System Component BMW 7 series F01/F02

Driver Information Systems -- Overview 1 illustration ~104 words

System Component

The head-up display is fitted above the steering column, immediately behind the instrument cluster. It is fastened to the bulkhead supporting structure by three hexagon-head bolts.

Scheme 51

Scheme 51: System Component
Scheme 51: System Component
IndexExplanation
1Carrier bracket
2Head-up display HUD
3Hexagon bolt

STEERING COLUMN LEGENDS

The head-up display comprises the following components

  1. Cover glass
  2. Mirrors
  3. 2 LED arrays
  4. TFT projection display
  5. PCB
  6. Housing

The following components are required in addition to the components listed above

  1. Windshield
  2. Light module and BEFAS
  3. Rain/light sensor
  4. Roof function Center and junction box
  5. HUD trim

The following controls are required to operate the HUD

  1. On/Off button on the BEFAS
  2. Light switch in the light switch cluster
  3. Instrument-lighting dimmer
  4. Controller
