Scheme 1
The opening screen when CIP is started.
Choose which vehicle you will be programming.
Scheme 2
Scheme 3
Select depending upon programming required.
To retrofit select Load SW.
To update a vehicle select Vehicle.
Selecting Vehicle will ensure that complete encoding is performed.
Scheme 4
Regardless of whether you have selected Load SW or Vehicle, the VO will be determined.
Scheme 5
A YES selection will lead you to choose which control module(s) have been replaced.
A NO selection will lead you to Retrofits .
Scheme 6
After selecting YES fitted control modules will be determined.
Scheme 7
After determining the fitted modules, a measures plan will be made. At this point you will be notified if control modules need to be replaced.
Control module replacement is required if the hardware level in a module can not be upgraded to a high enough software level.
In the case above no modules need replacement, in fact on the DSC needs to be reprogrammed.
Scheme 8
DSC programming is being carried out.
Scheme 9
If you selected no earlier (Have any control modules been replaced?) you would come to this screen.
Here selections to reprogram individual modules can be made or entry into retrofit programming.
Scheme 10
Selecting retrofit on the previous screen brings you here.
More selections (such as mobile phone USA) are on the next page, accessed by pressing retrofits on bottom of selection list.
Scheme 11
Select the retrofit, in this case the Mobile phone USA.
Scheme 12
You will be asked which battery the car has installed.
Scheme 13
A measures plan will be determined and displayed to accomplish the retrofit.
Press Accept.
Scheme 14
The retrofit is being carried out.
Scheme 15
By selecting Vehicle initially when entering CIP, you will save time when updating the vehicle.
Updating through Load SW differs from Measures Plan determined through Vehicle.
When updating through Load SW only the module programmed is re-coded. You still need to come to this screen and perform Complete Encoding.
By updating through Vehicle, the entire car is automatically encoded, after the programming is complete.
Scheme 16
Press start to begin the programming and encoding procedure.
