24 0 010 Fixture
In conjunction with: 00 2 510
Note: For checking axial play of drive shaft
Transmission: 4 HP 22, 4 HP 24, A5S 310Z, A5S 560Z
Storage location: B23
Order number: 24 0 010
Fixture
Consisting of
1 = 24 0 011 Dial gauge holder
2 = 24 0 012 Clamping piece
Scheme 305
24 0 030 Adapter
In conjunction with: 13 3 061, 24 0 021, 24 0 023
Note: For pressure gauge 13 3 061 / For checking converter pressure
Transmission: 4 HP 22
Storage location: B23
Order number: 24 0 030
Adapter
Scheme 306
24 0 040 Retaining Fixture
Note: For removing and installing disc pack
Transmission: 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location: C27
Order number: 24 0 040
Retaining fixture
Consisting of
1 = 24 0 041 Disc
2 = 24 0 042 Ring
3 = 24 0 043 Half shells
Scheme 307
24 0 050 Extractor Grip
Note: For sealing plug in bottom section of transmission casing
Transmission: 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location: A24
Order number: 24 0 050
Extractor grip
Scheme 308
24 0 070 Adapter
In conjunction with: 13 3 061 (pressure gauge), 24 0 021, 24 0 023
Note: For checking pump pressure
Transmission: 4 HP 22, 4 HP 24
Storage location: B23
Order number: 24 0 070
Adapter
Scheme 309
24 0 080 Funnel
Minimum set: Mechanical tools
Note: For filling transmission fluid in transmission
Transmission: 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S6S 420G, S6S 560G, ZF S5-16
Order number: 24 0 080
Funnel
Scheme 310
24 0 090 Drift
Note: For driving in radial seal in transmission case front section / Replaced by 24 0 110, November 96
Transmission: 4 HP 22, 4 HP 24
Order number: 24 0 090
Drift
Scheme 311
24 0 120 Attachment For Trolley
Note: For removing and installing transmission / Replaced by 24 0 130, March 87
Transmission: 4 HP 22
Order number: 24 0 120
Attachment for trolley
24 0 130 Take-Up Support For Transmission
In conjunction with: 00 2 030 (not included in minimum kit)
Note: For removal and installation
Transmission: 4 HP 22, 4 HP 24
SI number: 1 02 87(721)
Order number: 24 0 130
Take-up support for transmission
Scheme 312
24 0 140 Pipe Manifold
Minimum set: Mechanical tools
In conjunction with: 13 3 061, 24 0 021, 24 0 022, 13 6 051, 13 6 052, 24 5 190
Note: For pressure gauge 13 3 061 and BMW DIS for measuring oil pressure in transmission
Transmission: A4S 270R, A4S 310R, A5S 310Z, A5S 560Z
Storage location: C3
SI number: 1 01 92(469)
Order number: 24 0 140
Pipe manifold
Scheme 313
24 0 150 Mounting Bracket
In conjunction with: 00 1 450
Note: For mounting transmission on assembly stand
Transmission: 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, A4S 270R, A4S 310R, A5S 310Z
Order number: 24 0 150
Mounting bracket
Consisting of
2 = 24 0 152 Baseframe
3 = 24 0 153 Spindle with rotary handle
6 = 24 0 156 Spindle
Note: With thrust piece, transmission: all
In conjunction with: 00 1 450
Scheme 314
24 0 170 Support
In conjunction with: 00 2 030 (not included in minimum kit)
Note: For removing and installing transmission
Transmission: A5S 560Z
SI number: 1 06 92(509)
Order number: 24 0 170
Support
Consisting of
24 0 171 Adjusting screw
Scheme 315
24 0 180 Support
In conjunction with: 00 1 450
Note: For mounting transmission on assembly stand.
Transmission: A5S 310Z, A5S 325Z, A5S 360R, A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z
SI number: 1 06 92 (509)
Order number: 24 0 180
Support
Consisting of
1 = 24 0 181 Baseframe
2 = 24 0 182 Pressure spindle with star handle
4 = 24 0 184 Spindle, long (2 x)
5 = 24 0 185 Adapter
Scheme 316
24 0 190 Holding Fixture
Minimum set: Mechanical tools
Note: For output flange of propeller shaft while releasing and tightening slotted nut
Transmission: A5S 310Z, A5S 325Z, A5S 360R, A5S 560Z
SI number: 1 06 92(509)
Order number: 24 0 190
Holding fixture
Scheme 317
24 0 200 Support
In conjunction with: 00 1 450
Note: For mounting transmission on assembly stand.
Transmission: A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z
SI number: 1 27 06 (328)
Order number: 24 0 200
Support
Consisting of
1 = 24 0 201 Basic body
2 = 24 0 202 Spindle with thrust member
3 = 24 0 203 Spindle with screw
4 = 24 0 204 Sliding piece
5 = 24 0 205 Adapter (long)
6 = 24 0 206 Adapter (medium)
7 = 24 0 207 Adapter (short)
Scheme 318
24 0 250 Take-Up Support For Transmission
In conjunction with: 24 5 301 and 00 2 030 (not included in minimum tool kit)
Note: For removing and installing transmission.
Transmission: A5S 440Z
SI number: 1 08 96(080)
Order number: 24 0 250
Take-up support for transmission
Scheme 319
24 1 050 Impact Bush
Note: For fitting rotary shaft seal for torque converter in oil pump housing
Transmission: 3 HP 20, 3 HP 22
Storage location: C29
Order number: 24 1 050
Impact bush
Scheme 320
24 1 060 Impact Bush
Note: For fitting rotary shaft seal for torque converter in oil pump housing and on output flange
Transmission: 3 HP 20, 3 HP 22, A5S 300J, BW 65
Storage location: B29, C29
Order number: 24 1 060
Impact bush
Scheme 321
24 1 070 Impact Bush
Minimum set: Mechanical tools
Note: For fitting rotary shaft seal in oil pump housing
Transmission: A5S 325Z
Storage location: B36
SI number: 1 03 98(303)
Order number: 24 1 070
Impact bush
Scheme 322
24 1 080 Bush (Aluminium)
Minimum set: Mechanical tools
In conjunction with: 00 5 010
Note: For fitting on input shaft while removing rotary shaft seal from oil pump housing
Transmission: A5S 325Z
Storage location: A36
SI number: 1 03 98(303)
Order number: 24 1 080
Bush (aluminium)
Scheme 323
24 1 090 Impact Bush
Note: For installing rotary shaft seal on output flange
Transmission: A5S 390G
SI number: 1 08 98(333)
Order number: 24 1 090
Impact bush
Scheme 324
24 1 100 Impact Bush
Note: For fitting rotary shaft seal for output flange in transmission extension
Transmission: 3 HP 12, 3 HP 20, 3 HP 22
Order number: 24 1 100
Impact bush
Scheme 325
24 1 110 Socket With Magnet
Minimum set: Mechanical tools
Note: For loosening and tightening converter mounting
Transmission: 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 200R, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 390R, A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z
Storage location: B19
SI number: 1 04 86 (566)
Order number: 24 1 110
Socket with magnet
Scheme 326
24 1 120 Gauge
Note: For adjusting position switch in "P" position during assembly / Model year: As from 03/96
Transmission: A4S 270R
SI number: 1 07 96(068)
Order number: 24 1 120
Gauge
Scheme 327
24 1 170 Pin Wrench
Minimum set: Mechanical tools
Note: For releasing and tightening slotted nut on output flange
Transmission: A5S 310Z
Storage location: A35
SI number: 1 09 90(282)
Order number: 24 1 170
Pin wrench
Scheme 328
24 1 180 Fixture
In conjunction with: 24 1 080 (A5S 325Z)
Note: For removing and installing oil pump
Transmission: A5S 310Z, A5S 560Z
Storage location: B18
SI number: 1 09 90(282)
Order number: 24 1 180
Fixture
Consisting of
1 = 24 1 181 Retaining tube
2 = 24 1 182 Thread spindle
3 = 24 1 183 Retaining ring, inner
Note: (not shown)
Scheme 329
24 1 190 Drift
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note: For fitting rotary shaft seal in front section of transmission casing
Transmission: A5S 310Z
Storage location: B28
SI number: 1 09 90(282)
Order number: 24 1 190
Drift
Scheme 330
24 1 210 Retaining Plate For Disc Package
Note: Not required as from transmission No. 11 2 300
Transmission: A5S 310Z
Storage location: B22
SI number: 1 09 90(282)
Order number: 24 1 210
Retaining plate for disc package
Scheme 331
24 1 220 Take-Up Support For Drive Flange
In conjunction with: 24 1 170 (A5S 310Z), 24 4 110 (A5S 440Z)
Note: When loosening slotted nut
Transmission: A5S 310Z, A5S 440Z
SI number: 1 09 90(282)
Order number: 24 1 220
Take-up support for drive flange
Scheme 332
24 1 230 Pressing Tool
Note: For removing and installing piston (cover) on brake Ct
Transmission: A5S 310Z
Storage location: B20
SI number: 1 14 93(718)
Order number: 24 1 230
Pressing tool
Scheme 333
24 1 240 Measuring Device
Note: For determining spacers on brake C
Transmission: A5S 310Z
Storage location: B20
SI number: 1 14 93(718)
Order number: 24 1 240
Measuring device
Scheme 334
24 1 250 Lifting Gear
Note: For removing and installing brake clutch unit D/G incl. sprag wheel
Transmission: A5S 310Z
Storage location: B11, C11
SI number: 1 14 93(718)
Order number: 24 1 250
Lifting gear
Scheme 335
24 1 290 Wedges
Note: For fixing disc pack C in position while securing retainer tabs
Transmission: A5S 560Z
Storage location: C17
SI number: 1 01 95(892)
Order number: 24 1 290
Wedges
Scheme 336
24 1 300 Impact Tool
Note: For securing retainer tabs on disc pack C
Transmission: A5S 560Z
Storage location: C17
SI number: 1 01 95(892)
Order number: 24 1 300
Impact tool
Scheme 337
24 1 310 Releasing Tool
Note: For releasing retainer tabs on disc pack C
Transmission: A5S 560Z
Storage location: C2
SI number: 1 01 95(892)
Order number: 24 1 310
Releasing tool
Consisting of
1 = 24 1 311 Profile section (slide)
2 = 24 1 312 Basic body
Scheme 338
24 2 020 Tool
Note: For compressing disc spring
Transmission: 4 HP 22, 4 HP 24
Storage location: C32
Order number: 24 2 020
Tool
Scheme 339
24 2 030 Tool
Note: For compressing disc spring
Transmission: 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location: C32
Order number: 24 2 030
Tool
24 2 040 Tool
Note: For compressing disc spring
Transmission: 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location: C32
Order number: 24 2 040
Tool
24 2 050 Extractor Grip
Note: For sealing plugs in transmission case lower section / Replaced by 24 0 050
Order number: 24 2 050
Extractor grip
24 2 140 Tensioning Tool
Note: For removing and installing snap ring in front of centering plate of ZF transmissions
Transmission: 3 HP 12, 3 HP 20, 3 HP 22
Order number: 24 2 140
Tensioning tool
Scheme 340
24 2 310 Tool Kit For Removing And Installing Reverse Gear Piston
Note: For disassembling and assembling transmission for "Sealing intermediate plate" job
Transmission: A4S 270R, A4S 310R
SI number: 1 22 97(239)
Order number: 24 2 310
Tool kit for removing and installing reverse gear piston
Consisting of
1 = 24 2 311 Pressure plate
Note: For removing and installing spring retainer
2 = 24 2 312 Spindle with pressure plate
Note: Spindle M14x1.5, nut M14, pressure plate and washer / For removing and installing spring retainer
3 = 24 2 313 Guide pin (2)
Note: For fixing gaskets and intermediate plates on intermediate housing
4 = 24 2 314 Slip bush
Note: For removing piston in cylinder of intermediate plate
Scheme 341
24 2 320 Box Spanner
In conjunction with: 24 2 330
Note: For 3/16" socket head cap screw with 1/4" socket for adjusting brake band
Transmission: A4S 270R, A4S 310R
SI number: 1 24 97(257)
Order number: 24 2 320
Box spanner
Scheme 342
24 2 330 1/2" Open-Ended Spanner
In conjunction with: 24 2 320
Note: For adjusting brake band
Transmission: A4S 270R, A4S 310R
SI number: 1 24 97(257)
Order number: 24 2 330
1/2" open-ended spanner
Scheme 343
24 3 040 Gauge
Note: For adjusting restrictor piston when installing gearshift unit
Transmission: 3 HP 12, 3 HP 20, 3 HP 22
Order number: 24 3 040
Gauge
Scheme 344
24 3 050 Gauge
Note: For aligning hydraulic gearshift unit in transmission
Transmission: 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Order number: 24 3 050
Gauge
Scheme 345
24 3 140 Drive Bush
Note: For checking smooth movement of oil pump
Transmission: 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A5S 560Z
Storage location: A20
Order number: 24 3 140
Drive bush
Scheme 346
24 3 150 Drive Bush
Note: For checking smooth movement of oil pump
Transmission: 3 HP 20, 3 HP 22
Storage location: A20
Order number: 24 3 150
Drive bush
Scheme 347
24 4 070 Fixture
Note: For checking torque converter for leaks
Transmission: 3 HP 20, 3 HP 22, 4 HP 22
Order number: 24 4 070
Fixture
Scheme 348
24 4 080 Fixture
Note: For firmly holding torque converter in position while removing and installing transmission
Transmission: 4 HP 22, 4 HP 24
Storage location: Single
Order number: 24 4 080
Fixture
Scheme 349
24 4 090 Drift
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note: For fitting rotary shaft seal on output end
Transmission: A5S 440Z, A5S 560Z
Storage location: B28
SI number: 1 06 92(509)
Order number: 24 4 090
Drift
Scheme 350
24 4 100 Drift
Minimum set: Mechanical tools
Note: For fitting rotary shaft seal on drive side (behind converter)
Transmission: A5S 440Z, A5S 560Z
Storage location: C29
SI number: 1 06 92(509)
Order number: 24 4 100
Drift
Scheme 351
24 4 110 Spanner
Minimum set: Mechanical tools
Note: For releasing and tightening slotted nut on output flange
Transmission: A5S 440Z, A5S 560Z
Storage location: A23
SI number: 1 06 92(509)
Order number: 24 4 110
Spanner
Scheme 352
24 4 120 Fixture
Note: For firmly holding torque converter in position while removing and installing transmission.
Replaced by 24 4 130.
Order number: 24 4 120
Fixture
Scheme 353
24 4 130 Locating Tool
Minimum set: Mechanical tools
Note: For firmly holding torque converter in position while removing and installing transmission
Transmission: A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 440Z, A5S 560Z, GA6 HP26Z
Storage location: A33
SI number: 1 05 97 (181)
Order number: 24 4 130
Locating tool
Consisting of
1 = 24 4 131 Base unit
2 = 24 4 132 Blade
Note: Transmission: A5S 440Z, GA6HP26Z (N62)
3 = 24 4 133 Blade
Note: Transmission: A4S 310R and A5S 390G
4 = 24 4 134 Blade
Note: Transmission: A5S 310Z, A5S 560Z, A5S 300J and A5S 325Z
5 = 24 4 135 Blade
Note: Transmission: A5S 560Z, GA6 HP26Z (M67), GA6 HP32Z (N73)
6 = 24 4 136 Counter plate
7 = 24 4 137 Blade
Note: Transmission: A5S 360R
Scheme 354
24 4 160 Support Bracket
Minimum set: Mechanical tools
Note: For securing converter during removal and installation of transmission
Series: E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E87, E90, E92, RR1
Transmission: GA6 HP19Z, GA6 HP26Z, GA6 HP32Z
Storage location: A47, C46
SI number: 1 11 02 (908)
Order number: 24 4 160
Support bracket
Consisting of
1 = 24 4 161 Basic body
2 = 24 4 162 Shaped section
Note: For converter variant N73
3 = 24 4 163 Shaped section
Note: For converter variant M57TU
4 = 24 4 164 Shaped section
Note: For converter variant M54
5 = 24 4 165 Shaped section
Note: Transmission: GA6 HP19 in E87, E90
Scheme 355
24 4 200 Drift And Slip Bush
Minimum set: Mechanical tools
Note: For driving in shaft seal on drive shaft.
Transmission: GACVT16Z
Order number: 24 4 200
Drift and slip bush
Consisting of
1 = 24 4 201 Drift
2 = 24 4 202 Slip bush
Scheme 356
24 4 210 Socket WAF 46
Note: For releasing and tightening down output shaft screw/bolt (bearing side).
Transmission: GACVT16Z
SI number: 1 09 05 (188)
Order number: 24 4 210
Socket WAF 46
Scheme 357
24 4 220 Extractor
Note: For removing primary bearing on drive shaft.
Transmission: GACVT16Z
SI number: 1 09 05 (188)
Order number: 24 4 220
Extractor
Consisting of
1 = 24 4 221 Basic body
2 = 24 4 222 Claws (2 x)
3 = 24 4 223 Thrust piece
4 = 24 4 224 Ring
Scheme 358
24 4 230 Drift
Note: For driving in primary bearing on drive shaft.
Transmission: GACVT16Z
SI number: 1 09 05 (188)
Order number: 24 4 230
Drift
Scheme 359
24 5 120 Tool
Note: For centering converter bell housing with respect to oil pump during assembly
Transmission: A4S 270R, A4S 310R
Storage location: B2
SI number: 1 04 95(906)
Order number: 24 5 120
Tool
Consisting of
1 = 24 5 121 Centering bush
2 = 24 5 122 Centering pin (3)
Scheme 360
24 5 140 Centering Pin
Note: For transfer plate and gasket to shift unit (2 x)
Transmission: A4S 310R
Order number: 24 5 140
Centering pin
24 5 150 Centering Pin With Thread (2)
Note: For centering gearshift unit in transmission during assembly
Transmission: A4S 270R, A4S 310R
Storage location: A2
SI number: 1 03 90(184)
Order number: 24 5 150
Centering pin with thread (2)
Scheme 361
24 5 160 Centering Pins
Note: For centering main housing with respect to intermediate and converter housing (2)
Transmission: A4S 270R, A4S 310R
Storage location: A2, B2
SI number: 1 03 93(663)
Order number: 24 5 160
Centering pins
Scheme 362
24 5 190 Adapter
In conjunction with: 13 3 061, 13 3 067, 24 0 021, 24 0 023, 24 0 140
Note: For pressure gauge 13 3 061 for checking oil pressure in transmission
Transmission: A4S 270R, A4S 310R
Storage location: C20
SI number: 1 03 90(184)
Order number: 24 5 190
Adapter
Scheme 363
24 5 200 Impact Bush
Note: For driving in radial seal of selector lever shaft / Replaced by 24 5 360
Transmission: A4S 270R, A4S 310R
SI number: 1 03 90 (184)
Order number: 24 5 200
Impact bush
Scheme 364
24 5 210 Holder
Note: For loosening and tightening gearshift cable
Transmission: 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 310Z
Storage location: B19
SI number: 1 04 91(372)
Order number: 24 5 210
Holder
Scheme 365
24 5 220 Holder
Note: For loosening and tightening gearshift cable
Transmission: A5S 300J, A5S 310Z
Storage location: B19
SI number: 1 04 91(372)
Order number: 24 5 220
Holder
Scheme 366
24 5 240 Holder
Note: For releasing and tightening gearshift cable / transmission with position switch
Transmission: A5S 310Z, A5S 560Z
Storage location: B19
SI number: 1 06 92(509)
Order number: 24 5 240
Holder
Scheme 367
24 5 250 Bush
Minimum set: Mechanical tools
In conjunction with: 24 5 490
Note: For fitting rotary shaft seal on selector shaft
Transmission: A5S 310Z, A5S 560Z
Storage location: B19
SI number: 1 02 95(896)
Order number: 24 5 250
Bush
Scheme 368
24 5 260 Extractor Tool
Minimum set: Mechanical tools
Note: For removing rotary shaft seal of selector shaft / transmission with position switch
Transmission: A5S 310Z, A5S 440Z, A5S 560Z
Storage location: B19
SI number: 1 02 95 (896)
Order number: 24 5 260
Extractor tool
Consisting of
1 = 24 5 261 Insert
2 = 24 5 262 Bushing
Scheme 369
24 5 270 Bush
Minimum set: Mechanical tools
In conjunction with: 24 5 490
Note: For fitting rotary shaft seal on selector shaft
Transmission: A5S 440Z
Storage location: B18
SI number: 1 08 96(080)
Order number: 24 5 270
Bush
Scheme 370
24 5 350 Take-Up Support For Automatic Transmission
Note: Miscellaneous: Japan and South Africa only
Transmission: A5S 300J
Order number: 24 5 350
Take-up support for automatic transmission
Scheme 371
24 5 400 Drift
In conjunction with: 00 5 500
Note: For drive shaft seal.
Transmission: GACVT16Z
Order number: 24 5 400
Drift
Scheme 372
24 5 490 Slip Sleeve (5)
Minimum set: Mechanical tools
Note: For preventing damage to rotary shaft seal while fitting on gearshift shaft
Transmission: A5S 310Z, A5S 440Z, A5S 560Z
SI number: 1 02 95 (896)
Order number: 24 5 490
Slip sleeve (5)
Scheme 373
24 8 100 Adapter
Minimum set: Mechanical tools
Note: For filling automatic transmission
Transmission: GACVT16Z
SI number: 1 05 01 (718)
Order number: 24 8 100
Adapter
Scheme 374
24 8 110 Drift
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note: For driving shaft seal onto drive flange
Transmission: GACVT16Z
SI number: 1 02 02 (823)
Order number: 24 8 110
Drift
Scheme 375
24 8 120 Rubber Profile
Minimum set: Mechanical tools
Note: For protecting shaft seal in transmission when installing output shafts.
Transmission: GACVT16Z, GS5-65BH, GS6-85BG, GS6-85DG
SI number: 1 02 02 (823)
Order number: 24 8 120
Rubber profile
Scheme 376
24 8 130 Drift
In conjunction with: 00 5 550
Note: For driving in shaft seal on input shaft. Transmission: CVT automatic transmission Replaced by 24 4 200
Transmission: GACVT16Z
SI number: 1 02 02 (823)
Order number: 24 8 130
Drift
