11 23 010 Removing and installing/replacing vibration damper (M62)
Unscrew and remove splash guard.
Remove alternator drive belt, refer to 11 28 010 REPLACING ALTERNATOR DRIVE BELT (M62)
Remove drive belt for a/c compressor, refer to 11 28 050 REPLACING DRIVE BELT FOR A/C COMPRESSOR (M60/M62/M73)
Release screws and remove vibration damper.
Scheme 542
11 23 031 Removing and installing/replacing hub for vibration damper (M62)
Removing vibration damper, refer to 11 23 010 REMOVING AND INSTALLING/REPLACING VIBRATION DAMPER (M62)
Remove cooling air duct for alternator.
Scheme 543
Remove brake air duct, left and right.
Release retainer for pressure line from engine support.
Pay attention to dowel pin.
Secure special tool 11 2 450.
Note. Protect engine bracket from damage.
Insert wood between engine support and special tool 11 2 450.
Unscrew central bolt.
