13 0 131 Compressed air hose with filter
| Order number | 13 0 131 |
|---|---|
| Compressed air hose with filter |
SPECIAL TOOL DESIGNATION
Scheme 1
13 0 132 Adapter
| Order number | 13 0 132 |
|---|---|
| Adapter |
SPECIAL TOOL DESIGNATION
Scheme 2
13 0 133 Container
| Order number | 13 0 133 |
|---|---|
| Container |
SPECIAL TOOL DESIGNATION
Scheme 3
13 3 010 Hose clip
Minimum set: Mechanical tools
| Note | For disconnecting a hose for repair work |
|---|---|
| Series | E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, R50, R52, R53, RR1 |
| Storage location | A22 |
| Order number | 13 3 010 |
| Hose clip |
SPECIAL TOOL DESIGNATION
Scheme 4
13 3 060 Fixture
| Note | For checking fuel pressure on K-Jetronic and L-Jetronic as well as oil pressure |
|---|---|
| Engine | M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N40, N42, N45, N46, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11, W17 |
| Order number | 13 3 060 |
| Fixture | |
| Consisting of | |
| 1 = 13 3 061 | Pressure gauge 0...25 bar |
| 2 = 13 3 062 | 2-way cock |
| Note | Engine: All, except S50, S54, N73 |
| 3 = 13 3 063 | Connecting lines (2 x) |
| Note | For fuel and oil pressure testing |
| 4 = 13 3 064 | Connecting line |
| Note | Mit T-piece for L-Jetronic All except N73 |
| 5 = 13 3 065 Connecting piece distributor | |
| Note | All except N73 |
| 6 = 13 3 066 Connecting piece warm-up sensor | |
| Note | All except N73 |
| 7 = 13 3 067 Connecting hose | |
| Note | For checking fuel pump delivery All except N73 |
| In conjunction with: 13 3 020 | |
| 8 = 13 3 068 Connecting piece distributor | |
| Note | All except N73 |
| In conjunction with: BMW SERVICE TESTER | |
| 9 = 13 3 069 | Connecting piece |
| Note | For warm-up sensor with hose all except N73 |
| In conjunction with: BMW SERVICE TESTER |
SPECIAL TOOL DESIGNATION
Scheme 5
13 5 220 Adapter
Minimum set: Mechanical tools
| In conjunction with | 13 3 063 or 13 6 051 |
|---|---|
| Note | For pressure gauge 13 3 061 or BMW DIS for measuring fuel pressure at injection rail |
| Engine | M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N40, N42, N62, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11, W17 |
| Storage location | C16 |
| SI number | 1 06 95 (963) |
| Order number | 13 5 220 |
| Adapter | |
| Consisting of | |
| 1 = 13 5 221 | Adapter |
| Note | Engine: M43, M44, M52, M62 |
| 2 = 13 5 222 Coupling connector | |
| Note | For connecting DIS pressure sensor |
SPECIAL TOOL DESIGNATION
Scheme 6
13 5 280 Plugs for fuel lines
| Note | For sealing off fuel lines when removing and installing engine - Applicable to M62 only fitted in E39 / M52 only fitted in E38 / S50B32 only fitted in E36 / N62 only fitted in E65 / M54 in E83. |
|---|---|
| Series | E36, E38, E39, E46, E60, E61, E63, E64, E65, E66, E67, E83, E85, R50, R52, R53, RR1 |
| Engine | M52, M54, M62, N40, N42, N62, N73, S50B32, W10, W11 |
| Storage location | B16 |
| SI number | 1 18 96(163) |
| Order number | 13 5 280 |
| Plugs for fuel lines | |
| Consisting of | |
| 1 = 13 5 281 | Seal (2 x) |
| Note | For sealing quick couplings |
| 2 = 13 5 282 Seal (2 x) | |
| Note | For sealing fuel lines |
SPECIAL TOOL DESIGNATION
Scheme 7
13 6 050 Set of adapters for BMW DIS
Minimum set: Mechanical tools
| Note | For measuring oil and fuel pressures |
|---|---|
| Engine | M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N40, N42, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11, W17 |
| Storage location | A16, B16 |
| SI number | 1 12 94(859) |
| Order number | 13 6 050 |
| Set of adapters for BMW DIS | |
| Consisting of | |
| 1 = 13 6 051 | Connecting hose |
| For connecting reducers 13 6 052, 13 6 053, 13 6 55 and adapters | |
| 11 4 050, 11 4 160, 11 4 170, 13 5 131 to BMW DIS | |
| 2 = 13 6 052 | Reducer |
| Note | For pipe elbows 24 0 023, 24 0 024, 24 0 140 |
| In conjunction with: 13 6 051 | |
| 3 = 13 6 053 | Reducer for adapter 16 1 300 |
| In conjunction with: 13 6 051 | |
| 4 = 13 6 054 | Pipe elbow |
| In conjunction with: 13 6 051, 11 4 050 | |
| 5 = 13 6 055 | Reducer for T-pieces 13 6 056 and 13 6 057 |
| In conjunction with: 13 6 051 | |
| 6 = 13 6 056 | T-piece for 6 mm dia. line |
| 7 = 13 6 057 | T-piece for 8 mm dia. line |
SPECIAL TOOL DESIGNATION
Scheme 8
13 6 058 T-piece for 12 mm dia. line
| Order number | 13 6 058 |
|---|---|
| T-piece for 12 mm dia. line |
SPECIAL TOOL DESIGNATION
Scheme 9
13 6 200 Ultrasonic cleaning system
| Note | For fuel injectors complete with special detergent |
|---|---|
| Engine | M10, M20, M21, M30, M40, M41, M42, M43, M44, M50, M51, M52, M54, M60, M62, M70, M73, M88, N42, N46, S14, S38, S50B30, S50B32, S50US, S52US |
| Storage location | Single |
| SI number | 2 01 87(623) |
| Order number | 13 6 200 |
| Ultrasonic cleaning system | |
| Consisting of | |
| 1 = 13 6 201 | Ultrasonic cleaning unit |
| Note | Without special cleaner |
| 3 = 13 6 203 | Basket |
| Note | For diesel injection nozzles |
| 5 = 13 6 205 | Mounting rail |
| Note | For fuel injectors - engine: M10, M20, M30, M40, M42, M43, M44, M M50, M52, M54, M60, M62, M70, M73, M88, N42, S14, S38, S50B30, S50B32, S50US, S52 |
| 6 = 13 6 206 | Wiring harness |
| 13 6 202 | Special cleaner (R 60 L) 10 ltr. |
| 13 6 207 | Cleaning agent concentrate 1 ltr. |
| Note | Tunop 656 |
