Passive Safety Systems -- Overview: Overview BMW 7 series F01/F02

Passive Restraints 3 illustrations ~149 words

Model Overview

The passive safety system ACSM, the replacement system to the byteflight, is already used on the following models.

Model seriesModelUsed as ofVariant
E605 Series Saloon09/2005ACSM 1
E615 Series Touring09/2005ACSM 1
E636 Series Coup$eA09/2005ACSM 1
E646 Series Convertible09/2005ACSM 1
E85Z4 Roadster01/2006ACSM 1
E86Z4 Coup$eA05/2006ACSM 1
E881 Series Convertible04/2008ACSM 2
E70X5 SAV11/2006ACSM 2
E71X6 SAC04/2008ACSM 2
E933 Series Convertible03/2007ACSM 2
F017 Series Saloon11/2008ACSM 3
F027 Series Saloon long version11/2008ACSM 3

MODEL OVERVIEW REFERENCE CHART

Scheme 1

Scheme 1: F01/F02 Bus System Overview

Legend for F01/F02 Bus System Overview

IndexExplanation
ACSMCrash Safety Module (Advanced Crash Safety Module)
ALActive steering system
CASCar Access System
CICCar Information Computer
CIDCentral information display
CONController
DMEDigital Motor Electronics
DSCDynamic Stability Control
DVDDVD changer
EDC SHLElectronic damper control, rear left satellite
EDC SHRElectronic damper control, rear right satellite
EDC SVLElectronic damper control, front left satellite
EDC SVRElectronic damper control, front right satellite
EGSElectronic transmission control
EHCElectronic ride-height control
EKPSElectrical fuel pump control
EMA LIElectrically motorized reel, left, (seat belt)
EMA REElectrically motorized reel, right, (seat belt)
EMFElectromechanical parking brake
FDRear compartment display
FD2Rear display 2
FKARear compartment heating/air conditioning system
FLAHigh-beam assistant
FRMFootwell module
FZDRoof functions Center
GWSGear selector lever
HiFiHiFi amplifier
HKLLuggage compartment lid lift
HSRRear-axle drift angle control
HUDHead-up display
ICMIntegrated Chassis Management
IHKAIntegrated automatic heating/air conditioning
JBEJunction box electronics
KAFASCamera-based driver assistance systems
KOMBIInstrument cluster
NVENight Vision electronics
PDCPark Distance Control
TPMSTire Pressure Monitoring System
OBDDiagnosis socket
RSE-MidRear seat entertainment
SDARSSatellite tuner
SMBFPassenger's seat module
SMBFHRear passenger seat module
SMFADriver's seat module
SMFAHRear module on driver' seat side
SWWLane change warning
SZLSteering column switch cluster
TCUTelematics control unit
TOP-HIFITop-HiFi system
TRSVCControl unit for rear view camera and Side View (Top Rear Side View Camera)
ULF-SBX HighInterface box - high (USB/audio interface)
VDMVertical dynamics management (central control unit for electronic damper control)
VSWVideo switch
ZGMCentral gateway module

LEGENDS FOR F01/F02 BUS SYSTEM

Scheme 2

Scheme 2: ACSM3 System Circuit Diagram
IndexExplanation
1Central gateway module
2Up-Front sensor, left
3Instrument cluster
4Car Access System
5Crash safety module
6Up-Front sensor, right
7Door pressure sensor, left
8Front airbag, driver
9Coil spring for airbag
10Knee airbag, driver
11Passenger Airbag OFF light
12Knee airbag, passenger
13Front airbag, passenger
14Door pressure sensor, right
15Head airbag, left
16B-pillar sensor, left
17Adaptive belt force limiter, driver
18Belt contact, driver
19Seat belt pretensioner, driver
20Side airbag, driver's side
21Active head restraint, driver
22Central sensor with rollover detection
23Belt contact, passenger
24Seat belt pretensioner, front passenger
25OC3 mat
26Active head restraint, passenger
27Side airbag, passenger side
28Head airbag, right
29B-pillar sensor, right
30Adaptive belt force limiter, passenger
31Telematics Control Unit for emergency call
32Safety battery terminal

INDEX CHART

Electric motor driven reel in operation

When the driver or front passenger fastens their seat belt or there is a critical driving situation in terms of driving dynamics, the electric motor is activated and moves the drive shaft using the worm gear.

The worm gear turns the drive wheel with the coupling. The locking pawls move out and engage in the ring gear (C).

The ring gear, which is located on the belt shaft, drives the belt shaft (D). The seat belt is rolled up on the belt shaft and thereby shortened. This tensions the seat belt to the occupants.

Scheme 3

Scheme 3: Electric motor driven reel in operation
