84 10 050 Removing and installing (replacing) USB hub
| IMPORTANT | Read and comply with NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE) . |
Necessary preliminary tasks
- Remove «LUGGAGE COMPARTMENT TRIM ON LEFT SIDE PANEL»(ref-297477-S27600701182008090200000) .
- Partially detach «LEFT LUGGAGE COMPARTMENT WHEEL ARCH TRIM»(ref-297477-S39420885822008090200000) .
Release screws (1) and feed out USB hub with holder (2).
Scheme 36
Release nuts (1) and disconnect plug connections (2).
Scheme 37
84 11 550 Removing and installing/replacing hands free microphone
Special tools required
- «64 1 020»(ref-297521-S29338299452008090300000) .
Lever out front microphone trim (1) with special tool 64 1 020.
Disconnect plug connection underneath and remove microphone trim (1).
Scheme 38
| IMPORTANT | Disconnecting the plug connection for the hands-free microphone or emergency SOS call button results in fault memory entries in the telephone control unit (limitation in the emergency SOS call system). After fitting, read out fault memory and if necessary delete entries. |
Unlock detent lug (1) and feed out hands-free microphone (2) in direction of arrow.
Installation
Arrow on hands-free microphone (2) points in driving direction.
Scheme 39
84 11 600 Replacing cordless keypad handset
Note. For operating cordless keypad handset, refer to operating instructions of corresponding telephone.
84 11 610 Removing and installing/replacing eject box (cordless keypad handset)
Necessary preliminary tasks
- If necessary, remove cordless keypad handset from eject box.
- Remove «FRESH-AIR GRILLE IN REAR CABIN»(ref-297483-S40386809552008090200000) .
If necessary, disconnect antenna plug (1).
Disconnect plug connection (2).
Unlock socket housing on plug connection (2) and slide out contact carrier.
Scheme 40
Note. Unlock eject box (1) and fold up.
Release screws (2).
Feed out plug connection and remove eject box (1).
Installation
Ensure correct cable routing in eject box (1).
Scheme 41
84 11 650 Removing and installing/replacing telematic control unit (TCU) (option SA633/SA638/SA639/SA664)
| IMPORTANT | Replacement with option SA638/SA664: Carry out PROGRAMMING/CODING If necessary, carry out coupling procedure Replacement with option SA633/SA639: Carry out PROGRAMMING/CODING Via Diagnosis and Information System (DIS): Service functions Start subsequent assessment |
| IMPORTANT | Read and comply with NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE) . |
Note. Follow INSTRUCTIONS FOR HANDLING FIBRE OPTIC CABLES .
Necessary preliminary tasks
- Disconnect «BATTERY NEGATIVE LEAD»(ref-272716-S14920322362007112600000) .
- Remove «LUGGAGE COMPARTMENT WHEEL ARCH TRIM ON LEFT»(ref-297477-S39420885822008090200000) .
Unlock plug connections (1) and (2) and disconnect.
Unfasten antenna plug (3) and disconnect.
Release nuts (4) and remove TCU (5).
Installation
Observe color coding of aerial/antenna plugs (3).
Scheme 42
84 21 526 Removing and installing/replacing line compensator
| IMPORTANT | Read and comply with NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE) . |
Necessary preliminary tasks
- Remove «LUGGAGE COMPARTMENT WHEEL ARCH TRIM ON LEFT»(ref-297477-S39420885822008090200000) .
Release knurled nuts.
Disconnect antenna plug (1).
Unfasten plug connection (2) and disconnect.
Release screws (3) and remove compensator (4).
Scheme 43
84 21 535 Removing and installing/replacing hands free charging electronics
| IMPORTANT | Read and comply with NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE) . |
Note. Comply with INSTRUCTIONS FOR HANDLING FIBRE OPTIC CABLES .
Necessary preliminary tasks
- Disconnect «BATTERY NEGATIVE LEAD»(ref-272716-S14920322362007112600000) .
- Remove «LUGGAGE COMPARTMENT TRIM ON LEFT SIDE PANEL»(ref-297477-S27600701182008090200000) .
- Partially remove «LUGGAGE COMPARTMENT WHEEL ARCH TRIM ON LEFT»(ref-297477-S39420885822008090200000) .
Disconnect antenna lead plug connection (1).
Unscrew nuts (2).
Disconnect plug connection (3).
Remove hands-free charging electronics (4) in direction of arrow.
Scheme 44
Replacement
- Carry out «PROGRAMMING/CODING»(/bmw/m5/e60e61-2004-2010/remont/horns/#general-electrical-system-repair__61-00-program-encode-the)
- If necessary, log mobile phone on to vehicle
84 21 542 Removing and installing (replacing) hands-free charging electronics (High)
| IMPORTANT | Read and comply with NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE) . |
Note. Comply with INSTRUCTIONS FOR HANDLING FIBRE OPTIC CABLES .
Necessary preliminary tasks
- Disconnect «BATTERY NEGATIVE LEAD»(ref-272716-S14920322362007112600000)
- Partially remove «LUGGAGE COMPARTMENT FLOOR TRIM PANEL»(ref-297477-S37164142922008090200000) .
- If necessary, remove storage tray for car jack
- If necessary, remove spare wheel
- Remove control unit cover
M5
Remove hands-free charging electronics (1) from shell insert (2).
Scheme 45
All
Remove hands-free charging electronics (1) from device mounting (2).
Scheme 46
Disconnect plug connection (1).
Remove hands-free charging electronics (2).
Scheme 47
Replacement
- Carry out «VEHICLE PROGRAMMING/CODING»(/bmw/m5/e60e61-2004-2010/remont/horns/#general-electrical-system-repair__61-00-program-encode-the)
- If necessary, log mobile phone on to vehicle
84 31 020 Removing and installing/replacing hands free system speaker
Necessary preliminary tasks
- Remove «TRIM PANEL FOR PEDAL ASSEMBLY»(ref-297477-S12403481672008090200000) .
Screw on threaded ring (1) in direction of arrow and remove hands-free system speaker (2) from trim for pedal assembly (3).
Scheme 48
84 50 060 Removing and installing/replacing Bluetooth antenna
Necessary preliminary tasks
- Remove «CENTER CONSOLE»(ref-297477-S01293729252008090200000) .
Unfasten plug connection (1) and disconnect.
Detach Bluetooth antenna (2) in direction of arrow from rear-compartment ventilation duct (3).
Scheme 49
When replacing dual-lock tape
- Clean bonding surfaces.
- Stick on dual-lock tape and press down firmly with fingers for at least 2 secs. (ambient temperature at least 18°C).
- Fit Bluetooth antenna on rear-compartment ventilation duct only after a minimum period 30 minutes (strain-free dwell time).
- Subjecting the bond to premature load will result in a loss of adhesion and thus a defective bond => use new dual-lock tape.
Installation
Fit Bluetooth antenna (1) during installation so that dual-lock tapes (2) and (3) coincide exactly.
Scheme 50
65 20 030 Removing and installing/replacing empty housing for roof-mounted aerial
Note. Clean roof.
Tape off roof surface (2) around aerial cover (3) with yellow adhesive tape (1). To do so, slide adhesive tape slightly under roof aerial.
If necessary, carefully heat vehicle roof in aerial area with a hot air blower (max. 50 °C).
| IMPORTANT | Risk of damage! Handle special tool correctly and make sure you are standing safely with a firm foothold next to vehicle. In order to prevent dents in the roof outer skin, do not exert any pressure on the roof. |
Scheme 51
| IMPORTANT | Risk of damage! Make sure your arms do not cross over (1) when holding special tool 65 2 010 (knife). Pull handle must always be ahead of the guiding hand (2). |
Scheme 52
Cut through adhesive bead all round with special tool 65 2 010 (knife).
Pull on handle (1) and align blade on handle (2).
Note. Use sharp blades only. If necessary, sharpen blade.
Remove cover of multiband telephone aerial (3).
Scheme 53
Installation
- The cover of the multiband telephone aerial is secured with window adhesive. All preparatory operations correspond to the «WINDOW CEMENTING INSTRUCTIONS»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-31-notes-on-window-bonding) .
Note. The aerial cover must be replaced if its centering pins (1) are damaged. Bonding surface (2) must be clean and free from grease.
Scheme 54
Position two spacers (1) on cleaned aerial cover.
Dimensions
- 10 mm
- 14 mm
Position spacer (2) centrally and flush with shoulder of adhesive flange.
| IMPORTANT | Spacers must be used without fail! |
Scheme 55
Apply trace of adhesive bead all round outer contour as follows.
Distance between adhesive bead and edge of aerial cover
- 6.5 mm ±1 mm
Start and end of bead trace must have an overlap length of max. 10 mm.
| IMPORTANT | To prevent the adhesive from escaping, the adhesive bead diameter must not exceed 3 mm ± 1 mm. |
Scheme 56
Note. Attach the aerial cover coated with adhesive by hand. To spread the adhesive better, move the cover back and forth horizontally slightly when pressing down. If necessary, secure aerial cover with adhesive tape and do not press down on one side of the aerial more firmly than the other. After bonding, leave vehicle to stand for at least 3 hours at room temperature. To guarantee a permanent bond: Only use washing installations after a period of 24 hours has passed.
