WHEEL ALIGNMENT SPECIFICATIONS & PROCEDURES
Note. See appropriate SPECIFICATIONS & PROCEDURES article in WHEEL ALIGNMENT.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||
|---|---|---|---|
| Control Arm Holder To Front Axle Support | 74 (100) (1) | ||
| Control Arm On Steering Knuckle/Swivel Bearing | 59 (80) | ||
| Front Axle Support To Engine Support | |||
| 10 mm Bolts | |||
| 8.8 Thread | 31 (42) | ||
| 9.8 Thread | 35 (47) | ||
| 12 mm Bolts | |||
| 8.8 Thread | 57 (77) | ||
| 10.9 Thread | 81 (110) | ||
| 12.9 Thread | 77 (105) | ||
| Guide Joint To Swivel Bearing | 44 (60) | ||
| Guide Joint To Tension Strut | 59 (80) | ||
| Piston Rod On Thrust Bearing | 47 (64) | ||
| Reinforcement Plate To Front Axle Support/Engine Carrier | 41 (56) | ||
| Spring Strut Mount To Wheel Arch | |||
| 18 mm | 18 (24) | ||
| 21 mm | 25 (34) | ||
| Spring Strut Shock Absorber To Pivot Mount | 184 (250) | ||
| Stabilizer Link On Spring Strut Shock Absorber & Stabilizer | 74 (100) | ||
| Steering Gear Banjo Bolts | |||
| 10 mm | 10 (12) | ||
| 14 mm | 30 (35) | ||
| 16 mm | 35 (40) | ||
| 18 mm | 39 (45) | ||
| Cap Screw | 310 (36) | ||
| Steering Gear Clamp | |||
| Aluminum Joint | 21 (28) | ||
| Steel Joint | 18 (24) | ||
| Steering Gear To Front Axle Support | 74 (100) | ||
| Tension Strut To Front Axle Support | 122 (165) | ||
| Tie Rod End Nut | 59 (80) | ||
| Wheel Hub Collar Nut | 214 (290) | ||
| Wheel Lug Bolts | 81-96 (110-130) | ||
| (1) Torque Angle is 75-105 degrees | |||
| (1) | Torque Angle is 75-105 degrees |
TORQUE SPECIFICATIONS (3-SERIES)
