Engine Electrical System - Special Tools: Other — Engine Electrical System - Special Tools — Gauges & Instrument Panels

Engine Electrical System - Special Tools: Other BMW 7 series E65/E66

Minimum set: Mechanical tools

Note	For fitting spark plug connectors to ignition lead
Series	E36, E38
Storage location	K 103
SI number	1 03 89 (037)
Order number	12 1 080
Repair kit Consisting of
1 = 12 1 081	Pliers
3 = 12 1 083	Matrix set
Note: Cable 4 mm2 / ignition cable
6 = 12 1 086	Mounting sleeve

REPAIR KIT - GENERAL SPECIFICATION

Identifying Repair Kit. Scheme 209

Scheme 209: Identifying Repair Kit

In conjunction with	12 1 200
Note	For releasing spark plugs as well as for tightening to torque limit
Engine	M40, M42, M43, M43TU, M44, M50, M52, M60, M62, M70, M73, N40, N42, N46, N73, S14, S38, S50B30, S50B32, W10, W11
Storage location	B13
Order number	12 1 170 Spark plug tool
Consisting of
1 = 12 1 171	Spark plug key WAF 16 mm
Note: S50, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, W10, W11, N40, N42, N73
In conjunction with: 12 1 172 (S50), 12 1 200 (M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, W10, W11, N73)
2 = 12 1 172	Torque limiter 23 Nm +/- 3 Nm
Note: S14, S38, S50
In conjunction with: 12 1 171 (S50), 12 1 160 (S14, S38)

SPARK PLUG TOOL - GENERAL SPECIFICATION

Identifying Spark Plug Tool. Scheme 210

Scheme 210: Identifying Spark Plug Tool

In conjunction with	12 1 171, 12 1 172
Note	For tightening spark plugs to torque limit
Engine	M40, M42, M43, M43TU, M44, M50, M52, M52TU, M54, M56, M60, M62, M70, M73, N40, N42, N46, N73, S50US
Storage location	B13
SI number	1 05 92(507)
Order number	12 1 200 Torque limiter 30 Nm

TORQUE LIMITER 30 NM - GENERAL SPECIFICATION

Identifying Torque Limiter 30 Nm. Scheme 211

Scheme 211: Identifying Torque Limiter 30 Nm

Identifying Adapter Set For 134-Pin Module Plug. Scheme 212

Scheme 212: Identifying Adapter Set For 134-Pin Module Plug

In conjunction with	61 1 459
Note	For diagnosis and troubleshooting on DME and transmission control - from model year 98
Engine	M54, M56, M62, M73, N40, N42, N46, N62, N73
Storage location	N 201, N 202, N 203, N 204
SI number	2 04 97(248)
Order number	12 1 300 Adapter set for 134-pin module plug
Consisting of
12 1 301	Adapter lead 9-pin
12 1 302	Measurement module 24-pin
12 1 303	Measurement module 40-pin
12 1 304	Measurement module 52-pin
Note: Supplied from 08/2004 in conjunction with 12 1 305 (zero-coded cover cap for new SGM control unit in E6x)

ADAPTER SET FOR 134-PIN MODULE PLUG - GENERAL SPECIFICATION

12 7 060 Anti-Static Mat (ESD)

Note	ESD (Electro Static Discharge) For protection against ESD during repairs to electronic components. (Replaces the sub-number 12 7 192 from EPROM tool kit 12 7 190)
Series	E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, R50, R52, R53, RR1
SI number	2 06 04 (128)
Order number	12 7 060
Anti-static mat (ESD)

ANTI-STATIC MAT (ESD) - GENERAL SPECIFICATION

Identifying Anti-Static Mat (ESD). Scheme 213

Scheme 213: Identifying Anti-Static Mat (ESD)

Note	For removing and installing pulley on alternator
Engine	M10, M21, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M57, M57TU, M60, M62, M67, M70, M73, N46, N62, N73, S14, S50B30, S50B32
Storage location	B21
SI number	1 12 93(701)
Order number	12 7 110
Socket wrench socket WAF 24

SOCKET WRENCH SOCKET WAF 24 - GENERAL SPECIFICATION

Identifying Socket Wrench Socket WAF 24. Scheme 214

Scheme 214: Identifying Socket Wrench Socket WAF 24

12 7 121 Counterholder wrench

In conjunction with	Socket
Note	Alternator N42 engine
Order number	12 7 121
Counterholder wrench

COUNTERHOLDER WRENCH - GENERAL SPECIFICATION

12 7 122 Socket

In conjunction with	Counterholder wrench
Note	Hazet 8808 lg 10
SI number	1 28 03 (051)
Order number	12 7 122
Socket

SOCKET - GENERAL SPECIFICATION

In conjunction with	12 1 171, 12 1 172, 12 1 200
Note	For removing and installing spark plugs
Series	E31, E38
Engine	M73
Storage location	C13
SI number	1 11 94(858)
Order number	12 7 130 3/8" extension piece (2)
Consisting of
1 = 12 7 131	Extension piece, long
2 = 12 7 132	Extension piece, short

3/8" EXTENSION PIECE - GENERAL SPECIFICATION

Identifying Extension Piece. Scheme 215

Scheme 215: Identifying Extension Piece

12 7 190 Eprom tools / ID marking

Storage location	J 101
Order number	12 7 190 Eprom tools / ID marking
Consisting of
1 = 12 7 191	Eprom extractor pliers
2 = 12 7 192	Antistatic mat
Note: incl. arm band

EPROM TOOLS / ID MARKING - GENERAL SPECIFICATION

12 7 200 Set of tools

Note	For opening & closing control unit box
Storage location	J 106
Order number	12 7 200 Set of tools
Consisting of
1 = 12 7 201	Pliers
Note: For bending open tab washers
2 = 12 7 202	Lever
Note: For bending tab washers
3 = 12 7 203	Pliers
Note: For closing tab washers
4 = 12 7 204	Torx socket T20
5 = 12 7 205	Torx socket T10
6 = 12 7 206	Fine pen
Note: Black, waterproof
8 = 12 7 208	Slotted screwdriver 2 mm
9 = 12 7 209	Straightening tool
Note: For Eprom connections

SET OF TOOLS - GENERAL SPECIFICATION

12 7 210 Control unit seal

Storage location	J 106
Order number	12 7 210
Control unit seal
Consisting of
1 = 12 7 211	Seal marks
2 = 12 7 212	Hole punch
Note: For seal mark dating

CONTROL UNIT SEAL - GENERAL SPECIFICATION
