63 10 Adjusting headlight for RHD/LHD vehicles

When crossing borders into countries where they drive on the other side of the road from that where the car was registered, it is essential to cover the asymmetrical wedge in the low beam headlight. The following illustrations show the covered areas in question.

Note. Any adhesive residue may only be removed with the supplied cleaning cloth.

Scheme 19

(Scheme 19) shows the headlights on a left-hand-drive car.

(Scheme 20) shows the headlights on a right-hand-drive car.

Note. On cars fitted with xenon lights, it is not necessary to tape off the lights as they have their own adjustment facility; refer to the Owner's Manual.

Scheme 20

1. Car parked on level ground.
2. Replace faulty glass and mirrors and blackened light bulbs.
3. Check tire pressure and correct if necessary.
4. Apply load equivalent to one person on driver's seat (approx. 75 kg).
5. Vehicle with full fuel tank or appropriate additional weight in luggage compartment.
6. Correct adjustment of headlights in relation to engine hood (gap dimensions).
7. Manual headlight vertical aim control: Turn handwheel to 0 position.
8. Automatic headlight vertical aim control: Wait approx. 30 seconds after switching on lights.
9. Version with xenon headlights: Wait 80 seconds after switching on lights. During this time, do not move the vehicle and avoid vibrations.
10. Align headlight aimer with vehicle longitudinal axis and parallel to parking surface. Set marking line (M) on aimer to distance (e). Scale graduations on aimer are equal to a gradient in cm at a distance of 10 meters.

Light/dark limit of headlights in headlight aimer

e Adjustment dimension, headlights

1. as per type plate on headlight housing in % (e.g.: 1.0 % = 10 cm /10 m = 10 on headlight aimer). Adjustment dimension, fog lights
2. all vehicles 2.0 % = 20 cm /10 m = 20 on headlight aimer.

H Height of center of headlight above parking surface.

h H - e = height of marking line above parking surface

+ Central mark = center point of high-beam headlight.

M Marking line of headlamp aimer

S Parking surface of vehicle and headlight aimer

Adjustment dimension (e) is only valid for EUR. Observe differing national regulations.

63 10 004 ADJUSTING HEADLIGHTS

Observe test preconditions for headlight adjustment, refer to 63 10 ... TEST REQUIREMENTS FOR HEADLIGHT VERTICAL AIM ADJUSTMENT .

Adjust headlights by turning adjusting screws (1) and (2).

Scheme 21

A definite allocation of adjusting screws is not possible. Both directions are always adjusted differently.

1. Adjustment screw primarily for vertical adjustment
2. Adjustment screw primarily for lateral adjustment

63 10 014 ADJUSTING FOG LAMPS

Observe test preconditions for adjusting headlights. Refer to 63 10 ... TEST REQUIREMENTS FOR HEADLIGHT VERTICAL AIM ADJUSTMENT .

Saloon/sedan, touring up to 09/2001

Adjust fog lamp (1) at adjusting screw (2).

Scheme 22

Saloon/sedan, touring from 09/2001

Note. Tools required

Offset hexagon head screwdriver (size 4 mm) with ball head (1).

Using above-mentioned tool through opening (2), turn adjusting screw of fog lamp (3).

Scheme 23

Coupe, convertible

Adjust fog lamp (1) at adjusting screw (2).

Scheme 24

Saloon/Sedan, Touring, Coupe, Convertible with M/aerodynamics package

If necessary, unclip trim. Refer to 63 17 030 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT FOGLAMP INSERT (M/AERODYNAMICS PACKAGE) .

Adjusting Fog Lamp At Adjusting Screw.

Scheme 25

compact

Adjust fog lamp (2) at adjusting screw (1).

Scheme 26

Compact with M/aerodynamics package

Adjust fog lamp (1) at adjusting screw (2).

Scheme 27

63 12 001 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT

Coupe/Convertible from 03/2003

Remove left headlight (xenon headlight). Refer to 63 12 010 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT (XENON HEADLIGHT) .

All others

Necessary preliminary tasks

1. Remove direction indicator lamp. Refer to «63 13 150 REMOVING AND INSTALLING/REPLACING COMPLETE FRONT LEFT OR RIGHT TURN SIGNAL LAMP»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair) .
2. Remove trim from headlight housing. Refer to «51 13 065 REMOVING AND INSTALLING/REPLACING TRIM ON LEFT OR RIGHT HEADLIGHT HOUSING (COUPE, CONVERTIBLE)»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-13-065-removing-and-installingreplacing) .

Note. Illustration shows air cleaner cover removed for purposes of clarity.

Unlock and disconnect all plug connections on headlight.

Scheme 28

Release screws (1) and (2) and lever out headlight towards front.

Scheme 29

Installation

Tighten screws (1) hand-tight only.

Pull headlight fully towards front.

Close hood and adjust headlight to fit.

Open hood and tighten down screws (1).

Install and tighten down screws (2).

Installation

Adjust headlights. Refer to 63 10 004 ADJUSTING HEADLIGHTS .

63 12 002 Removing and installing/replacing right headlight

Remove and install/replace headlight. Refer to 63 12 001 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT .

63 12 005 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT (XENON HEADLIGHT)

Coupe/Convertible from 03/2003

Remove left headlight (xenon headlight). Refer to 63 12 010 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT (XENON HEADLIGHT) .

All others

Remove spray nozzles of headlight cleaning system. Refer to 61 67 045 REMOVING AND INSTALLING/REPLACING SPRAY NOZZLES FOR LEFT OR RIGHT HEADLIGHT CLEANING SYSTEM .

Remove left headlight. Refer to 63 12 001 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT .

63 12 006 Removing and installing/replacing right headlight (xenon headlight)

Remove headlight (xenon headlight). Refer to 63 12 005 Removing and installing/replacing left headlight (xenon headlight) .

63 12 010 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT (XENON HEADLIGHT)

Necessary preliminary tasks

1. Remove spray nozzles of headlight cleaning system. Refer to «61 67 045 REMOVING AND INSTALLING/REPLACING SPRAY NOZZLES FOR LEFT OR RIGHT HEADLIGHT CLEANING SYSTEM»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-repair__61-67-045-removing-and-installingreplacing) .

Release screws (1).

Scheme 30

Pull headlight (2) forwards slightly in direction of arrow.

Unlock plug connections (1) and disconnect.

Remove headlamp (2).

Scheme 31

Installation

1. Observe gap dimensions.
2. Adjust headlights.

Replacement

1. Remove ignition unit and lamp for xenon headlight. Refer to «63 99 076 REPLACING LAMP FOR LEFT XENON HEADLIGHT (COUPE, CONVERTIBLE)»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-99-076-replacing-lamp-for) .
2. Remove control unit for xenon headlight.

63 12 016 Replacing left headlight (adaptive headlight)

Necessary preliminary tasks

1. Remove left headlight, refer to «63 12 010 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT (XENON HEADLIGHT)»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-12-010-removing-and-installingreplacing)
2. Remove drive unit for adaptive headlight, refer to «63 12 895 REPLACING DRIVE FOR LEFT ADAPTIVE DIRECTIONAL HEADLIGHT»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-12-895-replacing-drive-for)
3. Remove control unit for left xenon headlight, refer to «63 12 860 REPLACING CONTROL UNIT FOR LEFT XENON HEADLIGHT (M3)»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-12-860-replacing-control-unit)
4. Remove bulb for left xenon headlight (ignition unit), refer to «63 99 076 REPLACING LAMP FOR LEFT XENON HEADLIGHT (COUPE, CONVERTIBLE)»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-99-076-replacing-lamp-for)

After installation

1. Carry out programming/coding, refer to «DIAGNOSIS PROGRAMMING/CODING»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-repair__diagnosis-programmingcoding)
2. Adjust headlight, refer to «63 10 004 ADJUSTING HEADLIGHTS»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-10-004-adjusting-headlights)

63 12 034 REMOVING AND INSTALLING/REPLACING LENS COVER FOR LEFT HEADLIGHT (HALOGEN HEADLIGHT)

Remove turn signal lamp. Refer to 63 13 150 REMOVING AND INSTALLING/REPLACING COMPLETE FRONT LEFT OR RIGHT TURN SIGNAL LAMP .

Remove trim from headlight housing. Refer to 51 13 065 REMOVING AND INSTALLING/REPLACING TRIM ON LEFT OR RIGHT HEADLIGHT HOUSING (COUPE, CONVERTIBLE) .

Unclip cover strip from outside to inside.

Scheme 32

Unclip all retainers.

Scheme 33

Remove lens cover.

Installation

If necessary, replace headlight seal.

Contact point of headlight seal is situated on radiator side (high beam headlight) in area of clip.

63 12 035 Removing and installing/replacing lens cover for right headlight (halogen headlight)

Remove and install/replace lens cover for headlight (halogen headlight). Refer to 63 12 034 REMOVING AND INSTALLING/REPLACING LENS COVER FOR LEFT HEADLIGHT (HALOGEN HEADLIGHT) .

63 12 037 Removing and installing/replacing lens cover for left headlight (xenon headlight)

Remove and install/replace lens cover for headlight. Refer to 63 12 034 REMOVING AND INSTALLING/REPLACING LENS COVER FOR LEFT HEADLIGHT (HALOGEN HEADLIGHT) .

63 12 038 Removing and installing/replacing lens cover for right headlight (xenon headlight)

Remove and install/replace lens cover for headlight. Refer to 63 12 034 REMOVING AND INSTALLING/REPLACING LENS COVER FOR LEFT HEADLIGHT (HALOGEN HEADLIGHT) .

63 12 860 REPLACING CONTROL UNIT FOR LEFT XENON HEADLIGHT (M3)

Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel.

Disconnect plug connection (1).

Scheme 34

Unclip control unit cover (3) and remove.

Installation

Make sure catches (2) are correctly seated.

Release screws (1) and (3) and nut (2).

Scheme 35

Remove holder of control unit for xenon headlight (4) and place to one side.

Release screws (1) and remove retaining plate (2).

Scheme 36

Detach control unit for xenon headlight (3) from holder of control unit for xenon headlight (4) and remove.

63 12 861 Replacing control unit for right xenon headlight (M3)

Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel.

Remove right headlight. Refer to 63 12 005 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT (XENON HEADLIGHT) .

Loosen screws (1).

Scheme 37

Remove control unit for xenon headlight (2) in direction of arrow from guides and place to one side.

Installation

Ensure correct cable routing.

Loosen screws (1).

Scheme 38

Detach control unit for xenon headlight (3) from holder of control unit for xenon headlight (2) and remove.

63 12 870 REPLACING IGNITION UNIT FOR LEFT XENON HEADLIGHT (COUPE, CONVERTIBLE)

Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel.

Build status up to 03/2003

Necessary preliminary tasks

1. Remove left headlight (xenon headlight). Refer to «63 12 005 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT (XENON HEADLIGHT)»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-12-005-removing-and-installingreplacing) .
2. Remove left headlight insert (xenon headlight). Refer to «67 16 011 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT VERTICAL AIM ADJUSTER (XENON HEADLIGHT)»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#electrical-drives-repair__67-16-011-removing-and-installingreplacing) .

Unfasten plug connection (1) and disconnect.

Scheme 39

Loosen screws (2).

Remove xenon headlight for xenon headlight (3).

Build status from 03/2003

Unlock catch (1) and feed out/remove cover (2) in direction of arrow.

Scheme 40

Installation

Make sure retaining lugs (1), cover (2) and seal (3) are exactly seated.

Scheme 41

Catch (4) must be fully locked.

Unclip electrical lead at point (1).

Scheme 42

Turn ignition unit for xenon headlight (2) approx. 30° in direction of arrow and detach.

Plug connection (3) is automatically released by turning ignition unit for xenon headlight (2).

Installation

Make sure ignition unit for xenon headlight (2) is correctly engaged.

63 12 871 Replacing right ignition unit for right xenon headlight

Operation is described in

Replacing ignition unit for left xenon headlight. Refer to 63 12 870 REPLACING IGNITION UNIT FOR LEFT XENON HEADLIGHT (COUPE, CONVERTIBLE) .

63 12 895 REPLACING DRIVE FOR LEFT ADAPTIVE DIRECTIONAL HEADLIGHT

Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel.

Necessary preliminary tasks

1. Remove left headlight. Refer to «63 12 010 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT (XENON HEADLIGHT)»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-12-010-removing-and-installingreplacing) .

Release screws (1).

Scheme 43

Remove drive for adaptive directional headlight (2) in direction of arrow from headlight (3).

Installation

Fit drive for adaptive directional headlight (1) exactly on headlight.

Scheme 44

Make sure pin housing (2) is correctly seated in plug housing (3).

Carry out coding/programming. Refer to DIAGNOSIS PROGRAMMING/CODING .

63 12 950 Replacing a lower holder for headlight mounting

Remove headlight. Refer to 63 12 001 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT or 63 12 005 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT (XENON HEADLIGHT) .

Release screws and remove lower holder.

Scheme 45

Installation

Tighten screws hand-tight only.

Install headlight and align to engine hood. Refer to 63 12 001 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT .

Tighten down screws.

Version with headlight cleaning system

Unclip clip for hose (1) and disconnect hose (2).

Scheme 46

Up to 09/2001

Open hood.

Press down retainer (1) through bore in side panel and slide turn signal lamp towards front.

Scheme 47

Installation

Make sure bonded rubber seal (1) is correctly seated on trim (2).

Scheme 48

From 09/2001

Open hood.

Loosen screw (1).

Scheme 49

Installation

Observe tightening torque, 1.5 Nm.

Note. Secure front turn signal lamp (2) against falling out.

Slide out front turn signal lamp (2) in direct of arrow.

Installation

Make sure nut (1) is correctly seated on headlight housing (2).

Scheme 50

If necessary, when screwing front turn signal lamp into place, secure nut (1) with screwdriver (3) against turning.

Installation

When sliding in front turn signal lamp (1), make sure guides (2) are correctly seated in headlight mounts (3).

Scheme 51

Make sure bonded seal is correctly seated under front turn signal lamp (1).

All

Disconnect plug connection (1).

Scheme 52

Note. Turn signal lamp, front left

To release, turn bulb holder (2) clockwise.

Turn signal lamp, front right

To release, turn bulb holder (2) counterclockwise.

Turn bulb holder (2) and remove turn signal lamp (3).

Installation

Make sure seal is correctly seated between bulb holder (2) and turn signal lamp (3).

63 13 200 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT ADDITIONAL TURN SIGNAL LAMP (COUPE, CONVERTIBLE, COMPACT)

Special tools required

1. 64 1 020

For identification of special tools, refer to LIGHTS - SPECIAL TOOLS - 3-SERIES (M54/E46) .

M3 only

Lever out additional front turn signal lamp (1) with special tool 64 1 020 in direction of arrow.

Scheme 53

Pull out additional front turn signal lamp (1) up to bulb holder, turn through approx. 90° and feed out.

All others

Lever out additional front turn signal lamp (1) with special tool 64 1 020 in direction of arrow.

Pull out additional front turn signal lamp (1) up to bulb holder, turn through approx. 90° and feed out.

Scheme 54

Disconnect plug connection (1) and remove additional front turn signal lamp (2).

Scheme 55

63 14 120 Removing and installing/replacing reflecting tail light on rear bumper (coupe, convertible)

Note. Once the bumper (1) has been pressed on, the reflecting tail light (2) is forced out by spring force.

Scheme 56

Press bumper (1) in center upwards and remove reflecting tail light (2) towards rear/top.

Installation

Insert reflecting tail light (2) at bottom into bumper (1) and press top/center against reflecting tail light (2) until it snaps into place in bumper (1).

Installation

Fixtures (1) and springs (2) on reflecting tail light (3) must not be damaged.

Scheme 57

Installation

Fixtures (1) in bumper (2) must not be damaged.

Scheme 58

63 17 030 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT FOGLAMP INSERT (M/AERODYNAMICS PACKAGE)

Special tools required

1. 64 1 020

For identification of special tools, refer to LIGHTS - SPECIAL TOOLS - 3-SERIES (M54/E46) .

Version 1

Place special tool 64 1 020 in opening (2) and unclip trim (1) in direction of arrow.

Scheme 59

Installation

Make sure trim (1) engages correctly.

Release screw (1).

Scheme 60

Feed foglamp insert (3) in direction of arrow out of outer guides (2) and remove.

Disconnect plug connection behind it and remove foglamp insert (3).

Installation

Make sure foglamp insert (3) is correctly seated in outer guides (2).

Make sure ventilation grommet of foglamp insert (3) is laid without kinks and is sufficiently firmly seated.

If necessary, adjust fog lamp. Refer to 63 10 014 ADJUSTING FOG LAMPS .

Version 2

Unclip trim (1) in direction of arrow.

Scheme 61

Installation

Make sure trim (1) engages correctly.

Release screw (1).

Withdraw fog lamp insert (2) in direction of arrow.

Scheme 62

Disconnect plug connection behind it and remove foglamp insert (2).

Installation

Feed lugs (3) into outer guides (4).

Make sure ventilation grommet of foglamp insert (2) is laid without kinks and is sufficiently firmly seated.

If necessary, adjust fog lamp. Refer to 63 10 014 ADJUSTING FOG LAMPS .

63 21 055 REPLACING A SOCKET HOUSING FOR LEFT OR RIGHT REAR LIGHT (COUPE, CONVERTIBLE)

In side panel

unlock catch (1) and remove socket housing for rear light (2).

Scheme 63

Disconnect plug connection and remove socket housing for rear light.

Scheme 64

In rear lid

Partially release panel for rear lid. Refer to 51 49 000 REMOVING AND INSTALLING OR REPLACING TRIM FOR TRUNK LID .

Disconnect plug connection, unlock socket housing and remove.

Scheme 65

63 21 180 Removing and installing/replacing left or right rear light (in side panel)

Remove socket housing for rear light. Refer to 63 21 055 REPLACING A SOCKET HOUSING FOR LEFT OR RIGHT REAR LIGHT (COUPE, CONVERTIBLE) .

Saloon/Sedan, Coupe And Convertible

Detach luggage compartment wheel arch liner in rear area. Refer to 51 47 151 REMOVING AND INSTALLING/REPLACING TRUNK WHEEL HOUSING TRIM, LEFT .

Release nuts and remove rear light towards outside.

Scheme 66

Coupe And Convertible Only

Convert side trim or near light (inside).

Touring

Unscrew nut (1).

Scheme 67

Release nuts (2) slightly and remove rear light (3) towards outside.

Installation

Make sure rear light seal is correctly seated, replace if necessary.

Make sure there is a uniform gap all round between outer rear light and side panel.

63 21 183 Removing and installing/replacing left or right rear light (on rear lid)

Remove socket housing for rear light. Refer to 63 21 055 REPLACING A SOCKET HOUSING FOR LEFT OR RIGHT REAR LIGHT (COUPE, CONVERTIBLE) .

Release nut slightly

Scheme 68

Press lock in direction of rear light housing and remove rear light towards outside.

Installation

Make sure rear light seal is correctly seated, replace if necessary.

Make sure there is a uniform gap all round between outer rear light and rear lid.

Installation

Attach outer detent lugs (1) to rear lid.

Scheme 69

63 31 000 REMOVING AND INSTALLING/REPLACING COMPLETE CEILING LIGHT

Note. Secure complete ceiling light against falling out.

Version with inside reading lamps

Lever out complete ceiling light (1) in direction of arrow.

Scheme 70

Disconnect plug connection underneath and remove complete ceiling light (1).

Version without inside reading lamps

Lever out complete ceiling light (1) in direction of arrow.

Scheme 71

Disconnect plug connection underneath and remove complete ceiling light (1).

63 31 015 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT INTERIOR LIGHT (C-PILLAR OR HARD TOP)

Note. Secure interior light against falling out.

Version with inside reading lamp

Lever out interior light (1) in direction of arrow.

Scheme 72

Disconnect plug connection underneath and remove interior light (1).

Version without inside reading lamp

Lever out interior light (1) in direction of arrow.

Scheme 73

Disconnect plug connection underneath and remove interior light (1).

63 31 020 REMOVING AND INSTALLING/REPLACING FOOTWELL LIGHT

Lever out footwell light (1) in direction of arrow.

Scheme 74

Disconnect plug connection and remove footwell light.

63 31 050 REMOVING AND INSTALLING/REPLACING MIRROR LIGHT

Replacement

If necessary, convert bulb.

Lever front mirror light (1) in direction of arrow.

Scheme 75

Disconnect plug connection underneath and remove mirror plate light (1).

Replacement

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 31 150 Removing and installing/replacing glovebox light

Lever out glovebox light (1) in direction of arrow.

Scheme 76

Disconnect plug connection and remove glovebox light (1).

63 99 ... INSTRUCTIONS FOR HANDLING LIGHT BULBS (EXTERIOR LIGHTS)

Do not touch the glass bulbs in new lights bulbs as even the slightest contamination will burn in and reduce bulb service life.

Only touch light bulbs with clean gloves or a clean cloth.

Do not expose light bulbs to mechanical vibrations.

Use only recommended light bulbs.

Follow the light bulb manufacturer's instructions without fail.

63 99 ... INSTRUCTIONS FOR REPLACING LIGHT BULBS (INTERIOR LIGHTS)

Do not touch the glass bulbs in new lights bulbs as even the slightest contamination will burn in and reduce bulb service life.

Only touch light bulbs with clean gloves or a clean cloth.

Do not expose light bulbs to mechanical vibrations.

Use only recommended light bulbs.

Follow the light bulb manufacturer's instructions without fail.

63 99 002 REPLACING HALOGEN BULB FOR HIGH-BEAM HEADLIGHT ON LEFT

Necessary preliminary tasks

M54, N42 only

1. Detach intake muffler housing and place to one side.

S54 only

1. Remove intake hood and intake manifold. Refer to «13 71 000 REMOVING AND INSTALLING INTAKE FILTER HOUSING (S54)»(/bmw/m3/e46-1999-2006/remont/fuel-system/#fuel-system-repair__13-71-000-removing-and-installing) .

Coupe/Convertible from 03/2003

N40 only

1. Detach intake muffler housing and place to one side.

Note. For purposes of clarity, illustration shows removed headlight.

Turn protective cap (1) in direction of arrow and remove from headlight (2).

Scheme 77

Unfasten plug connection (1) and disconnect.

Scheme 78

Disconnect locking clip (2) in direction of arrow and fold upwards.

Remove bulb (3) from headlight (4).

Unfasten plug connection and disconnect.

Turn retaining ring in direction of arrow and remove bulb holder towards rear.

Scheme 79

Note. If retaining ring is tightly seated, press bulb holder forwards.

Remove bulb from bulb holder.

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 003 Replacing halogen bulb for high-beam headlamp on right

Operation is described in: replace halogen bulb for high-beam headlamp. Refer to 63 99 002 REPLACING HALOGEN BULB FOR HIGH-BEAM HEADLIGHT ON LEFT .

63 99 071 Replacing halogen-light bulb for left or right headlight

Disconnect plug.

Scheme 80

Turn retaining ring in direction of arrow and remove bulb holder towards rear.

Note. If retaining ring is firmly seated, press bulb holder forwards.

Remove bulb from bulb holder.

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 076 REPLACING LAMP FOR LEFT XENON HEADLIGHT (COUPE, CONVERTIBLE)

Necessary preliminary tasks

1. Remove left control unit cover. Refer to «63 12 860 REPLACING CONTROL UNIT FOR LEFT XENON HEADLIGHT (M3)»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-12-860-replacing-control-unit) .

Detach cover for low beam (1) in direction of arrow.

Scheme 81

Installation

Ensure cover for low beam (1) and lug (2) are correctly seated.

Turn ignition unit for xenon headlight (1) in direction of arrow.

Scheme 82

Turn retaining ring (2) in direction of arrow and remove.

Remove lamp for xenon headlight.

Necessary preliminary tasks

1. Remove ignition unit for xenon headlight. Refer to «63 12 870 REPLACING IGNITION UNIT FOR LEFT XENON HEADLIGHT (COUPE, CONVERTIBLE)»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-12-870-replacing-ignition-unit) .

Turn retaining ring for xenon headlight lamp (1) in direction of arrow and remove.

Scheme 83

Remove lamp for xenon headlight (2).

Installation

Insert lamp for xenon headlight (1) exactly in mounting (2).

Scheme 84

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

Detach filler neck and place to one side. Refer to 17 11 100 REMOVING AND INSTALLING/REPLACING COOLANT EXPANSION TANK (S54) .

N42 only

Remove intake hood.

Detach water reservoir for windshield washer system and place to one side.

Replace bulb for xenon light. Refer to 63 99 076 REPLACING LAMP FOR LEFT XENON HEADLIGHT (COUPE, CONVERTIBLE) .

63 99 132 REPLACING BULB FOR SIDE MARKER LAMP, FRONT LEFT

US only

Replace bulb for front turn-signal lamp. Refer to 63 99 273 REPLACING BULB FOR TURN INDICATOR, FRONT LEFT .

All models except US

M54 only

Release intake filter housing and place to one side.

Turn bulb holder for side marker lamp in direction of arrow and pull out towards rear.

Scheme 85

Withdraw bulb from bulb holder for side marker lamp.

Scheme 86

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 133 Replacing bulb for side marker lamp, front right

Replace bulb for front side marker lamp. Refer to 63 99 132 REPLACING BULB FOR SIDE MARKER LAMP, FRONT LEFT .

63 99 230 Replacing halogen bulb for left or right fog lamp (M aerodynamics package)

Remove fog lamp. Refer to 63 17 030 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT FOGLAMP INSERT (M/AERODYNAMICS PACKAGE) .

Turn bulb with socket (1) and remove from fog lamp (2).

Scheme 87

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 273 REPLACING BULB FOR TURN INDICATOR, FRONT LEFT

Coupe/Convertible from 03/2003

Turn bulb holder for turn indicator bulb (1) in direction of arrow and pull out of headlight (2) towards rear.

Scheme 88

Pull bulb for turn indicator (1) out of turn indicator bulb holder (2).

Scheme 89

All others

Necessary preliminary tasks

1. Remove complete front turn-signal lamp. Refer to «63 13 150 REMOVING AND INSTALLING/REPLACING COMPLETE FRONT LEFT OR RIGHT TURN SIGNAL LAMP»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair) .
2. Remove bulb.

All

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 275 Replacing bulb for turn indicator, front right

Coupe/Convertible from 03/2003

Necessary preliminary tasks

1. Detach washer fluid reservoir for windshield washer system and place to one side.

All

Replace bulb for front turn-signal lamp. Refer to 63 99 273 REPLACING BULB FOR TURN INDICATOR, FRONT LEFT .

63 99 295 Replacing bulb for auxiliary turn indicator light, front left or right

Remove additional front turn signal lamp. Refer to 63 13 200 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT ADDITIONAL TURN SIGNAL LAMP (COUPE, CONVERTIBLE, COMPACT) .

Turn bulb holder (1) and remove from additional front turn signal lamp (2).

Scheme 90

Note. Additional turn signal lamp, front left

To open, turn bulb holder (1) counterclockwise.

Additional turn signal lamp, front right

Saloon/sedan, touring from 09/2001: To open, turn bulb holder (1) clockwise.

All others: To open, turn bulb holder (1) counterclockwise.

Pull bulb out of holder (1).

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 315 Replacing bulb(s) for left or right rear light (Coupe, Convertible)

Note. Coupe/Convertible from 03/2003

The light sources of the rear light in the side section are made up of LEDs.

Necessary preliminary tasks

1. Remove socket housing for rear light, refer to «63 21 055 REPLACING A SOCKET HOUSING FOR LEFT OR RIGHT REAR LIGHT (COUPE, CONVERTIBLE)»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-21-055-replacing-a-socket)

In side section

Twist defective light bulb and pull out to remove.

Scheme 91

Note. Turn indicator Tail/brake light Tail light

In rear lid

Twist defective light bulb and pull out to remove.

Scheme 92

Note. Reversing light Left side: if necessary rear fog light Right side: Not used

All

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 401 Replacing bulb for left or right license plate light

Lever out lens (1) on left or right from opening (2) and remove.

Scheme 93

Lever out bulb (3).

Note. Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 431 Replacing light bulb(s) for ceiling light

Remove complete ceiling light (with inside reading lamps). Refer to 63 31 000 REMOVING AND INSTALLING/REPLACING COMPLETE CEILING LIGHT .

Turn socket housing for bulb counterclockwise and remove.

Remove bulb.

Note. Socket housing for left inside reading lamp Socket housing for ceiling light Socket housing for right inside reading lamp

Scheme 94

Remove complete ceiling light (without inside reading lamps). Refer to 63 99 ... INSTRUCTIONS FOR REPLACING LIGHT BULBS (INTERIOR LIGHTS) .

Loosen screws (1).

Scheme 95

Remove ceiling light (2) from lens underneath.

Remove bulb(s).

All

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 435 Replacing bulb for left or right interior light (C-pillar or hard top)

Remove interior light. Refer to 63 31 015 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT INTERIOR LIGHT (C-PILLAR OR HARD TOP) .

Turn socket housing counterclockwise and remove.

Scheme 96

Remove bulb.

Note. Socket housing for inside reading lamp Socket housing for interior light

Unclip lens (1).

Scheme 97

Pull bulb (1) in direction of arrow from bulb holder.

Scheme 98

All

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 437 Replacing light bulb for footwell light

Remove footwell light. Refer to 63 31 020 REMOVING AND INSTALLING/REPLACING FOOTWELL LIGHT .

Move lens cover (1) in direction of arrow and remove.

Scheme 99

Remove bulb (2) underneath.

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 445 Replacing bulb(s) for mirror light

Remove mirror light. Refer to 63 31 050 REMOVING AND INSTALLING/REPLACING MIRROR LIGHT .

Spread bow contacts (1) and remove bulb(s) (2).

Scheme 100

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

63 99 451 Replacing light bulb for luggage compartment lighting

Lever out lens in direction of arrow.

Scheme 101

Remove bulb.

Scheme 102

Installation

Note type of bulb. Refer to LIGHTS - TECHNICAL DATA - 3-SERIES (E46) .

See also:
• 51 13 065 REMOVING AND INSTALLING/REPLACING TRIM ON LEFT OR RIGHT HEADLIGHT HOUSING (COUPE, CONVERTIBLE)
• 61 67 045 REMOVING AND INSTALLING/REPLACING SPRAY NOZZLES FOR LEFT OR RIGHT HEADLIGHT CLEANING SYSTEM
• 61 35... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE)
• DIAGNOSIS PROGRAMMING/CODING
• 67 16 011 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT VERTICAL AIM ADJUSTER (XENON HEADLIGHT)
• LIGHTS - SPECIAL TOOLS - 3-SERIES (M54/E46)
• 51 49 000 REMOVING AND INSTALLING OR REPLACING TRIM FOR TRUNK LID
• 51 47 151 REMOVING AND INSTALLING/REPLACING TRUNK WHEEL HOUSING TRIM, LEFT
• LIGHTS - TECHNICAL DATA - 3-SERIES (E46)
• 13 71 000 REMOVING AND INSTALLING INTAKE FILTER HOUSING (S54)
• 17 11 100 REMOVING AND INSTALLING/REPLACING COOLANT EXPANSION TANK (S54)
• 63 10 ... TEST REQUIREMENTS FOR HEADLIGHT VERTICAL AIM ADJUSTMENT
• 63 17 030 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT FOGLAMP INSERT (M/AERODYNAMICS PACKAGE)
• 63 12 010 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT (XENON HEADLIGHT)
• 63 10 004 ADJUSTING HEADLIGHTS
• 63 12 001 REMOVING AND INSTALLING/REPLACING LEFT HEADLIGHT
• 63 12 005 Removing and installing/replacing left headlight (xenon headlight)
• 63 99 ... INSTRUCTIONS FOR HANDLING LIGHT BULBS (EXTERIOR LIGHTS)
• 63 99 076 REPLACING LAMP FOR LEFT XENON HEADLIGHT (COUPE, CONVERTIBLE)
• 63 12 895 REPLACING DRIVE FOR LEFT ADAPTIVE DIRECTIONAL HEADLIGHT
• 63 12 860 REPLACING CONTROL UNIT FOR LEFT XENON HEADLIGHT (M3)
• 63 12 034 REMOVING AND INSTALLING/REPLACING LENS COVER FOR LEFT HEADLIGHT (HALOGEN HEADLIGHT)
• 63 12 870 REPLACING IGNITION UNIT FOR LEFT XENON HEADLIGHT (COUPE, CONVERTIBLE)
• 63 10 014 ADJUSTING FOG LAMPS
• 63 21 055 REPLACING A SOCKET HOUSING FOR LEFT OR RIGHT REAR LIGHT (COUPE, CONVERTIBLE)
• 63 99 ... INSTRUCTIONS FOR REPLACING LIGHT BULBS (INTERIOR LIGHTS)
• 63 99 002 REPLACING HALOGEN BULB FOR HIGH-BEAM HEADLIGHT ON LEFT
• 63 99 273 REPLACING BULB FOR TURN INDICATOR, FRONT LEFT
• 63 99 132 REPLACING BULB FOR SIDE MARKER LAMP, FRONT LEFT
• 63 13 200 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT ADDITIONAL TURN SIGNAL LAMP (COUPE, CONVERTIBLE, COMPACT)
• 63 31 000 REMOVING AND INSTALLING/REPLACING COMPLETE CEILING LIGHT
• 63 31 015 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT INTERIOR LIGHT (C-PILLAR OR HARD TOP)
• 63 31 020 REMOVING AND INSTALLING/REPLACING FOOTWELL LIGHT
• 63 31 050 REMOVING AND INSTALLING/REPLACING MIRROR LIGHT
