Fuel Injector Volume Adjustment
Piezo-fuel injectors not only bear the hydraulic tolerances but also information concerning the stroke characteristics of the injector. This is a separate classification for the injector voltage calibration.
This information is necessary due to the individual voltage requirement of each fuel injector. The fuel injector is assigned to a voltage requirement class. This replaces the seventh digit of the numerical combination on the injector for hydraulic adjustment.
A piezo-fuel injector therefore has only six characters for the hydraulic adjustment (due to a more precise manufacture of the piezo-fuel injectors) and a seventh character for the injector voltage adjustment.
Scheme 290
| Index | Explanation |
|---|---|
| 1 | 7 Character code for adjustment |
| 2 | Voltage adjustment |
INDEX EXPLANATION CHART
Volume Adjustment
If the digital diesel electronics detects engine speed fluctuations, the actuation period of the fuel injectors is corrected based on these engine speed fluctuations. The volume adjustment adapts the injected volume of all cylinders with respect to each other.
