DESCRIPTION & OPERATION
Vehicles are equipped with power seats which adjust for cushion tilt angle, longitudinal adjustment, cushion adjustment, and back rest angle. An optional sports seat includes manual adjustment for thigh support.
Removal
Move seat as far forward as possible. Remove rear seat track bolts. Move seat as far back as possible. Deactivate belt lock tightener by turning screw until Green mark in sight glass changes to Red. (Scheme 1) Pry off caps covering front seat track bolts. Remove bolts. (Scheme 2) Disconnect electrical connectors. Lift seat out of vehicle.
Installation
To install, reverse removal procedure. Ensure belt lock tightener is activated by turning screw until Red mark changes to Green.
Scheme 1
Scheme 2
Removal & Installation
Move seat up as far as possible. Remove seat cushion. Cut plastic cable ties from wiring. Pull protective sleeve off electrical connector. Disconnect electrical connector. Tilt seat cushion upward and hold in position. Remove 3 screws from drive motor. (Scheme 3) Remove drive motor. To install, reverse removal procedure.
Note. Drive motor may be secured with 2 screws and one rivet. (Scheme 4) Drill out rivet and replace with bolt and nut.
