# Hifi radio circuit, w/o active sound design

# Hifi radio circuit, w/o active sound design (1 of 5)

Radio — Hifi radio circuit, w/o active sound design — Hifi radio circuit, w/o active sound design (1 of 5). BMW X3 M F97 (2019-2021)

Components on the diagram

# Hifi radio circuit, w/o active sound design (2 of 5)

Radio — Hifi radio circuit, w/o active sound design — Hifi radio circuit, w/o active sound design (2 of 5). BMW X3 M F97 (2019-2021)

Components on the diagram

# Hifi radio circuit, w/o active sound design (3 of 5)

Radio — Hifi radio circuit, w/o active sound design — Hifi radio circuit, w/o active sound design (3 of 5). BMW X3 M F97 (2019-2021)

Components on the diagram

# Hifi radio circuit, w/o active sound design (4 of 5)

Radio — Hifi radio circuit, w/o active sound design — Hifi radio circuit, w/o active sound design (4 of 5). BMW X3 M F97 (2019-2021)

Components on the diagram

# Hifi radio circuit, w/o active sound design (5 of 5)

Radio — Hifi radio circuit, w/o active sound design — Hifi radio circuit, w/o active sound design (5 of 5). BMW X3 M F97 (2019-2021)

Components on the diagram
