00 Danger of poisoning if oil is ingested/absorbed through the skin
Danger of poisoning!
Ingesting oil or absorbing through the skin may cause poisoning!
Possible symptoms are
- Headaches
- Dizziness
- Stomach aches
- Vomiting
- Diarrhoea
- Cramps/fits
- Unconsciousness
Protective measures/rules of conduct
- Pour oil only into appropriately marked containers
- Do not pour oil into drinking vessels (drinks bottles, glasses, cups or mugs)
- Observe country-specific safety regulations
First aid measures
- Do not induce vomiting. If the person affected is still conscious, he/she must rinse out their mouth with water, drink plenty of water and consult a doctor immediately. If the person affected is unconscious, do not administer anything by mouth, place the person in the recovery position and seek immediate medical attention.
00 Risk of injury if oil comes into contact with eyes and skin
Danger of injury!
Contact with eyes or skin may result in injury!
Possible symptoms are
- Impaired sight
- Irritation of the eyes
- Reddening of the skin
- Rough and cracked skin
Protective measures/rules of conduct
- Wear protective goggles
- Wear oil-resistant protective gloves
- Observe country-specific safety regulations
First aid measures
- Eye contact: Rinse eyes immediately with plenty of water for at least 15 minutes; if available, use an eye-rinsing bottle. If irritation of the eyes persists, consult a doctor.
- Skin contact: Wash off with soap and water immediately. If irritation persists, consult a doctor. NOTE: Do not use solvents/thinners.
00 Safety instructions for handling oil
| WARNING | DANGER OF POISONING if oil is ingested/absorbed through the skin! RISK OF INJURY if oil comes into contact with eyes and skin! |
Recycling
Observe country-specific waste-disposal regulations.
Measures if oil is unintentionally released
- Personal precautionary measures: Danger of slipping! Keep non-involved persons away from the work area. Wear personal protective clothing/equipment.
- Environmental protection measures: Prevent oil from draining into drain channels, sewerage systems, pits, cellars, water and the ground.
- Limiting spread: Use oil blocks to prevent the surface spread of oil.
- Cleaning procedure: Bind and dispose of escaped oil with nonflammable absorbents. NOTE: Do not flush oil away with water or aqueous cleaning agents.
00...... Raising vehicle with trolley jack
| IMPORTANT | Observe the following trolley-jack-related instructions |
Scheme 1
- Use only BMW-distributed/approved trolley jacks which have rubber plate contact points.
- Trolley jacks must be regularly serviced and always checked for functional reliability before they are used!
- Check the rubber plate on the trolley jack prior to each use, replacing if necessary.
| WARNING | The vehicle may be raised with a trolley jack only at the following jacking points! |
Scheme 2
- Car jacking point
- Side car jacking points
- Rear differential Risk of damage: It is not permitted to raise the vehicle at the rear differential cover!
Scheme 3
Scheme 4
37 10... Removing and installing/replacing pressure relief valves
Necessary preliminary tasks
- Remove «FRONT ASSEMBLY UNDERSIDE PROTECTION»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-490-removing-and-installing)
| IMPORTANT | Before releasing, it is essential to remove corrosion and dirt from the area around the pressure relief valves! |
Pull vent hose (3) out of Y-piece at marked position (see arrow in illustration). Vent line can be removed by sliding back the protruding collar on the Y-piece.
| IMPORTANT | Do not open banjo bolts (2). |
Release pressure relief valve (1) directly from oscillating motor.
Scheme 5
Installation
Replace distributor lines (2).
Screw pressure relief valve fully into oscillating motor and remove plug.
Tightening torque: see 1AZ in 37 11 CONTROL AND SUSPENSION ELEMENTS, FRONT
| IMPORTANT | Slide in yellow distributor line in forward direction of travel and black distributor line in rearward direction of travel. Slide distributor lines (2) into pressure relief valve (1) up to second marking (M). |
Scheme 6
37 12 001 Checking function of self-levelling suspension system
Carry out error search with BMW diagnosis system.
37 14 017 Removing and installing/replacing front mounted acceleration sensor (M model)
| IMPORTANT | Read and comply with NOTES ON PROTECTION AGAINST ELECTROSTATIC DAMAGE (ESD PROTECTION) . |
Necessary preliminary tasks
- Remove «FRONT WHEEL»(/bmw/m5/e60e61-2004-2010/remont/wheel-tire-system/#wheel-and-tires-repair__36-10-300-removing-or-installing)
- Partially detach «FRONT WHEEL ARCH COVER»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-040-removing-and-installingreplacing) (in rear area).
Release screws (1). Disconnect plug connection (2). Remove front mounted acceleration sensor (3).
Scheme 7
37 14 027 Removing and installing/replacing rear mounted acceleration sensor (M model)
| IMPORTANT | Read and comply with NOTES ON PROTECTION AGAINST ELECTROSTATIC DAMAGE (ESD PROTECTION) . |
Necessary preliminary tasks
- Remove «LUGGAGE COMPARTMENT TRIM ON SIDE PANEL ON RIGHT»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-220-removing-and-installingreplacing) .
Unscrew nuts (1). Disconnect connector (2). Remove rear mounted acceleration sensor (3).
Scheme 8
37 14 511 Replacing front ride-height sensor (M5, M6)
| IMPORTANT | Read and comply with NOTES ON PROTECTION AGAINST ELECTROSTATIC DAMAGE (ESD PROTECTION) . |
Necessary preliminary tasks
- Remove right steering gear cover.
Release nut (1) and disconnect jointed rod.
Tightening torque: see 7AZ in 37 14 ELECTRIC COMPONENTS
Release screws (2), remove ride-height sensor from bracket and disconnect plug connection (3).
Installation
Sensor lever must point from ride-height sensor to right front wheel.
Tightening torque: see 6AZ in 37 14 ELECTRIC COMPONENTS
Scheme 9
After installation
Check HEADLIGHT ADJUSTMENT , correct if necessary.
37 14 512 Replacing rear ride-height sensor
| IMPORTANT | Read and comply with NOTES ON PROTECTION AGAINST ELECTROSTATIC DAMAGE (ESD PROTECTION) . |
Release nut and disconnect jointed rod (3).
Installation
Replace self-locking nut.
Tightening torque: see 7AZ in 37 14 ELECTRIC COMPONENTS .
Release screws (1).
Tightening torque: see 6AZ in 37 14 ELECTRIC COMPONENTS .
Disconnect plug connection (4) and remove ride-height sensor.
Installation
Sensor lever (2) must point outwards from ride-height sensor.
Scheme 10
After installation
- Check «HEADLIGHT ADJUSTMENT»(/bmw/m5/e60e61-2004-2010/remont/exterior-lights/#lights-repair__63-10-004-adjusting-headlights) , correct if necessary.
37 15 055 Removing and installing/replacing EDC control unit (M model)
| IMPORTANT | Read and comply with NOTES ON PROTECTION AGAINST ELECTROSTATIC DAMAGE (ESD PROTECTION) . |
Necessary preliminary tasks
- Remove «TRIM FOR INSTRUMENT PANEL, BOTTOM LEFT»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-181-removing-and-installingreplacing) .
- Remove «FOOTWELL SIDE TRIM PANEL ON A-PILLAR, RIGHT»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-43-075-removing-and-installingreplacing) .
Press floor trim at front right to one side.
Open cutout in insulating mat (shown with dotted line) and release nut (1).
Disconnect plug connections (2). Unscrew nut (3).
Slide control unit (4) with bracket upwards and remove sideways.
If necessary, remove control unit (4) from bracket.
Scheme 11
After installation
Carry out PROGRAMMING/CODING
