Fuses & Circuit Breakers - e53 BMW X5 E53

Fuses & Circuit Breakers 10 illustrations ~386 words

DESCRIPTION

WARNINGVehicles are equipped with air bag supplemental restraint system. Before attempting any repairs involving steering column, instrument panel or related components, see AIR BAG SAFETY PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in appropriate AIR BAG DEACTIVATION PROCEDURES article.
CAUTIONWhen battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See appropriate COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. Obtain radio code card from customer. Note stored stations and restore them after connecting battery. Stored settings of on-board computer and clock will also be lost. All available central keys must be recoded for cars with first generation infrared transmitter locking systems.

ENGINE COMPARTMENT

For location of engine compartment fuse holder A6009 (in Integrated Supply Module) (Scheme 24)

Engine compartment fuses are protection for

  1. F001: 30A - Fuel injectors (5-8), Variable valve timing gear control unit, DME control unit.
  2. F002: 20A - Charcoal filter valve, Camshaft sensor (inlet), Camshaft sensor (exhaust), VANOS intake solenoid valve (cyl.bank 2), VANOS exhaust solenoid valve (cyl.bank 2).
  3. F003: 20A - Ignition coils (1-4).
  4. F004: 20A - Ignition coils (5-8).
  5. F005: 30A - Crankshaft sensor, Hot-film air mass meter, Camshaft sensor (inlet), Camshaft sensor (exhaust), Characteristic map (cooling), VANOS intake solenoid valve (cyl.bank 1), VANOS exhaust solenoid valve (cyl.bank 1).
  6. F006: 20A - Fuel injectors (1-4).
  7. F007: 20A - Transmission control.
  8. F008: 30A - Heated oxygen sensors, Oil quality sensor.
  9. F009: 10A - Fuse 51 (in front fuse holder A46 in passenger compartment), Fuel pump relay 1.
  10. F010: 40A - Variable valve timing gear control unit
  11. F011: 40A - Variable valve timing gear control unit.

Scheme 24

Scheme 24
Scheme 24

PASSENGER COMPARTMENT

For passenger compartment fuse holder A46 location (Scheme 25) For amperage and components covered (Scheme 26)through (Scheme 28)

Scheme 25

Scheme 25: PASSENGER COMPARTMENT
Scheme 25: PASSENGER COMPARTMENT

Note. The fuse assignments below are based on vehicle manufacture dates given by BMW. Use the vehicle's VIN code to determine the correct set of fuse assignments.

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Rear Fuse Carrier

Note. Rear fuse carrier is located in luggage compartment, at the RH panel. (Scheme 29)

For amperage and components covered (Scheme 30)through (Scheme 32)

Scheme 29

Scheme 29: Rear Fuse Carrier
Scheme 29: Rear Fuse Carrier

Note. The fuse assignments below are based on vehicle manufacture dates given by BMW. Use the vehicle's VIN code to determine the correct set of fuse assignments.

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Battery Supply Distribution Fuses

Battery supply distribution fuse panel is located in luggage compartment, on the left. (Scheme 33)

Battery supply distribution fuses are protection for

  1. F200: 200A - Passenger compartment fuse carrier A46.
  2. F201: 50A - Trailer module (AHM)
  3. F202: 80A - Luggage compartment fuse carrier fuses (F83-F87)
  4. F203: 100A - DDE relay
  5. F204: 50A - Air suspension compressor relay
  6. F205: 40A - Transfer box control unit
  7. F206: 80A - Luggage compartment fuse carrier fuses (F77-F81)
  8. F207: 80A - Luggage compartment fuse carrier fuses (F72-F75)

Scheme 33

Scheme 33
Scheme 33

WIRING DIAGRAMS

Note. For wiring diagrams, see appropriate SYSTEMS WIRING DIAGRAM article in ELECTRICAL.
