Oil pump and oil scraper - two parts
Release screws and remove oil pump intake pipe.
Scheme 1186
Release screws and remove oil pump.
Scheme 1187
Installation
Check dowel sleeves (1) for damage and correct installation position.
Scheme 1188
Installation
Replace O -ring on intake pipe.
Scheme 1189
If necessary, remove control piston.
Press sleeve downwards with suitable drift.
| CAUTION | The sleeve for the control plunger is under spring pressure. |
Remove circlip.
Scheme 1190
Installation
Scheme 1191
- Control plunger
- Spring
- Sleeve
- O-ring (replace)
- Circlip
