36 1 010 Spring lifter
Note. For lifting retaining spring when removing and installing balance weight
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E83, E85, E87, E90
Storage location: A28
SI number: 1 01 96(034)
Order number: 36 1 010
Spring lifter
Scheme 96
36 1 020 Tire pliers
Note. For compressing sides of tires when removing and installing retaining spring
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E83, E85, E87, E90
SI number: 1 01 96(034)
Order number: 36 1 020
Tire pliers
Scheme 97
36 1 030 Tester
Note. For measuring vertical and lateral runout of wheels
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, R50, R52, R53, RR1
SI number: 1 11 00(594)
Order number: 36 1 030
Tester
Consisting of
1 = 36 1 031 Pedestal
2 = 36 1 032 Post with clamp
3 = 36 1 033 Holder with clamp
4 = 36 1 034 Clamp
5 = 36 1 035 Measuring roller
6 = 36 1 036 Dial gauge
Scheme 98
36 1 040 Scraper
Note. For removing stick-on weights from aluminum rims
Series: All models
Storage location: Single
SI number: 1 13 00(596)
Order number: 36 1 040
Scraper
Scheme 99
36 1 250 Wheel hub grinder
Note. For cleaning wheel hubs
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, R50, R52, R53
SI number: 1 15 03 (005)
Order number: 36 1 250
Wheel hub grinder
Consisting of
1 = 36 1 251 Basic body
Note. Basic body with mounting screws (slotted pan-head screw)
2 = 36 1 252 Grinding wheel
3 = 36 1 253 Slotted pan-head screw (3 x)
Note. For securing grinding wheel on basic body
Scheme 100
Minimum set: Mechanical tools
Note. For loosening and tightening wheel studs (antitheft)
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, R50, R52, R53
SI number: 1 27 04 (167)
Order number: 36 1 300
Set of wheel stud adapters
Consisting of
36 1 301 Code 11
36 1 302 Code 12
36 1 303 Code 13
36 1 304 Code 14
36 1 306 Code 16
36 1 307 Code 17
36 1 308 Code 18
36 1 309 Code 19
36 1 311 Code 20
36 1 312 Code 31
Note. Replaced by 36 1 324, 12/2004
36 1 313 Code 32
Note. Replaced by 36 1 325, 12/2004
36 1 314 Code 33
Note. Replaced by 36 1 326, 12/2004
36 1 315 Code 34
Note. Replaced by 36 1 327, 12/2004
36 1 316 Code 35
Note. Replaced by 36 1 328, 12/2004
36 1 317 Code 36
Note. Replaced by 36 1 329, 12/2004
36 1 318 Code 37
Note. Replaced by 36 1 331, 12/2004
36 1 319 Code 38
Note. Replaced by 36 1 332, 12/2004
36 1 321 Code 39
Note. Replaced by 36 1 323 Code 30, 12/2004
36 1 322 Code 40
Note. Replaced by 36 1 333, 12/2004
36 1 305 Code 15
