Note. This information is intended as a quick reference for firing order and cylinder identification only. The information provided covers many vehicles and may include some information that does not apply to the vehicle you have currently selected.
4 CYLINDER ENGINE
Engine Configuation Firing Order Cylinder Identification In-Line 4 1-3-4-2
Scheme 11
6 CYLINDER ENGINE
Engine Configuation Firing Order Cylinder Identification In-Line 6 1-5-3-6-2-4
Scheme 12
V8 ENGINE
Engine Configuation Firing Order Cylinder Identification V8 1-5-4-8-6-3-7-2
Scheme 13
V10 ENGINE
Engine Configuation Firing Order Cylinder Identification V10 1-6-5-10-2-7-3-8-4-9
Scheme 14
V12 ENGINE
Engine Configuation Firing Order Cylinder Identification V12 1-7-5-11-3-9-6-12-2-8-4-10
