RADIAL SHAFT SEAL FOR DRIVE FLANGE (500 X-DRIVE)
Note. Numbers in text refer to numbers in figures.
Remove transfer case. See TRANSFER CASE - REMOVAL & INSTALLATION article.
Drive a hole into radial shaft seal (2) using a center punch (1). (Scheme 31) Do not use a drill as drillings may result in transmission malfunction.
Scheme 31
Screw in special tool (23 0 490). Drive out radial shaft seal (1) with impact weight (2). (Scheme 32)
Scheme 32
Drive in radial shaft seal with special tool (27 1 390). (Scheme 33)
Scheme 33
Add final details to vehicle. Check oil level. Check transmission for leaks.
RADIAL SHAFT SEAL FOR DRIVE FLANGE (NV125/LWX-500)
Note. Numbers in text refer to numbers in figures.
Remove transfer case. See TRANSFER CASE - REMOVAL & INSTALLATION article.
On NV125 transmission, remove shaft (1) (adapter) in direction of arrow. (Scheme 34)
Scheme 34
Drive a hole into radial shaft seal (2) using a center punch (1). (Scheme 35) Do not use a drill as drillings may result in transmission malfunction.
Scheme 35
Install special tool (23 0 490). Drive out radial shaft seal (1) with impact weight (2). (Scheme 36)
Scheme 36
On NV25 transmission, drive in radial shaft seal with special tools (27 1 360) and (00 5 500). (Scheme 37)
Scheme 37
On LWX-500 transmission, drive in radial shaft seal with special tool (27 1 370). (Scheme 38) Add final details to vehicle. Check oil level. Check transmission for leaks.
Scheme 38
27 21 020 RADIAL SHAFT SEAL FOR OUTPUT FLANGE (500 X-DRIVE)
Note. Numbers in text refer to numbers in figures.
Remove propeller shaft from transmission. Release centre bearing. Tie propeller shaft to one side. See 26 11 000 REMOVING AND INSTALLING COMPLETE PROPELLER SHAFT .
Release retaining ring (1). (Scheme 39)
Scheme 39
Remove drive flange with special tool (33 1 150). (Scheme 40)
Scheme 40
NOTE: During installation, replace "O" ring (1) in output flange. Check that "O" ring (1) is in correct position. (Scheme 41) Note that propeller shaft may move when the output flange is pushed on. The retaining ring can therefore no longer be fitted.
Scheme 41
To install version with mounting groove on output shaft (1), push on output flange. (Scheme 42)
Scheme 42
Using 2 screwdrivers, press output flange downward or output shaft (2) upwards until groove for retaining is completely visible. Fit retaining ring.
To install version without mounting groove on output shaft, support transfer box with a suitable sleeve (1) on transmission input shaft (2). (Scheme 43)
Scheme 43
Push on output flange. Fit retaining ring. Drive a hole into radial shaft seal (2) using a center punch (1). (Scheme 44) Do not use a drill as drillings may result in transmission malfunction.
Scheme 44
Screw in special tool (23 0 490). Drive out radial shaft seal (1) with impact weight (2). (Scheme 45)
Scheme 45
Drive in radial shaft seal with special tool (27 1 400). (Scheme 46)
Scheme 46
Add final details to vehicle. Check oil level. Check transmission for leaks.
RADIAL SHAFT SEAL FOR OUTPUT FLANGE (NV125/LWX-500)
Note. Numbers in text refer to numbers in figures.
Remove exhaust system. See EXHAUST SYSTEM . Detach propeller shaft at transfer case. SeeDRIVE SHAFTS & UNIVERSAL JOINTS article.
Secure output flange with special tool (23 0 020). Release nut (1) with special tool (23 2 320). During installation, replace nut (1). (Scheme 47)
Scheme 47
Secure nut (1) at points (2). Remove drive flange with special tool (33 1 150). see scheme 18
Drive a hole into radial shaft seal (2) using a center punch (1). (Scheme 48)
Scheme 48
Do not use a drill as drillings may result in transmission malfunction. Install special tool (23 0 490). Drive out radial shaft seal (1) with impact weight (2). (Scheme 49)
Scheme 49
Drive in radial shaft seal with special tool (27 1 380). (Scheme 50) During installation, radial shaft seal must rest flush on housing. Add final details to vehicle. Check oil level. Check transmission for leaks.
Scheme 50
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Drain Plug | 24 (33) |
| Servomotor To Transfer Box | 16 (22) |
| Transfer Box To Transmission | 32 (43) |
| Transmission Crossmember To Rubber Mounts | 55 (74) |
| Transmission Crossmember To Body | 30 (41) |
| Vibration Damper To Transfer Box | 17 (23) |
| INCH Lbs. (N.m) | |
| Resistor To Transfer Case | 17-44 (2-5) |
