Scheme 83
- Car parked on level ground.
- Replace faulty glass and mirrors and blackened light bulbs.
- Check tyre pressure and correct if necessary.
- Apply load equivalent to one person on driver's seat (approx. 75 kg).
- Vehicle with full fuel tank or appropriate additional weight in luggage compartment.
- Correct adjustment of headlights in relation to engine hood.
- Manual headlight vertical aim control: Turn handwheel to 0 position.
- Automatic headlight vertical aim control: Wait approx. 30 seconds after switching on lights.
- Version with xenon headlights: Wait 80 seconds after switching on lights. During this time, do not move the vehicle and avoid vibrations.
- Align headlight aimer with vehicle longitudinal axis and parallel to parking surface. Set marking line (M) on aimer to distance (e). Scale graduations on aimer are equal to a gradient in cm at a distance of 10 meters.
Light/Dark Limit Of Headlights In Headlight Aimer
- e Adjustment dimension, headlights: as per type plate on headlight housing in % (e.g.: 1.0 % = 10 cm / 10 m = 10 on headlight aimer). Adjustment dimension, fog lights: all vehicles 2.0 % = 20 cm / 10 m = 20 on headlight aimer.
- H Height of center of headlight above parking surface.
- h H - e = height of marking line above parking surface
- + Central mark = center point of high-beam headlight.
- M Marking line of headlamp aimer
- S Parking surface of vehicle and headlight aimer
Adjustment dimension (e) is only valid for EUR. Observe differing national regulations.
63 10 004 Adjusting headlights
Note. Comply with Test Preconditions For Headlight Adjustment .
Adjust headlights at adjusting screws (1) and (2).
A definite allocation of adjusting screws is not possible.
Scheme 84
- Adjustment screw primarily for vertical adjustment
- Adjustment screw primarily for lateral adjustment
63 10 014 Adjusting fog lamps
Comply with Test Preconditions For Headlight Adjustment .
Adjust fog lamp (1) at adjusting screw (2).
Scheme 85
63 12 010 Removing and installing/replacing left headlight (xenon headlight)
Necessary preliminary tasks
- Remove front bumper trim . See «51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM»(ref-202134-S30125830242005102700000) .
Release screws (1) and screw (2).
Installation
Adjust headlight to fit by way of 4 screw fastening points.
Pull headlight (3) forwards slightly.
Note. Direction indicator (4) remains fitted.
Unlock associated plug connections and disconnect.
Remove headlight (3).
Scheme 86
Outer screw fastening point
- Adjust headlight (1) to fit by means of adjusting screw (2).
- Tighten retaining screw (3) while simultaneously gripping nut (4).
Installation
Scheme 87
- Adjust headlights.
Replacement
- Remove ignition unit and bulb for xenon headlight . See «63 12 870 Replacing ignition unit for left xenon headlight»(/bmw/m6/e63e64-2005-2010/remont/exterior-lights/#lights-repair__63-12-870-replacing-ignition-unit) .
- Remove control unit for xenon headlights . See «63 12 860 Replacing control unit for left xenon headlight»(/bmw/m6/e63e64-2005-2010/remont/exterior-lights/#lights-repair__63-12-860-replacing-control-unit) .
- If necessary, remove drive unit for adaptive headlight . See «63 12 895 Replacing drive for left adaptive headlight»(/bmw/m6/e63e64-2005-2010/remont/exterior-lights/#lights-repair__63-12-895-replacing-drive-for) .
63 12 012 Removing and installing right headlight (xenon headlight)
Operation is described in
63 12 015 Removing and installing left headlight (adaptive headlight)
This operation is described in
"Removing and installing left headlight ( xenon headlight ".
63 12 016 Replacing left headlight (adaptive headlight)
| IMPORTANT | Read and comply with notes on protection against electrostatic discharge (ESD protection) . See 61 35 ... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE) . |
Necessary preliminary tasks
- Remove «left headlight»(/bmw/m6/e63e64-2005-2010/remont/exterior-lights/#lights-repair__63-12-015-removing-and-installing)
- Remove drive unit for adaptive headlight . See «63 12 895 Replacing drive for left adaptive headlight»(/bmw/m6/e63e64-2005-2010/remont/exterior-lights/#lights-repair__63-12-895-replacing-drive-for) .
- Remove control unit for left xenon headlight . See «63 12 860 Replacing control unit for left xenon headlight»(/bmw/m6/e63e64-2005-2010/remont/exterior-lights/#lights-repair__63-12-860-replacing-control-unit)
- Remove bulb for left xenon headlight (ignition unit). See «63 99 076 Replacing bulb for left (or right) xenon headlight»(/bmw/m6/e63e64-2005-2010/remont/exterior-lights/#lights-repair__63-99-076-replacing-bulb-for) .
After installation
- Carry out programming/coding
- Adjust headlight
63 12 017 Removing and installing/replacing right headlight (adaptive headlight)
Operation is described in
63 12 860 Replacing control unit for left xenon headlight
| WARNING | Version with xenon headlights: Danger to life due to high voltage! Therefore disconnect all components from voltage supply before removal. Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel. |
Necessary preliminary tasks
- Remove left headlight
Release screws (1).
Remove control unit for xenon headlight (2) from headlight (3).
Scheme 88
Installation
Fit control unit for xenon headlight (3) exactly on headlight.
Make sure plug housing (1) is correctly seated on pin housing (2).
Scheme 89
63 12 861 Replacing control unit for right xenon headlight
See replacing Control Unit For Left Xenon Headlight .
63 12 870 Replacing ignition unit for left xenon headlight
| WARNING | Version with xenon headlights: Danger to life due to high voltage! Therefore disconnect all components from voltage supply before removal. Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel. |
Release screws (1).
Fold down cover (2) and remove front wheel arch trim (3).
Scheme 90
Unlock catch (1) in direction of arrow and fold down cover (2).
Remove cover (2) from headlight (3) and feed out through opening in front wheel arch trim (4).
Scheme 91
Turn ignition unit for xenon headlight (1) approx. 30 ° counterclockwise and detach from headlight (3).
Note. Plug connection (2) is automatically released by turning ignition unit for xenon headlight (1).
Feed out ignition unit for xenon headlight (1) through opening in headlight (4) and remove.
Installation
Make sure electrical leads (5) are correctly routed.
Scheme 92
63 12 871 Replacing right ignition unit for right xenon headlight
63 12 895 Replacing drive for left adaptive headlight
| IMPORTANT | Read and comply with 61 35 ... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE) . |
| WARNING | Version with xenon headlights: Danger to life due to high voltage! Therefore disconnect all components from voltage supply before removal. Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel. |
Necessary preliminary tasks
- Remove front left wheel arch cover . See «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER»(ref-202134-S23586682412005102700000) .
Release screws (1).
Remove drive for adaptive headlight (2) in direction of arrow from headlight (3).
Scheme 93
Installation
Fit drive for adaptive headlight (1) exactly on headlight.
Make sure pin housing (2) is correctly seated in plug housing (3).
Scheme 94
Carry out coding/programming .
63 12 896 Replacing drive for right adaptive headlight
63 13 150 Removing and installing/replacing complete front left turn signal lamp
Necessary preliminary tasks
- Remove front left wheel trim. See «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER»(ref-202134-S23586682412005102700000) .
Release screw (1) on turn signal lamp (2).
Scheme 95
Release screws (1).
Release screws (2) on front side panel (3).
Installation
Make sure front side panel reinforcement plate is correctly seated.
Tightening torque 41 35 1AZ . See BODY EQUIPMENT - TIGHTENING TORQUES .
Raise front side panel (3) slightly and remove front turn signal lamp (4) in direction of travel.
Scheme 96
Installation
Make sure metal nuts (1) are correctly seated.
Replacement
If necessary, release screw (2) and remove holder (3) from front turn signal lamp (4).
Scheme 97
63 13 200 Removing and installing/replacing front left or right auxiliary turn signal lamp
Slide front auxiliary turn signal lamp (1) with trim strip (2) towards rear and fold out in direction of arrow from front side panel (3).
Scheme 98
Remove trim strip (1) from front auxiliary turn signal lamp (2).
Unfasten plug connection (3) and disconnect.
Remove front auxiliary turn signal lamp (2).
Scheme 99
Installation
Make sure trim strip (1) is correctly seated on front auxiliary turn signal lamp (2).
Fixtures (3), guide (4) and tab (5) must not be damaged.
Scheme 100
Replacement
If necessary, change bulb .
63 17 060 Removing and installing (replacing) left or right front fog lamp
E60/E61 only
Release screws (1).
Detach cover (2) from front underride protection (3) and feed out in direction of arrow.
Remove cover (2).
Scheme 101
E63/E64 only
Release screws (1) and screw (2).
Detach cover (3) from front underride protection (4) and feed out in direction of arrow.
Remove cover (3).
Scheme 102
Build date up to 03/07
Disconnect plug connection (1).
Release screws (2).
Feed front fog lamp (3) in direction of arrow out of mounting (4) and remove.
Scheme 103
Build date from 03/07
Disconnect plug connection (1).
Release screws (2).
Scheme 104
Replacement
- If necessary, convert bulb .
- «Adjust front fog lamps»(/bmw/m6/e63e64-2005-2010/remont/exterior-lights/#lights-repair__63-10-014-adjusting-fog-lamps) .
63 21 055 Replacing a socket housing for left or right rear light (on side panel)
Fold back cover (1) in direction of arrow and remove.
Scheme 105
Turn socket housing for rear light (1) in direction of arrow and remove from rear light (2).
Cut associated two-core lead with sufficient residual length remaining in vehicle and remove socket housing for rear light (1).
Installation
Wiring is carried out with connectors.
If necessary, secure two-core lead against rattling.
Scheme 106
63 21 057 Replacing a socket housing for left or right rear light (on bumper trim)
Necessary preliminary tasks
- Remove rear bumper trim . See «51 12 156 REMOVING AND INSTALLING REAR BUMPER TRIM»(ref-202134-S03823936922005102700000) .
Turn associated socket housing and remove from rear light (3).
- Socket housing of bulb for rear fog light
- Socket housing of bulb for reversing light
Cut associated two-core lead with sufficient residual length remaining in vehicle and remove socket housing.
Installation
Wiring is carried out with connectors.
Scheme 107
63 21 101 Replacing sealing frame for left or right rear light (on side panel)
Necessary preliminary tasks
- Remove rear light.
Detach sealing frame for rear light (1) from rear light (2).
Installation
Sealing frame for rear light (1) is centered via guides (3).
Make sure sealing frame for rear light (1) is correctly bonded all round on rear light (2).
Scheme 108
63 21 180 Removing and installing/replacing left or right rear light (in side panel)
Necessary preliminary tasks
- Partially remove luggage compartment wheel arch trim . See «51 47 151 REMOVING AND INSTALLING/REPLACING LEFT LUGGAGE COMPARTMENT WHEEL ARCH TRIM»(ref-202134-S33740613502005102700000) .
Unfasten plug connection (1) and disconnect.
Release nut (2), tightening torque 2.5 N.m.
Release screws (3), tightening torque 1.5 N.m.
Remove rear light (4) in outwards direction from side panel (5).
Installation
If necessary, adjust rear light (4) to fit by way of adjusting elements (6).
Scheme 109
Installation
Make sure rear light seal (1) is correctly seated, replace if necessary.
Guides (3) of rear light (2) must be visible.
63 21 183 Removing and installing/replacing left or right rear light
Necessary preliminary tasks
- Remove rear bumper trim. See «51 12 156 REMOVING AND INSTALLING REAR BUMPER TRIM»(ref-202134-S03823936922005102700000) .
Build date up to 09/2007
Unfasten plug connection (1) and disconnect.
Release screws (2).
Feed rear light (3) in direction of arrow out of bumper trim (4) and remove.
Scheme 110
Installation
Plastic lugs (1) must not be damaged.
Make sure electrical leads (2) are correctly routed.
Scheme 111
Build date after 09/2007
Disconnect plug connection (1). Release screws (4). Tightening torque 1.5 Nm. Unlock retaining lug (5) and rear light (2) in direction of arrow from bumper trim (3).
Installation: Retaining lug (5) must not be damaged or missing. Make sure wiring harness is correctly laid.
Scheme 112
63 25 000 Removing and installing/replacing auxiliary brake light
Detach cover for auxiliary brake light (1) on both sides in direction of arrow and unclip at points (2).
Feed cover for auxiliary brake light (1) in direction of arrow out of moulded roofliner (3) and remove.
Scheme 113
Installation
Retaining bar (1), clips (2) and guides (3) must not be damaged.
Make sure cover for auxiliary brake light (4) is correctly seated.
Scheme 114
Unfasten plug connection (1) and disconnect.
Unlock slide (2) on both sides and remove auxiliary brake light (3) in direction of arrow from rear window (4).
Installation
Make sure auxiliary brake light (3) is correctly positioned in rear window (4).
Scheme 115
63 25 000 Removing and installing/replacing supplementary brake light (from 09/2007)
| IMPORTANT | Read and comply with notes on protection against electrostatic damage (ESD protection). See 61 35 ... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE) . |
Necessary preliminary tasks
- Remove trim for rear lid. See «51 49 000 REMOVING AND INSTALLING OR REPLACING TRIM FOR REAR LID»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-49-000-removing-and-installing) .
Disconnect plug connection (1). Unscrew nuts (2). Tightening torque 63 25 1AZ . Remove compression springs (3) and washers (4). Unlock safety hooks (6) and remove supplementary brake light (5) in outward direction from rear lid.
Installation: Make sure seal is correctly seated on supplementary brake light (5). Safety hooks (6) must not be damaged or missing. Make sure safety hooks (6) are correctly engaged on rear lid. Tighten nuts (2) from inside outward.
Scheme 116
63 26 000 Removing and installing/replacing left or right number/license plate light
Special tools required
- 64 1 020
Lever license plate light (1) with special tool 64 1 020 out of rear bumper trim (2).
Unlock plug connection underneath and disconnect.
Remove license plate light (1).
Replacement
If necessary, remove bulb.
Note type of bulb .
Scheme 117
Scheme 118
63 31 000 Removing and installing/replacing complete ceiling light (front)
Special tools required
- 00 9 341
Unclip ceiling light (1) with special tool 00 9 341 at points (2).
Feed ceiling light (1) in direction of arrow out of front roofliner trim (3).
Unlock associated plug connection and disconnect.
Remove ceiling light (1).
Scheme 119
Installation
Retaining clips (1) and guides (2) must not be damaged.
Make sure ceiling light (3) is correctly seated.
Scheme 120
Replacement
- If necessary, convert bulbs.
- Note type of bulb.
63 31 020 Removing and installing/replacing footwell light
Special tools required
- 64 1 020
In footwell
Lever out footwell light (1) with special tool 64 1 020 as illustrated.
Disconnect associated plug connection and remove footwell light (1).
Replacement
Note type of bulb .
Scheme 121
On underside of door
Lever out footwell light (1) with special tool 64 1 020 as illustrated.
Disconnect associated plug connection and remove footwell light (1).
Replacement
Note type of bulb .
Scheme 122
63 31 050 Removing and installing/replacing mirror light
Fold down sun visor (2).
Lever front mirror light (1) in direction of arrow.
Disconnect plug connection underneath and remove mirror plate light (1).
Replacement
Note type of bulb .
Scheme 123
63 31 080 Removing and installing/replacing luggage compartment light
Special tools required
- 64 1 020
Lever out luggage compartment light (1) with special tool 64 1 020 as illustrated.
Disconnect associated plug connection and remove luggage compartment light (1).
Replacement
Note type of bulb .
Scheme 124
63 31 150 Removing and installing/replacing glovebox light
Special tools required
- 64 1 020
Lever glovebox light (1) with special tool 64 1 020 as illustrated out of glovebox housing (2).
Disconnect associated plug connection and remove glovebox light (1).
Replacement
Note type of bulb .
Scheme 125
63 31 160 Removing and installing/replacing door mirror light
Necessary preliminary tasks
- Remove retaining ring on door mirror
Unclip door mirror light (1) in direction of arrow from retaining ring on door mirror (2) and remove.
Scheme 126
63 31 180 Replacing LED for front door trim panel light
Necessary preliminary tasks
- Remove door trim panel . See «51 41 000 REMOVING AND INSTALLING LEFT OR RIGHT FRONT DOOR TRIM PANEL»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-41-000-removing-and-installing) .
Remove sheathing of wiring harness (1) in area (A). Cut through wiring harness (1) in area (A) and remove LED for door trim panel light (2).
Installation: Adapt length of wiring harness of new LED for door trim panel light. Connect wiring harness of new LED for door trim panel light using butt connectors to wiring harness (1).
Wrap wiring harness (1) in insulating tape.
Scheme 127
63 31 182 Replacing LED For Front Inside Door Opener
Necessary preliminary tasks
- Remove door trim panel . See «51 41 000 REMOVING AND INSTALLING LEFT OR RIGHT FRONT DOOR TRIM PANEL»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-41-000-removing-and-installing) .
Remove sheathing of wiring harness (1) in area (A). Cut through wiring harness (1) in area (A) and remove LED for door opener (2).
Installation: Adapt length of wiring harness of new LED for door opener. Connect wiring harness of new LED for door opener using butt connectors to wiring harness (1).
Wrap wiring harness (1) in insulating tape.
Scheme 128
63 99... Instructions for handling light bulbs (exterior lights)
| WARNING | Xenon headlights: Danger to life due to high voltage! Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel. |
| WARNING | Halogen lamps are under pressure: To avoid injury, wear protective goggles and gloves. |
| IMPORTANT | To prevent short-circuiting, disconnect light bulbs from voltage supply prior to replacement. |
Do not touch the glass bulbs in new lights bulbs as even the slightest contamination will burn in and reduce bulb service life.
Only touch light bulbs with clean gloves or a clean cloth.
Do not expose light bulbs to mechanical vibrations.
Use only recommended light bulbs.
Follow the light bulb manufacturer's instructions without fail.
63 99... Instructions for replacing light bulbs (interior lights)
| CAUTION | To prevent short-circuiting, disconnect light bulbs from voltage supply prior to replacement. |
Do not touch the glass bulbs in new lights bulbs as even the slightest contamination will burn in and reduce bulb service life.
Only touch light bulbs with clean gloves or a clean cloth.
Do not expose light bulbs to mechanical vibrations.
Use only recommended light bulbs.
Follow the light bulb manufacturer's instructions without fail.
63 99 ... Notes for replacing the protective cap of the headlight
| IMPORTANT | Risk of damage! Damaged seals on the protective caps will lead to moisture penetration into the headlight. This will in turn cause porous cable insulations and malfunctioning of the headlight. |
When working on the headlight system, check the protective cap seals. Replace the protective cap in the event of damage!
Example: screwed protective cap Seal (1) on protective cap (2).
Scheme 129
Example: latchable protective cap Seal (1) on protective cap (2).
Scheme 130
63 99 002 Replacing halogen bulb for left (or right) high-beam headlight
Unclip housing (1) at points (2).
Remove cover (3) from housing (1).
Scheme 131
Unclip engine hood lock pull (1) in area (2) and disengage at point (3).
Place housing (4) with associated pulls in working area to one side.
Installation
Make sure engine hood lock pulls are correctly laid.
Scheme 132
Unlock catch (1) and remove cap (2) in direction of arrow.
Scheme 133
Unclip bulb (1) by pressing on plug (2).
Remove bulb (1) from headlight (3) slightly, disconnect plug connection and remove bulb.
Installation
Insert bulb (1) in headlight (3) at bottom at first and then tilt upwards until bulb snaps audibly into place.
Make sure bulb (1) is correctly seated in catches (4).
Note bulb type .
Scheme 134
63 99 076 Replacing bulb for left (or right) xenon headlight
Necessary preliminary tasks
- Removing ignition unit for left xenon headlight . See «63 12 870 Replacing ignition unit for left xenon headlight»(/bmw/m6/e63e64-2005-2010/remont/exterior-lights/#lights-repair__63-12-870-replacing-ignition-unit) .
Unlock retaining ring (1) in counterclockwise direction and remove.
Remove bulb for xenon headlight (2) in direction of arrow from headlight (3).
Installation
Insert bulb for xenon headlight (2) exactly in headlight (3).
Note bulb type .
Scheme 135
Installation
Observe "Top marking" (1).
Fit retaining ring (2) on headlight is such a way that apertures (3) slide over fixtures for ignition unit (4).
Scheme 136
63 99 076 Replacing bulb for left (or right) xenon headlight (from 09/2007)
Operation is described in: Replacing ignition unit for left xenon headlight 63 12 870 .
63 99 140 Replacing bulb for front left (or right) parking light
Unclip housing (1) at points (2).
Remove cover (3) from housing (1).
Unclip engine hood lock pull (1) in area (2) and disengage at point (3).
Place housing (4) with associated pulls in working area to one side.
Installation
Make sure engine hood lock pulls are correctly laid.
Unlock catch (1) and remove cap (2) in direction of arrow.
Note. Illustration shows headlight removed. Plug connection already unlocked and disconnected.
Turn holder with bulb for side marker lamp (1) counterclockwise with aid of lug (2) and remove from headlight (3).
Installation
Holder with bulb for sidelight (1) must be correctly seated in mounting.
Note bulb type .
Scheme 137
63 99 201 Replacing halogen bulb for left or right front fog lamp
Necessary preliminary tasks
- Remove cover on front underside protection
Disconnect plug connection (1).
Turn bulb with bulb holder (2) in direction of arrow and remove.
Scheme 138
Installation
Note type of bulb.
63 99 273 Replacing bulb for front left (or right) direction indicator
Bulb, interior
Turn lever (1) counterclockwise and pull bulb holder (2) towards rear out of turn signal housing (3).
Remove bulb from bulb holder (2).
Installation
Note bulb type .
Make sure bulb holder (2) is correctly seated in turn signal housing (3).
Scheme 139
Bulb, exterior
Note. Front wheel removed for purposes of clarity.
Release screws (1).
Fold down cover (2) and remove front wheel arch trim (3).
Unfasten plug connection (1) and disconnect.
Turn bulb holder (2) counterclockwise and pull towards rear out of turn signal housing (3).
Remove bulb from bulb holder (1).
Installation
Note bulb type .
Scheme 140
63 99 295 Replacing bulb for auxiliary turn signal light, front left or right
Necessary preliminary tasks
- Remove front auxiliary turn signal light
Turn bulb holder (1) approx. 45 ° counterclockwise and remove from front auxiliary turn signal light (2).
Pull bulb out of holder (1).
Installation
Note type of bulb .
Scheme 141
63 99 312 Replacing bulb(s) for left or right rear light (on bumper trim, rear fog light, reversing light)
Necessary preliminary tasks
- Remove rear bumper trim . See «51 12 156 REMOVING AND INSTALLING REAR BUMPER TRIM»(ref-202134-S03823936922005102700000) .
Turn associated bulb holder and remove from rear light (3).
- Bulb holder of bulb for rear fog light
- Bulb holder of bulb for reversing light
Remove bulb for rear light (1) in direction of arrow from bulb holder (2).
Installation
Note type of bulb .
Scheme 142
63 99 315 Replacing bulb(s) for left or right rear light (rear turn indicator light)
Necessary preliminary tasks
- Remove «socket housing»(/bmw/m6/e63e64-2005-2010/remont/exterior-lights/#lights-repair__63-21-055-replacing-a-socket) for rear light .
Remove bulb for rear light (1) in direction of arrow from bulb holder (2).
Installation
Note type of bulb .
63 99 401 Replacing bulb for left or right license plate light
Necessary preliminary tasks
- Remove license plate light
Turn bulb holder (1) in direction of arrow and withdraw from license plate light (2).
Scheme 143
Detach bulb (1) in direction of arrow.
Installation
Note type of bulb .
Scheme 144
63 99 431 Replacing bulb for front ceiling light
Necessary preliminary tasks
- Remove front ceiling light
Turn bulb in direction of arrow and remove.
Installation
Note bulb type .
Scheme 145
63 99 437 Replacing bulb for footwell light (underside of door)
Necessary preliminary tasks
- Remove footwell light
Remove bulb (1) in direction of arrow.
Installation
Note bulb type .
Scheme 146
63 99 437 Replacing light bulb for footwell light
Necessary preliminary tasks
- Remove footwell light
Move lens cover (1) in direction of arrow and remove.
Remove festoon (2) underneath.
Installation
Note bulb type .
Scheme 147
63 99 445 Replacing bulb for mirror light
Necessary preliminary tasks
- Remove mirror light
Remove bulb (1) in direction of arrow.
Installation
Note bulb type .
63 99 452 Replacing light bulb for luggage compartment lighting
Necessary preliminary tasks
- Remove luggage compartment light
Remove bulb (1) in direction of arrow.
Installation
Note bulb type .
63 99 461 Replacing bulb for glovebox light
Necessary preliminary tasks
- Remove glovebox light
Move lens cover (1) in direction of arrow and remove.
Remove festoon (2) underneath.
Installation
Note bulb type .
See also:
• 61 35 ... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE)
• BODY EQUIPMENT - TIGHTENING TORQUES
• 51 49 000 REMOVING AND INSTALLING OR REPLACING TRIM FOR REAR LID
• 51 41 000 REMOVING AND INSTALLING LEFT OR RIGHT FRONT DOOR TRIM PANEL
• Test Preconditions For Headlight Adjustment
• 63 99... Instructions for handling light bulbs (exterior lights)
• 63 12 870 Replacing ignition unit for left xenon headlight
• 63 12 860 Replacing control unit for left xenon headlight
• 63 12 895 Replacing drive for left adaptive headlight
• Removing and installing left headlight
• left headlight
• 63 99 076 Replacing bulb for left (or right) xenon headlight
• Adjust front fog lamps
• 63 99... Instructions for replacing light bulbs (interior lights)
• socket housing
