Air conditioning — Heat pump circuit BMW i3 I01
All systems — 30 systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance electric
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights
- Navigation 5
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlock
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer
Air conditioning
# Heat pump circuit
# Heat pump circuit (1 of 2)
Components on the diagram
# Heat pump circuit (2 of 2)
