Protective measures/rules of conduct
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. Wear protective goggles and gloves. |
- Wear protective goggles
- Wear protective gloves
- Observe national/country-specific regulations
| IMPORTANT | Risk of slipping due to coolant on the floor. Danger of injury! |
Catch and dispose of drained coolant in drip tray (1) and if necessary special tool 00-2030 DEVICE (universal hydraulic lifter).
Recycling
Observe country-specific waste-disposal regulations.
Scheme 9
Checking pressure drop in cooling system
Open cap on coolant expansion tank. Fit special tool 17-0100 TESTER .
Build up gauge pressure of 2 bar, wait approx. 2 minutes.
Cooling system is impervious to leaks if pressure drop is max. 0.1 bar.
Scheme 10
Checking pressure relief valve in cap
Note. Coolant residue can cause the pressure relief valve in the cap to stick, therefore repeat the check procedure on the cap 2- 3 times.
Screw cap (1) onto special tool.
Build up pressure with special tool hand pump; observe pressure gauge to ascertain when opening pressure is achieved.
Scheme 11
| WARNING | Risk of scalding! Only carry out repair work on the cooling system after the engine has cooled down! |
| IMPORTANT | Lifetime coolant filling: Never reuse used coolant! When replacing and removing components which rely on the corrosion protection effect of the coolant, it is essential to change the coolant. The cooling system must therefore be drained and refilled. In the case of other removal work involving the draining of partial quantities of coolant, replace these quantities which have been drained with new coolant. |
Installation note
Use only recommended coolant and observe mixture ratio. See COOLING SYSTEM - OPERATING FLUIDS .
- Wear safety goggles
- Wear protective gloves
- Observe national/country-specific regulations
| IMPORTANT | For dirt contamination of the cooling system (e.g. by engine oil), the cooling system must be rinsed with water until all dirt contamination is removed! |
| IMPORTANT | Risk of skidding due to coolant on the floor. |
Danger of injury!
Catch and dispose of drained coolant in drip tray (1) and if necessary special tool 00-2030 DEVICE (universal hydraulic lifting equipment).
Recycling
Observe country-specific waste disposal regulations.
Necessary preliminary work
- See «FOLLOW NOTES FOR REPAIR WORK ON THE COOLING SYSTEM»(/bmw/m6/e63e64-2005-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-00-instructions-for-working-on) .
- Use only recommended coolant. See «COOLING SYSTEM - OPERATING FLUIDS»(/bmw/m6/e63e64-2005-2010/remont/cooling-system-mechanical/#cooling-system-operating-fluids) .
- Remove reinforcement plate. See «31 10 010 REMOVING AND INSTALLING/REPLACING REINFORCEMENT PLATE»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-repair__31-10-010-removing-and-installingreplacing) .
Draining coolant
Open sealing cap (1) on coolant expansion tank.
Scheme 12
Remove coolant drain plug (1) on radiator.
Drain, catch and dispose of coolant from radiator.
Scheme 13
Remove coolant drain plug (1) on radiator.
Drain, catch and dispose of coolant from radiator.
Scheme 14
Installation note
Replace sealing ring.
Tightening torque 17 11 4AZ .
Adding coolant
17 00... Instructions for working on cooling system
| WARNING | Danger of scalding! Work on the cooling system should only be carried out when the engine has cooled down. |
| IMPORTANT | Wear protective gloves and safety goggles. |
| IMPORTANT | Lifetime coolant filling: Never reuse used coolant. When replacing and removing components which rely on the corrosion protection effect of the coolant, it is essential to change the coolant. The cooling system must therefore be drained and refilled. In the case of other removal work involving the draining of partial quantities of coolant, replace these quantities which have been drained with new coolant. |
| IMPORTANT | Open cooling system only when it has cooled down. Opening the cooling system while hot can result in air entering the system. This can cause overheating with permanent damage to the engine. |
| IMPORTANT | You must protect the alternator against contamination before carrying out any work on the cooling circuit. Cover alternator with suitable materials. Failure to comply with this procedure may result in an alternator malfunction. |
| IMPORTANT | Do not fill coolant expansion tank over MAX level as overfilling will cause the coolant to overflow. This may give rise to traces of residual coolant on the expansion tank or in the engine compartment and wrongly suggest possible leakages. |
Recycling
Catch and dispose of drained coolant.
Observe country-specific waste-disposal regulations.
Note. To disconnect coolant hoses, use commercially available disconnect tools such as HAZET brand tools (see table).
Scheme 15
| HAZET no. | Description |
|---|---|
| 4590-1 | Disconnect tool, length (mm): 150 |
| 4590-2 | Disconnect tool, length (mm): 180 |
| 4590-3 | Disconnect tool, length (mm): 253 |
| 4590/2 | Disconnect/plier set |
| 4590/3 | Disconnect/plier set |
SPECIAL TOOLS REFERENCE CHART
Note. Tightening torque, hose clamps 17 00 1AZ .
Scheme 16
Instructions for disassembly/assembly of coolant hose quick-connect couplings
Disassembly of quick-connect coupling
Pull out lock (1) and (2). Pull off hose.
Scheme 17
Installation
Check O-rings (1).
Do not coat O-rings (1) with anti-seize agent.
Scheme 18
Assembly of quick-connect coupling
Press in lock (1) before installing fast-release coupling.
Push on hose.
Quick-connect coupling must clearly snap audibly into place.
Scheme 19
Special tools required
| Type | Engine | Adapter Y from 17-0100 TESTER |
|---|---|---|
| E60/E61/E63/E64 | All | 17 0 113 |
| E65/E66 | M54/N52/N62/N62T/N73 | 17 0 105 |
| E65/E66 | M57S/M57T/M67/M67T | 17 0 113 |
| E70/E71/E72 | All | 17 0 113 |
| E81/E82/E84/E87/E88/E89 | All | 17 0 113 |
| E83 | M54/N46/N52K | 17 0 105 |
| E83 | M47S/M57S/M57T/M57Y/N47 | 17 0 113 |
| E85/E86 | All | 17 0 105 |
| E90/E91/E92/E93 | All | 17 0 113 |
| F01/F02/F03/F04/F07/F10 | All | 17 0 113 |
| R50/R52 | W10 | 17 0 107 and 17 0 102 |
| R50 | W17 | 17 0 109 |
| R52/R53 | W11 | 17 0 109 |
| R55/R56/R57/R60 | All | 17 0 109 |
| F25 | All | 17 0 113 |
SPECIAL TOOLS REFERENCE CHART
| IMPORTANT | Lifetime coolant filling: Never reuse used coolant! When replacing and removing components which rely on the corrosion protection effect of the coolant, it is essential to change the coolant. The cooling system must therefore be drained and refilled. In the case of other removal work involving the draining of part quantities of coolant, replace these quantities which have been drained with new coolant. |
| IMPORTANT | You must protect the alternator against contamination by coolant when carrying out repair work on the cooling circuit. Cover alternator with suitable materials. Failure to comply with this procedure may result in an alternator malfunction. |
Note on ordering
- Workshop equipment
- Workshop equipment catalogue
- Filler unit no. 81 39 2 152 473
- Collecting vessel no. 81 49 2 152 347
- Adapter: «17-0100 TESTER»(/bmw/m6/e63e64-2005-2010/remont/cooling-system-mechanical/#cooling-system-special-tools)
| IMPORTANT | Risk of slipping due to coolant on the floor. Danger of injury! |
Catch and dispose of emerging coolant in drip tray (1) and if necessary special tool 00-2030 DEVICE (universal hydraulic lifting equipment).
Recycling
Observe country-specific waste disposal regulations.
| IMPORTANT | Check all the coolant hoses before filling the cooling system with the vacuum filling unit. If necessary, replace damaged and porous coolant hoses. |
Scheme 20
- 1) Filling unit with vacuum meter and shut-off valves
- 2) Filler hose
- 3) Coolant container
- 4) Venturi nozzle
- 5) Compressed air connection (max. 6 bar)
- 6) Outgoing-air hose (lead outgoing-air hose into a collecting container)
Requirements
- Cooling system expansion tank must be empty.
- There must be sufficiently premixed coolant in the filling unit container, 1 - 2 liters more than the vehicle filling capacity. Use only recommended coolant and observe mixture ratio and capacities. See «COOLING SYSTEM - OPERATING FLUIDS»(/bmw/m6/e63e64-2005-2010/remont/cooling-system-mechanical/#cooling-system-operating-fluids) .
- Position the filling unit container at the same height as the coolant expansion tank.
- Compressed-air connection with 6 bar pressure present.
- Set vehicle heater to maximum temperature.
Select adapter (Y) according to table and connect to coolant expansion tank.
Connect filler unit to adapter connection (X).
Scheme 21
Shut-off valves (A) and (B) of the filling unit (1) must be closed.
X) Expansion tank connection
Scheme 22
Connect venturi nozzle (1) to filling unit (2).
X) Expansion tank connection
Scheme 23
Connect compressed air (1).
X) Expansion tank connection
Scheme 24
Open shut-off valve (B).
The venturi nozzle produces a flow noise.
Scheme 25
Then open shut-off valve (A) until the filling hose (1) is free of bubbles.
Close shut-off valve (A) again. The filling hose (1) is vented in this way.
Scheme 26
Shut-off valve (B) remains open. Generate vacuum in coolant system for approx. 2 minutes. The final vacuum is reached at a vacuum of -0.7 to -0.95 bar. Green scale on the vacuum meter.
Note. The coolant hoses contract during vacuum build-up.
Then close shut-off valve (B) again.
Scheme 27
Both shut-off valves (A) and (B) must be closed. Then seal Venturi nozzle (1).
Scheme 28
The cooling system must hold the vacuum for 30 seconds. If the needle in the vacuum meter falls, this indicates a leak in the cooling system.
If the vacuum remains constant, proceed with filling.
In event of leaks, check cooling system for leaks.
Scheme 29
| IMPORTANT | There must be sufficiently premixed coolant in the filling unit container, 1 - -2 liters more than the vehicle filling capacity. Position the filling unit container at the same height as the coolant expansion tank. |
Shut-off valve (B) remains closed during the filling process.
To fill the cooling system, open shut-off valve (A) to filling unit container.
Scheme 30
Coolant is now added.
The filling process is finished when the needle in the vacuum meter is at 0 bar or no longer falls.
If necessary, reduce remaining vacuum. Open shut-off valve (B) to do so.
Scheme 31
Remove filling unit with adapter from expansion tank.
Scheme 32
Adjust coolant level to max.
Close coolant expansion tank.
Check function of cooling system.
Check cooling system for leaks.
17 00 039 Venting cooling system and checking for water leaks (S85)
| WARNING | Danger of scalding! Open sealing cap only after engine has cooled down. |
Only when refilling!
| IMPORTANT | Do not fill coolant expansion tank over MAX level as overfilling will cause the coolant to overflow. This may give rise to traces of residual coolant on the expansion tank or in the engine compartment and wrongly suggest possible leakages. |
Use only recommended coolant. See COOLING SYSTEM - OPERATING FLUIDS .
Perform filling operation slowly.
Adjust coolant level to MAX.
Close coolant expansion tank.
Installation
Close cap (1) until the arrow marks line up.
| IMPORTANT | The following venting procedure is necessary e.g. when a part is replaced in the cooling system or when the cooling system is refilled. |
Only when filling!
- Perform filling operation slowly.
- Set heater to maximum temperature and turn fan down to lowest speed.
- Start engine and run at idle speed.
- Fill coolant expansion tank with 250 ml above max. (250 ml correspond to A=18 mm).
- Run engine for 15 mins.
- Cooling system vents itself.
- Coolant level must drop to marking.
- If necessary, correct coolant level.
- Close cap on expansion tank.
Scheme 33
Note. If necessary, check COOLING SYSTEM FOR WATER LEAKS .
17 11 000 Removing and installing radiator (S85)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Necessary preliminary tasks
- «FOLLOW INSTRUCTIONS FOR WORKING ON COOLING SYSTEM»(/bmw/m6/e63e64-2005-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-00-instructions-for-working-on) .
- Remove «FAN COWL»(/bmw/m6/e63e64-2005-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing)
- Drain «COOLANT»(/bmw/m6/e63e64-2005-2010/remont/cooling-system-mechanical/#cooling-system-repair)
Release and disconnect coolant hoses (1).
Release clamp (2), detach coolant hose.
Scheme 34
Release and disconnect coolant hoses (1).
Release clamp (2), detach coolant hose.
Remove radiator towards top.
Installation
Ensure correct seating in side guides.
Scheme 35
Vent COOLING SYSTEM .
Check COOLING SYSTEM FOR LEAKS .
- Remove «FAN COWL WITH ELECTRIC FAN»(/bmw/m6/e63e64-2005-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing)
- Draw off hydraulic fluid
Catch and dispose of hydraulic fluid.
Observe country-specific waste-disposal regulations.
Unlock and disconnect left and right oil lines.
Release screw.
| IMPORTANT | Risk of damage to connecting pipes. |
Carefully press cooling coil on left towards front, then clip out on right and remove.
Installation
Bleed power steering.
Scheme 36
- Remove front bumper trim. See «51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM (M6)»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-11-156-removing-and-installing) .
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Engine oil escapes when oil lines are released. Catch and dispose of emerging engine oil.
Observe country-specific waste-disposal regulations.
Unfasten nut.
Detach oil line from engine oil cooler.
Catch and dispose of escaping oil.
Installation
Replace sealing ring.
Scheme 37
Unfasten screws.
Remove engine oil cooler (1).
Installation
After completing work, check engine oil level and top up if necessary.
Scheme 38
17 11 035 Removing and installing/replacing fan cowl with electric fan (S85)
| IMPORTANT | Risk of short circuits! When removing fan cowl, protect plug and housing against moisture; dry with compressed air if necessary. |
- Read out fault memory of DDE control unit; if necessary, work through test schedules
- Switch off ignition
- Remove radiator cover. See «Removing radiator cover»(/bmw/m6/e63e64-2005-2010/remont/cooling-system-mechanical/#cooling-system-repair__removing-radiator-cover) .
Unlock plug (1) on AUC sensor and disconnect.
Note. Modify AUC sensor when replacing fan cowl.
Scheme 39
Unlock plug (1) and remove.
| IMPORTANT | Risk of short circuits! When removing fan cowl, protect plug and housing against moisture; dry with compressed air if necessary. |
Scheme 40
Unclip cable (1).
Unclip vent lines (2).
Raise fan cowl (3) approx. 3 cm.
Fold in both retaining tabs in direction of arrow.
Remove fan cowl (3) towards top.
Scheme 41
Clear DME fault memory.
Removing radiator cover
Note. Illustrations show N62
Release screws along line.
Unclip Bowden cable (1).
Remove cover (2).
Scheme 42
Note. Illustrations show N62
Unclip line (1).
Unfasten screws.
Remove module carrier cover (2).
Scheme 43
- Remove front bumper trim. See «51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM (M6)»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-11-156-removing-and-installing) .
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Engine oil escapes when oil lines are released. Catch and dispose of emerging engine oil.
Observe country-specific waste-disposal regulations.
Unfasten nut.
Detach oil line from engine oil cooler.
Catch and dispose of escaping oil.
Installation
Replace sealing ring.
Unfasten screws.
Remove engine oil cooler (1).
Installation
After completing work, check engine oil level and top up if necessary.
17 21 010 Removing and installing/replacing transmission oil cooler (GS7S47BG SMG)
| IMPORTANT | It is essential to adhere to the exact filling capacities specified. Fill transmission at room temperature only (approx. 20 - 30 °C). Refer to 00 11 230 CHANGING/SUPPLEMENT TRANSMISSION OIL IN MANUAL TRANSMISSION (GS7S47 SMG) . Gear oil: refer to MANUAL TRANSMISSION - OPERATING FLUIDS . Failure to comply with this instruction will result in serious damage to the transmission. |
Catch and dispose of gear oil with suitable equipment.
Observe country-specific waste-disposal regulations.
- Unscrew and remove splash guard.
- Remove reinforcement plate. See «31 10 010 REMOVING AND INSTALLING/REPLACING REINFORCEMENT PLATE»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-repair__31-10-010-removing-and-installingreplacing) . Important notes on installation are described in this work step
- Remove heat shields
- Drain. See «00 11 230 CHANGING/SUPPLEMENT TRANSMISSION OIL IN MANUAL TRANSMISSION (GS7S47 SMG)»(/bmw/m6/e63e64-2005-2010/remont/manual-trans/#manual-transmission-repair__00-11-230-changingsupplement-transmission-oil) .
Disconnect connector (1).
Scheme 44
Release union nut (1).
Tightening torque 23 41 19AZ .
Remove oil cooler connection (2).
Tightening torque 23 41 20AZ .
Scheme 45
Release banjo bolt (1).
Installation
Replace banjo bolt with seal.
Tightening torque 23 41 18AZ .
Scheme 46
Release screw (1). Remove gear oil cooler in direction of arrow.
Tightening torque 23 41 16AZ .
Scheme 47
Installation
Journal (1) on gear oil cooler must be secured in rubber grommet (2).
Scheme 48
See also:
• 17-0100 TESTER
• OPENING PRESSURE OF PRESSURE RELIEF VALVE
• COOLING SYSTEM - OPERATING FLUIDS
• 31 10 010 REMOVING AND INSTALLING/REPLACING REINFORCEMENT PLATE
• 17 11 4AZ
• 51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM (M6)
• 00 11 230 CHANGING/SUPPLEMENT TRANSMISSION OIL IN MANUAL TRANSMISSION (GS7S47 SMG)
• 23 41 19AZ
• FOLLOW NOTES FOR REPAIR WORK ON THE COOLING SYSTEM
• FILL AND VENT COOLING SYSTEM
• FAN COWL
• COOLING SYSTEM
• Removing radiator cover
