Scheme 23
| In conjunction with | 00 5 500 |
|---|---|
| Note | For rotary shaft seal of inner segment shaft in steering gear |
| Series | E24, E28, E30, E31, E32, E34, E36, E38, E38/3, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91 |
| Storage location | B30 |
| Order number | 32 1 060 |
| Drift |
MECHANICAL TOOL (32 1 060 DRIFT)
Scheme 24
| Note | For opening and fastening hose clamps |
|---|---|
| Series | E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, R50, R52, R53, RR1 |
| SI number | 1 02 01 (667) |
| Order number | 32 1 260 |
| Pliers |
MECHANICAL TOOL (32 1 260 PLIERS)
32 1 270 Plugs (set)
Minimum set: Mechanical tools
Scheme 25
| Note | 27-piece, 3x per size - For sealing off hydraulic lines for brakes, steering etc. |
|---|---|
| Series | E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E85, E87, E90, R50, R53, RR1 |
| SI number | 1 14 01 (766) |
| Order number | 32 1 270 |
| Plugs (set) |
MECHANICAL TOOL (32 1 270 PLUGS)
Scheme 26
| Note | For removing track rod ball joints from drop arm and idler arm |
|---|---|
| Series | E24, E28, E34, E46, E46/16 |
| Storage location | B23 |
| Order number | 32 2 040 |
| Removal tool |
MECHANICAL TOOL (32 2 040 REMOVAL TOOL)
32 3 030 Setting tool
Minimum set: Mechanical tools
Scheme 27
| Note | For setting toe-in on rear axle - rear axle with KDS |
|---|---|
| Series | E36, E46, E83, E85 |
| Storage location | C36 |
| SI number | 1 02 98(302) |
| Order number | 32 3 030 |
| Setting tool |
MECHANICAL TOOL (32 3 030 SETTING TOOL)
Scheme 28
| Note | For fitting steering angle sensor on steering column |
|---|---|
| Series | E46, E85 |
| SI number | 1 02 98(302) |
| Order number | 32 3 040 |
| Slip bush |
MECHANICAL TOOL (32 3 040 SLIP BUSH)
32 3 090 Extractor
Minimum set: Mechanical tools
Scheme 29
| Note | For forcing wheel control joint off wheel carrier E30 (325ix), E34 (525ix), E36, E46, Z1, Z3. For forcing tie rod off wheel carrier E34 (525ix) |
|---|---|
| Series | E30, E34, E36, E36/7, E46, E85, R50, R52, R53 |
| Storage location | B21 |
| SI number | 1 04 92(487) |
| Order number | 32 3 090 |
| Extractor | |
| Consisting of | |
| 1 = 32 3 091 | Pressure screw |
MECHANICAL TOOL (32 3 090 EXTRACTOR)
32 3 110 Releasing tool
Minimum set: Mechanical tools
Scheme 30
| Note | For unlocking lock cylinder in steering wheel lock during removal |
|---|---|
| Series | E31, E32, E34, E36, E36/7, E38, E39, E46, E60, E61, E63, E64, E83, E85, R50, R52, R53 |
| Storage location | A31 |
| SI number | 1 06 94(801) |
| Order number | 32 3 110 |
| Releasing tool |
MECHANICAL TOOL (32 3 110 RELEASING TOOL)
Scheme 31
| Note | Drift for driving in steering shaft guide bearing on E46 (new steering gear). Volume production launch 1998. |
|---|---|
| Series | E46 |
| SI number | 1 02 98 (302) |
| Order number | 32 3 130 |
| Drift |
MECHANICAL TOOL (32 3 130 DRIFT)
32 3 140 Setting tool
Minimum set: Mechanical tools
Scheme 32
| Note | For setting front camber. |
|---|---|
| Series | E38, E39, E46, E53, E65, E66, E67, E83, E85, E87, E90, E91 |
| Storage location | C35 |
| SI number | 1 14 01 (766) |
| Order number | 32 3 140 |
| Setting tool | |
| Consisting of | |
| 4 = 32 3 144 | Screw |
| 5 = 32 3 145 | Washer |
| Note | For setting camber on front axle |
MECHANICAL TOOL (32 3 140 SETTING TOOL)
Scheme 33
| Note | For checking pump pressure in power steering system |
|---|---|
| Series | E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91 |
| Order number | 32 4 000 |
| Fixture | |
| Consisting of | |
| 1 =32 4 001 | Pressure gauge 16 bar |
| 2 = 32 4 002 | Pressure gauge 160 bar |
| 3 = 32 4 003 | Test fixture without pressure gauge |
| 4 = 32 4 004 | Line |
| 5 = 32 4 005 | Connecting piece |
| Note | For screwing into hydraulic pump / model series: E23, E46, E52, E53, E64, E65, E66, E85 |
| 6 = 32 4 006 | Connecting piece |
| Note | For screwing into test fixture 32 4 003 / model series: E23, E46, E52, E53, E64, E65, E66, E85 |
| 7 = 32 4 007 | Connecting piece M18 x 1.5 |
| Note | For screwing into pressure regulator / model series: E32, E34 |
| 8 = 32 4 008 | Connecting piece M14 x 1.5 |
| Note | For screwing into test fixture / model series: E32, E34 |
| 9 = 32 4 009 | Ball valve |
| 11 = 32 4 011 | Adapter M14 x 1.5 |
| 12 = 32 4 012 | Adapter M16 x 1.5 |
MECHANICAL TOOL (32 4 000 FIXTURE)
