Wiring diagram: Computer data lines — Computer data lines circuit BMW X4 G02
All systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers 3
- Electronic power steering
- Electronic suspension 2
- Engine performance 2.0l turbo
- Engine performance 3.0l turbo
- Exterior lights 3
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 4
- Navigation 15
- Passive restraints
- Power distribution
- Power door locks
- Power mirrors
- Power seats 10
- Power top/sunroof
- Power windows
- Radio 10
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 3
- Trunk, tailgate, fuel door 2
- Warning systems
- Wiper/washer
Computer data lines circuit (1 of 9) BMW X4 G02
Components on the diagram
Computer data lines circuit (2 of 9) BMW X4 G02
Components on the diagram
Computer data lines circuit (3 of 9) BMW X4 G02
Components on the diagram
Computer data lines circuit (4 of 9) BMW X4 G02
Components on the diagram
Computer data lines circuit (5 of 9) BMW X4 G02
Components on the diagram
Computer data lines circuit (6 of 9) BMW X4 G02
Components on the diagram
Computer data lines circuit (7 of 9) BMW X4 G02
Components on the diagram
Computer data lines circuit (8 of 9) BMW X4 G02
Components on the diagram
Computer data lines circuit (9 of 9) BMW X4 G02
