11 00 670 Securing engine in installation position (N52)
Special tools required
- «00 0 200 CROSS MEMBER»(ref-202720-S06782589052005102800000)
- 00 0 202
- 00 0 204
- 00 0 208
- 11 0 000
| WARNING | Danger of injury! Observe following instructions relating to special tool: Prior to each use, check the special tools for defects, modifications and operational reliability. Damaged/modified special tools must not be used! No changes or modifications may be made to the special tools! Keep special tools dry, clean and free of grease. |
Necessary preliminary tasks
- Secure engine bonnet/hood in service position, see «51 00 ... SERVICE POSITION OF ENGINE HOOD/BONNET (X3)»(ref-264509-S01183822762007091500000) or «51 00 ... SERVICE POSITION OF ENGINE HOOD/BONNET 9X5)»(ref-264848-S40400276242007091800000) .
- Remove cover for windscreen cowl panel, see «51 13 115 REMOVING AND INSTALLING/REPLACING COWL PANEL COVER (X3)»(ref-264509-S20402278472007091500000) or «51 13 116 REMOVING AND INSTALLING/REPLACING COWL PANEL COVER (X5)»(ref-264848-S38904187442007091800000) .
- Remove microfilter housing
- Remove tension strut on spring strut dome, see «51 71 373 REMOVING AND INSTALLING/REPLACING TENSION STRUT ON SPRING STRUT DOME (X3)»(ref-264509-S32368375752007091500000) or «51 71 372 REMOVING AND INSTALLING/REPLACING BOTH TENSION STRUTS ON SPRING STRUT DOMES (X5)»(ref-264848-S02049250662007091800000) .
- Remove acoustic cover
- Remove intake filter housing with rubber gaiter, see «13 71 000 REMOVING AND INSTALLING/REPLACING INTAKE FILTER HOUSING (N52K) (X3)»(ref-264491-S18207133492007091500000) or «13 71 000 REMOVING AND INSTALLING/REPLACING INTAKE FILTER HOUSING (N52K) (X5)»(ref-264831-S42748658632007091800000) .
Assemble cross member 00 0 200 with special tools 00 0 202 , 00 0 204 , 00 0 208 .
Scheme 126
Note. Use towing hook (72 15 8 108 670).
Scheme 127
Cut open cable tie (2).
Detach quick-release fastener (1) and place vent line (3) to one side.
Installation
Make sure the quick-release fastener is fitted correctly.
Scheme 128
| IMPORTANT | Avoid a change of engine position in the transverse or longitudinal direction. Always make sure there is sufficient clearance between the engine (or its attachment parts) and the body. |
| IMPORTANT | Risk of damage! With the aid of an assistant and the supports (1), place cross member 00 0 200 on the screw connections of the side panels. |
Screw in towing hook (2) and tighten down to approx. 30 Nm.
Secure special tool 11 0 000 to spindle 00 0 202 .
Fit suitable chains to special tool 11 0 000 and attach to towing hook (2) or engine lifting eye.
Scheme 129
| WARNING | Danger of injury! Tighten down all adjusting screws and nuts on cross member 00 0 200 . |
Unscrew nuts (1).
Raise engine approx. 10 mm with cross member.
Installation
Replace self-locking nuts.
Tightening torque: 22 11 2AZ, see 22 11 ENGINE SUSPENSION .
