Fuses & Circuit Breakers - e46 BMW M3 E46

Fuses & Circuit Breakers 8 illustrations ~278 words

IDENTIFICATION

WARNINGVehicles are equipped with air bag supplemental restraint system. Before attempting any repairs involving steering column, instrument panel or related components, see AIR BAG SAFETY PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in AIR BAG RESTRAINT SYSTEMS article.
CAUTIONWhen battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery.

ENGINE COMPARTMENT

Engine compartment fuse panel (Engine Electronics Fuse Carrier - A8680) is located at the left rear of engine compartment (Scheme 1)

Scheme 1

Scheme 1: ENGINE COMPARTMENT

Engine compartment fuses are protection for

  1. F1: 30A - Ignition Coils (1-6)
  2. F2: 30A - Idle Speed Control Valve
  3. F3: 20A Camshaft Position Sensors (1 and 2) Crankshaft Position Sensor Hot Film Mass Airflow Sensor Characteristic MAP Cooling Thermostat Secondary Air Injection Pump Relay Fuel Pump Relay Fuel Tank Leakage Diagnosis Module A/C Compressor Relay Exhaust Flap Valve ABS/DSC Unit DSC Steering Angle Sensor
  4. F4: 30A Oxygen Sensors (1-4) Transmission Control Module
  5. F5: 30A - Fuel Injectors Relay

PASSENGER COMPARTMENT

To locate the passenger compartment fuse box (Scheme 2) To access, open glove box, turn the locks by 90° and fold open the power distribution box downward. For fuse assignments for applicable models, see the Fuse Assignments table.

Note. For passenger compartment fuses not covered by (Scheme 3) through (Scheme 6), see Cable Shoe Fuses.

YearDate Of ManufactureSee Figure
2001Up To 9/01(Scheme 3)
10/01-3/03(Scheme 4)
2002(Scheme 4)
2003Up To 3/03(Scheme 4)
4/03-3/04(Scheme 5)
2004Up To 3/04(Scheme 5)
4/04 Onward(Scheme 6)

Fuse Assignments

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Cable Shoe Fuses

Cable Shoe Fuses are located behind glove box (Scheme 7)

Scheme 7

Scheme 7
  1. F102: 80A - B+ Potential Distributor
  2. F105: 50A - Ignition Switch, Diagnostic Plug (DLC)
  3. F106: 50A - Ignition Switch, Light Switching Central Control Unit

LUGGAGE COMPARTMENT

Note. On models equipped with rear battery.

Luggage compartment fuse holder (G19) is located at the right side, next to the battery (Scheme 8)

Scheme 8

Scheme 8: LUGGAGE COMPARTMENT

Luggage compartment Fuse 108 (200A) is protection for the passenger compartment fuse F105.

WIRING DIAGRAMS

Note. For wiring diagrams, see appropriate SYSTEMS WIRING DIAGRAM article in ELECTRICAL.
