ENGINE ELECTRONICS FUSE CARRIER

Engine electronics fuse carrier (A8680 or A6009) is located in left rear of engine compartment. (Scheme 1)

Scheme 1

FRONT FUSE HOLDER

For location of front fuse holder and power distribution (A41) (Scheme 2)

For amperage and components covered (Scheme 3)or (Scheme 4).

Scheme 2

Scheme 3

Scheme 4

POWER DISTRIBUTION

For location of power distribution (A41) (Scheme 2) Power distribution contains the following fuses

1. F102 - 80 Amp - B+ Potential Distributor
2. F104 - 100 Amp - Preheating Control Module
3. F105 - 50 Amp - Ignition Switch
4. F106 - 50 Amp - Light Switch Cluster, Ignition Switch
5. F107 - 50 Amp - Light Switch Cluster, Trailer Module

REAR FUSE BOX (A400)

For location (Scheme 5) Rear fuse box (A400) contains the following fuses

1. F108 - 250 Amp - Power Distribution
2. F109 - 60 Amp - Rear Fuse Holder

Scheme 5

REAR FUSE HOLDER (A49)

For location (Scheme 6) Rear fuse holder (A49) contains the following fuses

1. F80 - 30 Amp - Transfer Box Control Module
2. F81 - 30 Amp - Amplifier

Scheme 6
