16 00 General Function Description For Fuel Supply Systems
Fuel supply systems, spark-ignition engines
Fuel system
The electric fuel pump in the fuel tank generates the pressure in the fuel system which is set by the pressure regulator to a specific level.
Tank venting system
The tank venting system is an enclosed system which is vented via a carbon canister. The carbon is incorporated in the carbon canister as granulate. The large surface of the carbon stores the fuel vapors which occur in the fuel tank. The carbon canister must be regenerated on a regular basis so as to be able to continue storing fuel vapors. Regeneration is performed by way of purging with fresh air via the intake manifold. This process is controlled by the engine control unit.
Fuel supply systems, diesel engines
Fuel system
The electric fuel pump in the fuel tank supplies the engine with fuel. Two types of high-pressure pump are used for cylinder injection.
- The distributor injection pump supplies each cylinder directly with fuel via the corresponding injection nozzle.
- The high-pressure pump for the common rail systems generates in the fuel rail the necessary pressure for all the injection nozzles.
In common rail systems, a further pump (inline pump, M57/gear pump, M67) is connected between the high - pressure pump and the electric fuel pump. This pump supports the fuel pump in the fuel tank in the event of a high fuel demand.
Tank venting system
Diesel fuel is non-volatile and therefore a carbon canister is not required. The fuel tank is vented directly to atmosphere.
16 00 ... Overview of Fuel Supply System (Petrol/Gasoline)
- Draw off fuel. See «16 00 005 Draining and Filling Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-005-draining-and-filling)
- Dust filter with tube. See «16 14 060 Removing and Installing/Replacing Dust Filter for Tank Leak Diagnosis Module (DMTL)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-14-060-removing-and-installingreplacing)
- Leak diagnosis pump. See «16 13 015 Removing and Installing/Replacing Tank Leak Diagnosis Module (petrol/Gasoline Cars with US DMTL version)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-13-015-removing-and-installingreplacing)
- Carbon canister for DMTL (USA). See «16 12 010 Removing and Installing/Replacing Carbon Canister (US Version with DMTL)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-12-010-removing-and-installingreplacing)
- Fuel pump and right fuel gauge sensor. See «16 14 010 Removing and Installing/Replacing Fuel Pump (Petrol/Gasoline Vehicles)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-14-010-removing-and-installingreplacing)
- Fuel filler pipe. See «16 11 060 Removing and Installing Or Replacing Fuel Filler Pipe»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-11-060-removing-and-installing)
- Carbon canister. See «16 12 010 Removing and Installing/Replacing Carbon Canister»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-12-010-removing-and-installingreplacing)
- Control unit, electric fuel pump. See «16 14 500 Removing and Installing or Replacing Control Unit For Electric Fuel Pump»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-14-500-removing-and-installing)
- Left fuel gauge sensor. See «16 12 001 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Left)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-12-001-removing-and-installing)
- Fuel tank. See «16 11 030 Removing and Installing/Replacing Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-11-030-removing-and-installingreplacing)
- Clamping bands. See «16 11 ... Replacing Left Or Right Clamping Band For Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-11-replacing-left-or)
- Testing. See «16 00 100 Checking Fuel Tank And Tank Ventilation System For Leaks»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-100-checking-fuel-tank) , «16 00 102 Checking Fuel Tank And Tank Venting System For Leaks With Tank Leakage Diagnosis Module (DM-TL)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-102-checking-fuel-tank) , «16 00 510 Conducting Leak Test On Fuel Tank And Tank Ventilation System»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-510-conducting-leak-test) , «16 11 130 Checking Filler Cap Pressure Relief Valve»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-11-130-checking-filler-cap)
16 00 005 Draining and Filling Fuel Tank
Special tools required
- 16 1 080 «16 1 080 HOSE GUIDE»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-special-tools-n52-n62)
| IMPORTANT | Observe country-specific safety regulations. Ensure adequate ventilation in the place of work! Connect the exhaust and extraction systems to the exhaust tailpipe. The electric fuel pump must not operate without fuel! After completing repairs but before starting the engine for the first time, fill the fuel tank with min. 5 l fuel through the fuel filler pipe. Do not damage non-return flap when pulling out extraction hose. |
Diesel vehicles
Before starting the engine for the first time, if the tank has been run dry or drawn off, fill with diesel fuel and turn on ignition for approx. 1 minute. The fuel circuit is thus filled and vented, which results in the engine firing more quickly.
Drawing off fuel
Start engine and allow to run.
The electric fuel pump runs.
In this way, the fuel is repumped through the suction jet pump from the left to the right side of the fuel tank.
Note. Fuel can be drawn out of left and right sides of tank through filler neck, leaving only a small residue. The residual quantity is drawn off through the service opening (on right/left).
Insert special tool 16 1 080 HOSE GUIDE into filler neck.
Special tool 16 1 080 HOSE GUIDE has two different diameters for petrol/gasoline and diesel vehicles!
Slide extraction hose of extractor unit, refer to BMW Service Workshop Equipment and Planning Documentation , through special tool 16 1 080 HOSE GUIDE into the fuel filler pipe, turning in the process if necessary.
Insertion length approx. 170 cm.
Draw off fuel with suction unit (refer to BMW Service Workshop Equipment ) as far as possible.
Follow drawing off of fuel on fuel gauge in instrument cluster.
Scheme 47
Drawing off residual fuel quantity
| IMPORTANT | Ensure car interior is adequately ventilated. Catch dripping fuel in a suitable container. |
Remove left sensor unit. See 16 12 001 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Left) .
Remove right sensor unit. See 16 12 000 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Right) .
Draw off residual fuel quantity through service openings.
Fuel filling
Insert special tool 16 1 080 HOSE GUIDE into filler neck.
Special tool 16 1 080 HOSE GUIDE has two different diameters for petrol/gasoline and diesel vehicles!
Slide extraction hose of extractor unit, refer to BMW Service Workshop Equipment and Planning Documentation, approx. 40 cm into fuel filler pipe.
Fill fuel from suction extractor unit.
Extracting fuel after a defect in the suction jet pump or fuel pump
Draw off right half of tank completely through fuel filler pipe.
Remove left sensor unit. See 16 12 001 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Left) .
Insert extraction hose through service opening in tank, fuel (also residual quantity) can be drawn off.
16 00 100 Checking Fuel Tank And Tank Ventilation System For Leaks
Special tools required
- 13 3 010 «13 3 010 HOSE CLIP»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-system-special-tools-n52-n62)
- 16 1 070 «16 1 070 PLUG (CARBON CANISTER)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-special-tools-n52-n62__16-1-070-plug-carbon-canister)
- 16 1 171 «16 1 170 TESTER WITH TEST ADAPTER»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-special-tools-n52-n62__16-1-170-tester-with-test)
- 16 1 174 «16 1 170 TESTER WITH TEST ADAPTER»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-special-tools-n52-n62__16-1-170-tester-with-test)
Note. The following procedure is only applicable to vehicles without the tank leak diagnosis module. Check tank venting system if a leak is suspected.
Observe safety instructions on raising the vehicle. See 00 ... ... LIFTING VEHICLE WITH A LIFTING PLATFORM .
Comply with the following conditions in order to obtain plausible test results
- Content of fuel tank: Max. 90% (approx. 79 l) Min. 13% (approx. 11 l, reserve warning lamp must not light up).
- Park the car in the workshop at least 2 hours before the test so that the fuel temperature is approximately that of the workshop temperature (ideal fuel temperature approx. 10...20°C).
- Never refuel the vehicle directly prior to the leak test due to the strong emission of gas by the fresh fuel.
Remove rear right wheel arch trim.
Fold strainer in insect strainer to one side.
Using special tool 16 1 070 PLUG (CARBON CANISTER) , seal opening for insect strainer on carbon canister.
Remove fuel filler cap and connect special tool 16 1 170 TESTER WITH TEST ADAPTER to fuel filler neck.
Clamp special tool. See 16 1 170 TESTER WITH TEST ADAPTER on fuel filler neck with adjusting wheel (1).
| IMPORTANT | Set pressure regulator on special tool 16 1 171. See 16 1 170 TESTER WITH TEST ADAPTER fully in "-" direction. |
Connect special tool. See 16 1 170 TESTER WITH TEST ADAPTER using compressed air line (1) to garage compressed air system (8...10 bar).
Connect pressure sensor (2) from Diagnosis and Information System with a measuring range of 0...3.5 bar.
| IMPORTANT | Do not connect fast-release coupling (3) of special tool 16 1 171 16 1 170 TESTER WITH TEST ADAPTER yet. |
Select "Measurement" function on Diagnosis and Information System (DIS).
Set measuring range according to pressure sensor to 0...3.5 bar.
Using pressure regulator on special tool 16 1 171 16 1 170 TESTER WITH TEST ADAPTER , increase pressure by 0.050 bar.
Connect special tool 16 1 174 16 1 170 TESTER WITH TEST ADAPTER to fast-release coupling of special tool 16 1 171 16 1 170 TESTER WITH TEST ADAPTER .
Using pressure regulator on special tool 16 1 171 16 1 170 TESTER WITH TEST ADAPTER , reset gauge pressure in fuel tank to 0.050 bar.
| IMPORTANT | Do not under any circumstances increase pressure by more than 0.100 bar as this would result in damage to the fuel tank and venting system. |
Using special tool 13 3 010 13 3 010 HOSE CLIP , disconnect supply line from special tool 16 1 171 16 1 170 TESTER WITH TEST ADAPTER to tank filler neck.
Allow a rest period of approx. 20 secs.
Read off and note down starting pressure value. Wait approx. 60 secs.
Read off final pressure value and compare with starting pressure value.
Measurement evaluation
| Pressure drop between 0.008 and 0.010 bar. | Measure again. |
|---|---|
| Pressure drop in 60 secs. greater than 0.010 bar. | System leaking beyond permitted levels. Carry out leak test 16 00 510 Conducting Leak Test On Fuel Tank And Tank Ventilation System . |
Measurement Evaluation
16 00 102 Checking Fuel Tank And Tank Venting System For Leaks With Tank Leakage Diagnosis Module (DM-TL)
Note. An OBD fault is indicated by the "Check Engine" indicator lamp in the instrument cluster lighting up. This may indicate a leak in the tank venting system. Information on this is provided by the fault memory of the DME control unit.
- Read out fault memory of DME control unit and carry out a diagnosis in accordance with faults stored.
- A leak test with the DM-TL module is then carried out if: The components of the DM-TL module are O.K. A fault is stored in the DME fault memory (tank leak detected).
Adhere to following conditions in order to carry out a correct leak test
- Content of fuel tank < 90 %
- Reserve indicator lamp "off"
- Leave car in workshop for at least 2 hours so that fuel temperature comes into line with workshop temperature (ideal fuel temperature approx. 10...20 °C).
- Do not under any circumstances fill up car with fresh fuel (strong exhalation of fresh fuel).
- Check that fuel tank cap is correctly seated.
| WARNING | Check that fuel tank cap is correctly seated. |
Clear DME fault memory.
In the Diagnosis and Information System (DIS), go to the "Function and component selection" page.
Work through tank leakage diagnosis module. Leakage test is carried out.
If fault is recorded again in DME fault memory (tank leak detected), carry out leak test. See 16 00 510 Conducting Leak Test On Fuel Tank And Tank Ventilation System .
16 00 510 Conducting Leak Test On Fuel Tank And Tank Ventilation System
Note. The following procedure is only applicable to vehicles with the tank leak diagnosis module (DM-TL).
Select "Tank leak diagnosis module (DM-TL)" on Diagnosis and Information System (DIS).
- The leak diagnosis pump pressurizes the fuel tank and tank venting system for 30 secs.
- If pressure is required for more than 30 secs., reactivate the "Activate" button after 30 secs. in each case.
For vehicles without tank leak diagnosis module
Pressures fuel tank and tank venting system. See 16 00 100 Checking Fuel Tank And Tank Ventilation System For Leaks .
When leak-testing with a leak detector: follow manufacturer's operating instructions.
| IMPORTANT | On vehicles with tank leak diagnosis modules (DM-TL), do not work with external pressurization as the tank venting system will leak under this condition. Or use a suitable extractor system. On account of emerging fuel vapors, carry out all operations in well ventilated rooms. Observe country-specific accident prevention and occupational safety regulations. |
The leak test can be carried out with a leak detector. Possible causes may be
- Fuel tank cap leaking (check fuel cap pressure relief valve. See «16 11 130 Checking Filler Cap Pressure Relief Valve»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-11-130-checking-filler-cap) )
- Tank venting lines leaking (fuel tank carbon canister - tank venting valve)
- Tank venting valve leaking (engine compartment)
- Fuel level sensor flange on tank leaking
16 11 ... Replacing Left Or Right Clamping Band For Fuel Tank
Necessary preliminary tasks
- Remove underbody panelling. See «51 47 ... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELLING»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-removing-and-installingreplacing) on left and right
| IMPORTANT | Secure fuel tank against slipping and falling out. |
Heavily support the fuel tank.
Release screws (1) and remove clamping band.
Installation
Tightening torque. See 16 11 FUEL TANK AND MOUNTING PARTS .
16 11 030 Removing and Installing/Replacing Fuel Tank
Recycling
Fuel escapes when fuel lines are detached. Have a suitable collecting container ready.
Catch and dispose of escaping fuel.
Observe country-specific waste-disposal regulations.
| IMPORTANT | Ensure adequate ventilation in the place of work! Avoid skin contact (wear gloves)! |
After installation of fuel tank/prior to first engine start-up
- Check ground connection at fuel filler neck to body for continuity. If necessary, clean contact surface between body and fuel filler pipe screw connection.
- Fill fuel tank with at least 5 liters of fuel.
- Check transfer function of suction jet pump. See «16 12 ... Checking repumping function of suction - jet pump with BMW Diagnosis System»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-12-checking-repumping-function) .
Necessary preliminary tasks
- Draw off fuel from fuel tank. See «16 00 005 Draining and Filling Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-005-draining-and-filling)
- Remove propeller shaft. See «26 11 000 REMOVING AND INSTALLING PROPELLER SHAFT (INSERTED) COMPLETELY»(/bmw/x5/e70-2006-2010/remont/driveshaft-universal-joints/#propeller-shaft-repair)
- Remove underbody panelling on left and right. See «51 47 ... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELLING»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-removing-and-installingreplacing)
- Remove rear right wheel arch trim. See «51 71 041 REMOVING AND INSTALLING/REPLACING REAR LEFT OR RIGHT WHEEL ARCH COVER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-041-removing-and-installingreplacing)
Release nuts (1) and remove holder (2).
Release hose clamp (1) and detach fuel filler hose in direction of arrow.
Installation
Tightening torque 16 12 1AZ. See 16 12 FUEL DELIVERY .
Unlock quick-release fastener (1) and detach vent line.
Detach vent line from holders (2).
Unlock fuel feed line at quick-release fastener (1) and disconnect.
| IMPORTANT | Catch escaping fuel in a suitable container. |
| IMPORTANT | Secure fuel tank against slipping and falling out. |
Heavily support the fuel tank.
Release screws (1) on clamping bands on left and right.
Installation
Tightening torque 16 11 2AZ. See 16 11 FUEL TANK AND MOUNTING PARTS .
Slacken nut (2).
Installation
Tightening torque 16 11 2AZ. See 16 11 FUEL TANK AND MOUNTING PARTS .
| IMPORTANT | Do not lead refuelling vent line through opening in body when lowering. |
Lower fuel tank a little so that sensor units can be reached.
Disconnect plug connection (1).
Unlock and detach quick-connect couplings (2).
Disconnect plug connection (1).
Unlock and detach quick-connect couplings (2).
Lower fuel tank.
The following components must be modified when the fuel tank is replaced
- Right sensor unit (1). See «16 12 000 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Right)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-12-000-removing-and-installing)
- Left sensor unit (2). See «16 12 001 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Left)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-12-001-removing-and-installing)
- Fuel feed line (3)
- If necessary, lines for independent heating
16 11 060 Removing and Installing Or Replacing Fuel Filler Pipe
Recycling
Fuel escapes when fuel lines are detached. Have a suitable collecting container ready.
Catch and dispose of escaping fuel.
Observe country-specific waste-disposal regulations.
| IMPORTANT | Ensure adequate ventilation in the place of work! Avoid skin contact (wear gloves)! |
Before starting the engine for the first time
- Fill fuel tank with at least 5 liters of fuel.
- Check ground connection at fuel filler neck to body for continuity. If necessary, clean contact surface between body and fuel filler pipe screw connection.
Necessary preliminary tasks
- Draw off fuel from fuel tank. See «16 00 005 Draining and Filling Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-005-draining-and-filling)
- Remove rear right wheel arch trim. See «51 71 041 REMOVING AND INSTALLING/REPLACING REAR LEFT OR RIGHT WHEEL ARCH COVER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-041-removing-and-installingreplacing)
- Remove underbody panelling on right. See «51 47 ... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELLING»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-removing-and-installingreplacing)
Unhook retaining strap (1) from tank flap.
Open cap and set to one side.
Scheme 48
Unfasten hose clip (1).
Installation
Replace hose clip.
Tightening torque 16 12 1AZ. See 16 12 FUEL DELIVERY .
Scheme 49
Unlock quick-release fasteners (1) and disconnect vent hoses.
Release nuts (2) and (3).
Installation
Check plastic nut (3), replace if necessary.
Tightening torque 16 12 2AZ. See 16 12 FUEL DELIVERY .
Scheme 50
Unclip line holder (1).
Release nut (2) and remove fuel filler pipe.
Installation
Check plastic nut (2), replace if necessary.
Tightening torque 16 12 2AZ. See 16 12 FUEL DELIVERY .
16 11 071 Replacing Rubber Sleeve Between Fuel Filler Pipe And Fuel Tank
Recycling
Fuel escapes when fuel lines are detached. Have a suitable collecting container ready.
Catch and dispose of escaping fuel.
Observe country-specific waste-disposal regulations.
| IMPORTANT | Ensure adequate ventilation in the place of work! Avoid skin contact (wear gloves)! |
Before starting the engine for the first time
- Fill fuel tank with at least 5 liters of fuel.
Necessary preliminary tasks
- Draw off fuel from fuel tank. See «16 00 005 Draining and Filling Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-005-draining-and-filling)
- Remove underbody panelling on right. See «51 47 ... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELLING»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-removing-and-installingreplacing)
- Remove rear right wheel arch trim. See «51 71 041 REMOVING AND INSTALLING/REPLACING REAR LEFT OR RIGHT WHEEL ARCH COVER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-041-removing-and-installingreplacing)
Unclip line holder (1).
Slacken nut (2).
Installation
Check plastic nut (2), replace if necessary.
Tightening torque 16 12 2AZ. See 16 12 FUEL DELIVERY .
Loosen hose clamps (1).
Detach rubber sleeve first from fuel filler pipe and then from fuel tank.
Installation
Tightening torque 16 11 3AZ. See 16 11 FUEL TANK AND MOUNTING PARTS .
16 11 130 Checking Filler Cap Pressure Relief Valve
Special tools required
- 13 3 010 «13 3 010 HOSE CLIP»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-system-special-tools-n52-n62)
- 16 1 171 «16 1 170 TESTER WITH TEST ADAPTER»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-special-tools-n52-n62__16-1-170-tester-with-test)
- 16 1 172 «16 1 170 TESTER WITH TEST ADAPTER»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-special-tools-n52-n62__16-1-170-tester-with-test)
- 16 1 173 «16 1 170 TESTER WITH TEST ADAPTER»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-special-tools-n52-n62__16-1-170-tester-with-test)
Set pressure regulator on special tool 16 1 171. See 16 1 170 TESTER WITH TEST ADAPTER fully in "-" direction.
Connect special tool 16 1 171. See 16 1 170 TESTER WITH TEST ADAPTER via compressed air line (1) to workshop/garage compressed air system (8 ... 10 bar).
Connect pressure sensor (2) of Diagnosis and Information System with a measuring range of 0...3.5 bar.
Select special tool 16 1 172 or 16 1 173. See 16 1 170 TESTER WITH TEST ADAPTER matching vehicle's filler cap and attach to quick release coupling of special tool 16 1 171. See 16 1 170 TESTER WITH TEST ADAPTER .
Install filler cap on selected special tool (3).
Note. Only the absolute pressure is indicated in the display of the Diagnosis and Information System (DIS). The current ambient air pressure is already displayed without additional pressurization.
Check testing equipment for leaks!
Select "Measurement" function on Diagnosis and Information System (DIS).
Set measuring range according to pressure sensor to 0-3.5 bar.
Increase pressure by 0.2 bar with pressure regulator on special tool 16 1 171. See 16 1 170 TESTER WITH TEST ADAPTER .
Using special tool 13 3 010. See 13 3 010 HOSE CLIP , disconnect delivery line from special tool 16 1 171. See 16 1 170 TESTER WITH TEST ADAPTER to tank filler neck.
Wait 60 secs.
Read off final pressure value and compare with starting pressure value.
Measurement evaluation
| Pressure drop > 0.012 bar | Testing equipment leaking. Check connection points for leaks. |
Measurement Evaluation
Check filler cap pressure relief!
Follow same test procedure as for "Checking testing equipment for leaks".
Increase pressure by 0.3 bar with pressure regulator on special tool 16 1 171. See 16 1 170 TESTER WITH TEST ADAPTER .
Measurement evaluation
| Pressure drop > 0.012 bar | Filler cap pressure relief valve faulty. Replace filler cap. |
Measurement Evaluation
16 12 ... Replacing outer fuel filter
| IMPORTANT | Ensure adequate ventilation in the place of work! Ensure absolute cleanliness when working on the open fuel tank. Contaminants in the fuel tank can impair driving operation or may even result in vehicle breakdown! Catch escaping fuel in a suitable container. |
Necessary preliminary tasks
- Remove side left underbody panelling and tank underride protection on left. See «51 47 ... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELLING»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-removing-and-installingreplacing) .
| IMPORTANT | Fuel in fuel lines is under pressure Fuel escapes when fuel lines (1) are disconnected! Catch and dispose of escaping fuel. |
Release single-ear clip (1) and detach pressure reference line.
Installation: Replace single-ear clip. Detach fuel feed lines (2). Detach fuel return line (3). Release screws (4) and remove bracket.
Installation: Tightening torque, see 16 12 3AZ in 16 12 FUEL DELIVERY .
Remove fuel filter (5).
Removing Outer Fuel Filter. Scheme 51
Installation: After completing tasks, check fuel system for leaks
16 12 ... Checking Repumping Function Of Suction - Jet Pump with BMW Diagnosis System
| IMPORTANT | Ensure adequate ventilation in the place of work! Ensure absolute cleanliness when working on the open fuel tank. Contaminants in the fuel tank can impair driving operation or may even result in vehicle breakdown! Catch escaping fuel in a suitable container. |
Necessary preliminary tasks
- Fill level must be < or = 28 l If necessary, draw off fuel from fuel tank «16 00 005 Draining and Filling Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-005-draining-and-filling)
- Pour two to three liters of fuel into the left tank chamber via the flange opening
- Connect diagnosis system Path: Brief test KOMBI Instrument cluster Diagnosis control unit functions Diagnosis requests Tank sensor 1, tank sensor 2
Note. Tank sensor 1 = right tank sensor Tank sensor 2 = left tank sensor
Start engine.
Compare display for left and right tank chambers.
Repumping function OK
If fill level of tank sensor 2 (left chamber) is falling (approx. one liter per minute).
Repumping function not OK
If fill level of tank sensor 2 (left chamber) is stable or rising.
16 12 000 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Right)
Recycling
Fuel escapes when fuel lines are detached. Have a suitable collecting container ready.
Catch and dispose of escaping fuel.
Observe country-specific waste-disposal regulations.
| IMPORTANT | Ensure adequate ventilation in the place of work! Ensure absolute cleanliness when working on the open fuel tank. Contaminants in the fuel tank can impair driving operation or may even result in vehicle breakdown! |
Before starting the engine for the first time
- Fill fuel tank with at least 5 liters of fuel
Check transfer function of suction jet pump. See 16 12 ... Checking Repumping Function Of Suction - Jet Pump with BMW Diagnosis System .
Necessary preliminary tasks
- Draw off fuel from fuel tank. See «16 00 005 Draining and Filling Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-005-draining-and-filling)
- Remove rear seat bench «30 3RD SEAT ROW»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair) , «52 26 005 REMOVING AND INSTALLING / REPLACING REAR SEAT»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-005-removing-and-installing)
For vehicles with 2 seat rows only
Disconnect plug connection (1).
Remove cover (2).
Scheme 52
Release nuts (1) and remove cover for service opening (2) from right side of fuel tank.
Scheme 53
Disconnect plug connection (1).
Unlock quick-release fastener (2) and detach vent line.
If necessary, unlock quick-release fastener (3) for fuel feed line of independent heating and detach.
If necessary, disconnect plug connection (4) for independent heating fuel pump.
Scheme 54
Release completely remainder of torque break off head (1) with a screwdriver.
Remove hose clamp from clamping ring (2).
Note. A flexible extension can be used to release the hose clamp
Press clamping ring (2) part at open end in direction of arrow and remove.
Scheme 55
Installation
Make sure that service cover is installed in correct position.
Indentation (2) on clamping ring must line up with raised section (1) of tank.
Pin on service cover (3) must line up with indentation on clamping ring.
Hose clip with torque break off head (4) must always be replaced.
Tighten hose clip until torque break off head (4) breaks off.
Scheme 56
Installation
Seal (1) must always be replaced.
Scheme 57
Disconnect grounding cable (1) towards top.
| IMPORTANT | Grounding cable (1) must be replaced if it has been detached once! |
Scheme 58
Carefully raise service cover.
Unclip plastic tube (1).
Unlock and disconnect quick-connect coupling (2).
Remove fuel pump.
| IMPORTANT | Catch escaping fuel in suitable container. No fuel is permitted to get into the interior! |
Scheme 59
With fuel pump removed, disconnect plug connection (1) in tank and replace grounding cable (2).
Scheme 60
Unclip fuel level sensor (1) in direction of arrow from housing and then slide out of guides (2) in direction of arrow.
Installation
Fuel level sensor (1) must be felt and heard to snap into place.
Scheme 61
Disconnect plug connection (1) and disengage cable (2) from guides.
Scheme 62
16 12 001 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Left)
Recycling
Fuel escapes when fuel lines are detached. Have a suitable collecting container ready.
Catch and dispose of escaping fuel.
Observe country-specific waste-disposal regulations.
| IMPORTANT | Ensure adequate ventilation in the place of work! Ensure absolute cleanliness when working on the open fuel tank. Contaminants in the fuel tank can impair driving operation or may even result in vehicle breakdown! |
Before starting the engine for the first time
- Fill fuel tank with at least 5 liters of fuel
Necessary preliminary tasks
- Draw off fuel from fuel tank. See «16 00 005 Draining and Filling Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-005-draining-and-filling)
- Remove rear seat bench. See «30 3RD SEAT ROW»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair) , «52 26 005 REMOVING AND INSTALLING / REPLACING REAR SEAT»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-005-removing-and-installing)
- Remove right sensor unit. See «16 12 000 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Right)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-12-000-removing-and-installing)
For vehicles with 2 seat rows only
Disconnect plug connection (1).
Remove cover (2).
Release nuts (1) and remove cover for service opening (2) from left side of fuel tank.
Disconnect plug connection (1).
Unlock quick-release fastener (2) and detach fuel feed line.
Unlock quick-release fastener (3) for vent line and detach.
Scheme 63
Release completely remainder of torque break off head (1) with a screwdriver.
Remove hose clamp from clamping ring (2).
Note. A flexible extension can be used to release the hose clamp
Press clamping ring (2) part at open end in direction of arrow and remove.
Installation
Make sure that service cover is installed in correct position.
Indentation (2) on clamping ring must line up with raised section (1) of tank.
Pin on service cover (3) must line up with indentation on clamping ring.
Hose clip with torque break off head (4) must always be replaced.
Tighten hose clip until torque break off head (4) breaks off.
Installation
Seal (1) must always be replaced.
Scheme 64
Attach an auxiliary lead (1) to hose pack (2) through service opening.
The auxiliary lead is pulled through with the hose pack towards the left and facilitates subsequent reinstallation.
Installation
Make sure when pulling through the hose pack that the tank ventilation system in the tank tunnel is not damaged.
Scheme 65
Remove sensor unit (1) from fuel tank.
Feed sensor unit (1) with hose pack (2) out of fuel tank.
Installation
When replacing the sensor unit, modify the end of the auxiliary lead to the new hose pack and carefully pull in through the tank.
Note. Illustration shows the tank removed.
Scheme 66
Unclip fuel level sensor (1) in direction of arrow from housing and then slide out of guides in direction of arrow.
Installation
Fuel level sensor (1) must be felt and heard to snap into place.
Scheme 67
Disconnect plug connection (1) and disengage cable (2) from guides.
Scheme 68
16 12 010 Removing and Installing/Replacing Carbon Canister
Necessary preliminary tasks
- Remove rear right wheel arch trim. See «51 71 041 REMOVING AND INSTALLING/REPLACING REAR LEFT OR RIGHT WHEEL ARCH COVER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-041-removing-and-installingreplacing)
Unlock quick-release fasteners (1) and disconnect vent lines.
Release screws (2) and remove carbon canister (3).
Installation
Tightening torque 16 13 1AZ. See 16 13 TANK VENTILATION .
Scheme 69
16 12 010 Removing and Installing/Replacing Carbon Canister (US Version with DMTL)
Necessary preliminary tasks
- Remove rear right wheel arch trim. See «51 71 041 REMOVING AND INSTALLING/REPLACING REAR LEFT OR RIGHT WHEEL ARCH COVER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-041-removing-and-installingreplacing)
Disconnect plug connection (1).
Unlock and detach quick-connect couplings (2).
Unclip cable holders (3) from carbon canister.
Scheme 70
Release nuts (1) and remove carbon canister (2) towards bottom.
Installation
Tightening torque 16 13 1AZ. See 13 FUEL VENTILATION .
Scheme 71
The following components must be modified when the carbon canister is replaced
Scheme 72
- Dust filter (1). See «16 14 060 Removing and Installing/Replacing Dust Filter for Tank Leak Diagnosis Module (DMTL)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-14-060-removing-and-installingreplacing)
- Tank leakage diagnosis module (2). See «16 13 015 Removing and Installing/Replacing Tank Leak Diagnosis Module (Petrol/Gasoline Cars with US DMTL Version)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-13-015-removing-and-installingreplacing)
- Hose (3) between carbon canister and tank leakage diagnosis module
16 13 015 Removing and Installing/Replacing Tank Leak Diagnosis Module (Petrol/Gasoline Cars with US DMTL Version)
Necessary preliminary tasks
- Remove carbon canister. See «16 12 010 Removing and Installing/Replacing Carbon Canister (US Version with DMTL)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-12-010-removing-and-installingreplacing)
Unlock and disconnect quick-connect coupling (1).
Unfasten hose clip (2) and remove hose.
Installation
If necessary, replace hose clamp.
Release screws (3) and remove tank leakage diagnosis module.
Scheme 73
Recycling
Fuel escapes when fuel lines are detached. Have a suitable collecting container ready.
Catch and dispose of escaping fuel.
Observe country-specific waste-disposal regulations.
| IMPORTANT | Ensure adequate ventilation in the place of work! Ensure absolute cleanliness when working on the open fuel tank. Contaminants in the fuel tank can impair driving operation or may even result in vehicle breakdown! |
Before starting the engine for the first time
- Fill fuel tank with at least 5 liters of fuel
Check transfer function of suction jet pump. See 16 12 ... Checking Repumping Function Of Suction - Jet Pump with BMW Diagnosis System .
Necessary preliminary tasks
- Draw off fuel from fuel tank. See «16 00 005 Draining and Filling Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-005-draining-and-filling)
- Remove rear seat bench. See «30 3RD SEAT ROW»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair) and «52 26 005 REMOVING AND INSTALLING / REPLACING REAR SEAT»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-005-removing-and-installing)
For vehicles with 2 seat rows only
Disconnect plug connection (1).
Remove cover (2).
Release nuts (1) and remove cover for service opening (2) from right side of fuel tank.
Disconnect plug connection (1).
Unlock quick-release fastener (2) and detach vent line.
If necessary, unlock quick-release fastener (3) for fuel feed line of independent heating and detach.
If necessary, disconnect plug connection (4) for independent heating fuel pump.
Release completely remainder of torque break off head (1) with a screwdriver.
Remove hose clamp from clamping ring (2).
Note. A flexible extension can be used to release the hose clamp
Press clamping ring (2) part at open end in direction of arrow and remove.
Installation
Make sure that service cover is installed in correct position.
Indentation (2) on clamping ring must line up with raised section (1) of tank.
Pin on service cover (3) must line up with indentation on clamping ring.
Hose clip with torque break off head (4) must always be replaced.
Tighten hose clip until torque break off head (4) breaks off.
Installation
Seal (1) must always be replaced.
Disconnect grounding cable (1) towards top.
| IMPORTANT | Grounding cable (1) must be replaced if it has been detached once! |
Scheme 74
Carefully raise service cover.
Unclip plastic tube (1).
Unlock and disconnect quick-connect coupling (2).
Remove fuel pump.
| IMPORTANT | Catch escaping fuel in suitable container. No fuel is permitted to get into the interior! |
With fuel pump removed, disconnect plug connection (1) in tank and replace grounding cable (2).
Unclip fuel level sensor (1) in direction of arrow from housing and then slide out of guides (2) in direction of arrow.
Installation
Fuel level sensor (1) must be felt and heard to snap into place.
Disconnect plug connection (1) and disengage cable (2) from guides.
Recycling
Fuel escapes when fuel lines are detached. Have a suitable collecting container ready.
Catch and dispose of escaping fuel.
Observe country-specific waste-disposal regulations.
| IMPORTANT | Ensure adequate ventilation in the place of work! Ensure absolute cleanliness when working on the open fuel tank. Contaminants in the fuel tank can impair driving operation or may even result in vehicle breakdown! |
Before starting the engine for the first time
- Fill fuel tank with at least 5 liters of fuel
Check transfer function of suction jet pump. See 16 12 ... Checking Repumping Function Of Suction - Jet Pump with BMW Diagnosis System .
Necessary preliminary tasks
- Draw off fuel from fuel tank. See «16 00 005 Draining and Filling Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-005-draining-and-filling)
- Remove rear seat bench. See «30 3RD SEAT ROW»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair) or «52 26 005 REMOVING AND INSTALLING / REPLACING REAR SEAT»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-005-removing-and-installing)
- Remove right sensor unit «16 12 000 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Right)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-12-000-removing-and-installing)
For vehicles with 2 seat rows only
Disconnect plug connection (1).
Remove cover (2).
Release nuts (1) and remove cover for service opening (2) from left side of fuel tank.
Disconnect plug connection (1).
Unlock quick-release fastener (2) and detach fuel feed line.
Unlock quick-release fastener (3) for vent line and detach.
Scheme 75
Release completely remainder of torque break off head (1) with a screwdriver.
Remove hose clamp from clamping ring (2).
Note. A flexible extension can be used to release the hose clamp
Press clamping ring (2) part at open end in direction of arrow and remove.
Installation
Make sure that service cover is installed in correct position.
Indentation (2) on clamping ring must line up with raised section (1) of tank.
Pin on service cover (3) must line up with indentation on clamping ring.
Hose clip with torque break off head (4) must always be replaced.
Tighten hose clip until torque break off head (4) breaks off.
Installation
Seal (1) must always be replaced.
Attach an auxiliary lead (1) to hose pack (2) through service opening.
The auxiliary lead is pulled through with the hose pack towards the left and facilitates subsequent reinstallation.
Installation
Make sure when pulling through the hose pack that the tank ventilation system in the tank tunnel is not damaged.
Remove sensor unit (1) from fuel tank.
Feed sensor unit (1) with hose pack (2) out of fuel tank.
Installation
When replacing the sensor unit, modify the end of the auxiliary lead to the new hose pack and carefully pull in through the tank.
Note. Illustration shows the tank removed.
Unclip fuel level sensor (1) in direction of arrow from housing and then slide out of guides in direction of arrow.
Installation
Fuel level sensor (1) must be felt and heard to snap into place.
Disconnect plug connection (1) and disengage cable (2) from guides.
16 14 010 Removing and Installing/Replacing Fuel Pump (Petrol/Gasoline Vehicles)
Special tools required
- 00 9 252
Recycling
Fuel escapes when fuel lines are detached. Have a suitable collecting container ready.
Catch and dispose of escaping fuel.
Observe country-specific waste-disposal regulations.
| IMPORTANT | Ensure adequate ventilation in the place of work! Ensure absolute cleanliness when working on the open fuel tank. Contaminants in the fuel tank can impair driving operation or may even result in vehicle breakdown! |
Before starting the engine for the first time
- Fill fuel tank with at least 5 liters of fuel
Check transfer function of suction jet pump. See 16 12 ... Checking Repumping Function Of Suction - Jet Pump with BMW Diagnosis System .
Necessary preliminary tasks
- Draw off fuel from fuel tank. See «16 00 005 Draining and Filling Fuel Tank»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-supply-system-repair-n52-n62__16-00-005-draining-and-filling)
- Remove rear seat bench. See «30 3RD SEAT ROW»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair) or «52 26 005 REMOVING AND INSTALLING / REPLACING REAR SEAT»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-005-removing-and-installing)
For vehicles with 2 seat rows only
Disconnect plug connection (1).
Remove cover (2).
Release nuts (1) and remove cover for service opening (2) from right side of fuel tank.
Disconnect plug connection (1).
Unlock quick-release fastener (2) and detach vent line.
If necessary, unlock quick-release fastener (3) for fuel feed line of independent heating and detach.
If necessary, disconnect plug connection (4) for independent heating fuel pump.
Lever out remainder of torque break off head (1) with a screwdriver in direction of arrow.
Release hose clip of clamping ring (2) completely.
Note. A flexible extension can be used to release the hose clamp, e.g. special tool 00 9 252.
Press clamping ring (2) part at open end in direction of arrow and remove.
Installation
Make sure that service cover is installed in correct position.
Indentation (2) on clamping ring must line up with raised section (1) of tank.
Pin on service cover (3) must line up with indentation on clamping ring.
Hose clip with torque break off head (4) must always be replaced.
Tighten hose clip until torque break off head (4) breaks off.
Scheme 76
Installation
Seal (1) must always be replaced.
Disconnect grounding cable (1) towards top.
| IMPORTANT | Grounding cable (1) must be replaced if it has been detached once! |
Carefully raise service cover.
Unclip plastic tube (1).
Unlock and disconnect quick-connect coupling (2).
Remove fuel pump.
| IMPORTANT | Catch escaping fuel in suitable container. No fuel is permitted to get into the interior! |
With fuel pump remove, disconnect plug connection (1) and replace grounding cable (2).
16 14 060 Removing and Installing/Replacing Dust Filter for Tank Leak Diagnosis Module (DMTL)
Necessary preliminary tasks
- Remove rear right wheel arch trim. See «51 71 041 REMOVING AND INSTALLING/REPLACING REAR LEFT OR RIGHT WHEEL ARCH COVER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-041-removing-and-installingreplacing)
Unlock and disconnect quick-connect coupling (1).
Release screws (2) and remove dust filter (3).
Scheme 77
16 14 500 Removing and Installing or Replacing Control Unit For Electric Fuel Pump
| IMPORTANT | Read and comply with notes on protection against electrostatic damage (ESD protection). See 61 35... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE) . |
Necessary preliminary tasks
- Raise luggage compartment floor trim
Release screws (1) and remove battery cover towards top.
Unlock plug connections (1) and disconnect.
Release nuts (2) and remove control unit.
(Internal nut must only be slackened).
Installation
Tightening torque 16 14 1AZ. See 16 14 FUEL PUMP .
Replacement
- Carry out programming/coding. See «CODING & PROGRAMMING»(ref-232774-S42919497512006052200000)
See also:
• 16 1 080 HOSE GUIDE
• 13 3 010 HOSE CLIP
• 16 1 070 PLUG (CARBON CANISTER)
• 16 1 170 TESTER WITH TEST ADAPTER
• 00 ... ... LIFTING VEHICLE WITH A LIFTING PLATFORM
• 51 47 ... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELLING
• 16 11 FUEL TANK AND MOUNTING PARTS
• 26 11 000 REMOVING AND INSTALLING PROPELLER SHAFT (INSERTED) COMPLETELY
• 51 71 041 REMOVING AND INSTALLING/REPLACING REAR LEFT OR RIGHT WHEEL ARCH COVER
• 16 12 FUEL DELIVERY
• 30 3RD SEAT ROW
• 52 26 005 REMOVING AND INSTALLING / REPLACING REAR SEAT
• 16 13 TANK VENTILATION
• 13 FUEL VENTILATION
• 61 35... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE)
• 16 14 FUEL PUMP
• 16 00 005 Draining and Filling Fuel Tank
• 16 14 060 Removing and Installing/Replacing Dust Filter for Tank Leak Diagnosis Module (DMTL)
• 16 13 015 Removing and Installing/Replacing Tank Leak Diagnosis Module (petrol/Gasoline Cars with US DMTL version)
• 16 12 010 Removing and Installing/Replacing Carbon Canister (US Version with DMTL)
• 16 14 010 Removing and Installing/Replacing Fuel Pump (Petrol/Gasoline Vehicles)
• 16 11 060 Removing and Installing Or Replacing Fuel Filler Pipe
• 16 14 500 Removing and Installing or Replacing Control Unit For Electric Fuel Pump
• 16 12 001 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Left)
• 16 11 030 Removing and Installing/Replacing Fuel Tank
• 16 11 ... Replacing Left Or Right Clamping Band For Fuel Tank
• 16 00 100 Checking Fuel Tank And Tank Ventilation System For Leaks
• 16 00 102 Checking Fuel Tank And Tank Venting System For Leaks With Tank Leakage Diagnosis Module (DM-TL)
• 16 00 510 Conducting Leak Test On Fuel Tank And Tank Ventilation System
• 16 11 130 Checking Filler Cap Pressure Relief Valve
• 16 12 000 Removing and Installing or Replacing Fuel Gauge Sensor (Petrol/Gasoline, Right)
• 16 12 ... Checking repumping function of suction - jet pump with BMW Diagnosis System
