DESCRIPTION & OPERATION
All models are equipped with power windows with a one-touch open/close feature.
Removal & Installation
Remove door trim panel. Lower window about 12" (30 cm). Disconnect window motor electrical connector. Push clips aside. Hold door window and disconnect window lift arms. (Scheme 1) Twist and lift out door window. To install, reverse removal procedure.
Scheme 1
Scheme 1: Removal & Installation
Removal
- On 4-door models, remove window. See WINDOW. On 2-door and convertible models, clamp door window at raised position using wooden wedges. On all models, remove door or side panel.
- Remove screw from inside door handle. (Scheme 2) Remove door handle. Remove bolts and grind off rivets (as necessary). Remove window motor. (Scheme 3)
Installation
To install, reverse removal procedure. Replace rivets with bolts, washers and nuts.
Scheme 2
Scheme 3
Power Window Wiring Diagram (1992 2-Door Coupe). Scheme 4
Scheme 4: Power Window Wiring Diagram (1992 2-Door Coupe)
Power Window Wiring Diagram (1992 4-Door). Scheme 5
Power Window Wiring Diagram (1992 Convertible). Scheme 6
Scheme 6: Power Window Wiring Diagram (1992 Convertible)
Power Window Wiring Diagram (1993 2-Door Coupe). Scheme 7
Scheme 7: Power Window Wiring Diagram (1993 2-Door Coupe)
Power Window Wiring Diagram (1993 4-Door). Scheme 8
Scheme 8: Power Window Wiring Diagram (1993 4-Door)
Power Window Wiring Diagram (1995-96 318ti). Scheme 9
Scheme 9: Power Window Wiring Diagram (1995-96 318ti)
Power Window Wiring Diagram (1994-96 Except 318ti - 1 Of 2). Scheme 10
Scheme 10: Power Window Wiring Diagram (1994-96 Except 318ti - 1 Of 2)
Power Window Wiring Diagram (1994-96 Except 318ti - 2 Of 2). Scheme 11
Scheme 11: Power Window Wiring Diagram (1994-96 Except 318ti - 2 Of 2)
