 52 16 400 Removing and Installing/Replacing Seat Cover For Left Or Right Front Seat (Sport/Electric)
• 52 14 023 Removing and Installing / Replacing Drive For Left Or Right Active Seat
• 52 17 405 Replacing backrest cover for left or right front seat (comfort)
• 52 17 380 Removing and installing/replacing head restraint mount on left or right front seat (comfort)
• 52 17 205 Removing and installing/replacing both rear panels on left or right front seat backrest
• 52 17 041 Removing and installing/replacing inner cover on left or right front seat (comfort)
• 52 17 034 Removing and Installing/Replacing Shaft For Head Restraint Adjustment
• 52 17 390 Removing and installing/replacing front left or right head restraint (comfort)
• 52 26 .. Removing and Installing/Replacing Left Or Right LOCK Microswitch
• 52 26 .. Removing and Installing Belt Outlet Trim
• 52 26 400 REPLACING SEAT COVER FOR LEFT & Right Rear
• 52 26 411 Replacing Backrest Cover For Left Rear Seat
• 52 26 412 Replacing Backrest Cover For Right Rear Seat
• 52 26 000 Removing and Installing/Replacing Left Or Right Rear Seat (For 3Rd Seat Row)
• 52 26 388 Removing and Installing/Replacing Rear Middle Head Restraint
• 52 26 390 Removing and Installing Or Replacing Left Or Right Rear Head Restraint
• 52 26 .. Overview of Trims, Rear Seat
• 52 26 199 Removing and Installing/Replacing Rear Panel On Left Rear Seat Back
• 52 26 301 Removing and Installing/Replacing Release Unit For Left Or Right Backrest
• 52 26 030 Removing and installing/replacing armrest for rear seat backrest (through-loading system)
• 52 26 008 Removing and installing/replacing left/right sides of backrest on rear seat backrest (through-loading)
• 52 26 311 Removing and installing/replacing lock for left or right rear seat backrest
• 52 26 015 Removing and Installing/Replacing Left/Right Rear Seat Backrest (Throughloading)
• 52 26 085 Removing and Installing/Replacing Backrest Frame For Right Rear Seat (Through-Loading System)
• 52 30 010 Removing and Installing/Replacing Centre Console For 3Rd Seat Row
• 52 30 390 Removing and Installing Or Replacing Left Or Right Rear Head Restraint
• 52 30 020 Removing and Installing Gap Cover For Floor Panel On Left Or Right
• 52 30 080 Removing and Installing/Replacing Left Seat Backrest Frame
• 52 30 085 Removing and Installing/Replacing Right Seat Backrest Frame
• 52 30 000 Removing and Installing Complete 3Rd Seat Row
• 52 30 413 Removing and installing/replacing backrest cover for left or right rear seat
• 52 30 303 Removing and Installing/Replacing Actuating Mechanism For Rear Seat Backrest
• 52 30 .. Removing and Installing Outer Trim For 3Rd Seat Row
• 52 30 405 Removing and Installing/Replacing Seat Cover For Left Or Right Rear Seat
• 52 30 030 Removing and Installing Front Trim For 3Rd Seat Row On Left Or Right
• 52 30 .. Removing and Installing/Replacing Rear Left Or Right Head Restraint Guide
