Minimum set: Mechanical tools
| Note | For releasing and removing fresh air grille. For removing various trims. |
|---|---|
| Series | E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, R50, R52, R53, RR1 |
| Storage location | C33 |
| SI number | 1 15 99(483) |
| Order number | 64 1 020 |
| Release hook | |
RELEASE HOOK - GENERAL SPECIFICATION
Identifying Release Hook. Scheme 200
64 1 251 Spray lance, RHD vehicles
| In conjunction with | Guide 64 1 252 |
|---|---|
| Note | From spray apparatus set 64 1 250 (RHD vehicles) |
| SI number | 1 26 03 (044) |
| Order number | 64 1 251 |
| Spray lance, RHD vehicles | |
SPRAY LANCE, RHD VEHICLES - GENERAL SPECIFICATION
Identifying Spray Lance - RHD Vehicles. Scheme 201
64 1 252 Guide
| In conjunction with | Lance 64 1 251 |
|---|---|
| Note | Guide from spray apparatus set 64 1 250 |
| SI number | 1 26 03 (044) |
| Order number | 64 1 252 |
| Guide | |
GUIDE - GENERAL SPECIFICATION
Identifying Guide. Scheme 202
64 1 491 Spray lance (LHD vehicles)
| In conjunction with | Guide 64 1 492 |
|---|---|
| Order number | 64 1 491 |
| Spray lance (LHD vehicles) | |
SPRAY LANCE (LHD VEHICLES) - GENERAL SPECIFICATION
Identifying Spray Lance (LHD Vehicles). Scheme 203
64 1 492 Guide for spray lance (LHD vehicles)
| In conjunction with | Spray lance 64 1 491 for evaporator cleaning |
|---|---|
| Order number | 64 1 492 |
| Guide for spray lance (LHD vehicles) | |
GUIDE FOR SPRAY LANCE (LHD VEHICLES) - GENERAL SPECIFICATION
Identifying Guide For Spray Lance (LHD Vehicles). Scheme 204
64 5 000 Puller
| Note | For V-belt pulley on swash plate compressor in air conditioning system |
|---|---|
| Series | E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39 |
| Storage location | C27 |
| Order number | 64 5 000 |
| Puller | |
PULLER - GENERAL SPECIFICATION
Identifying Puller. Scheme 205
64 5 010 Puller
| Note | For pulley on vane cell compressor in air conditioning system |
|---|---|
| Series | E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39 |
| Storage location | C27 |
| SI number | 1 05 86(604) |
| Order number | 64 5 010 |
| Puller | |
PULLER - GENERAL SPECIFICATION
Identifying Puller. Scheme 206
64 5 020 Holder
| Note | For pulley on vane cell compressor and Seiko compressor |
|---|---|
| Series | E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39 |
| Storage location | A25, B25 |
| SI number | 1 05 86(604) |
| Order number | 64 5 020 |
| Holder | |
HOLDER - GENERAL SPECIFICATION
Identifying Holder. Scheme 207
64 5 030 Puller
| Note | For thrust washer in front housing cover of swash plate compressor |
|---|---|
| Series | E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39 |
| Storage location | A26 |
| Order number | 64 5 030 |
| Puller | |
PULLER - GENERAL SPECIFICATION
Identifying Puller. Scheme 208
64 5 100 Set of sealing adapters
| Note | For closing off line flanges of A/C components (evaporator, condenser, compressor) for leak testing. Set consists of (see Fig.): 1 = 64 5 102" 2 = 64 5 103" 3 = 64 5 105 (replaces 64 5 10)" 4 = 64 5 106 (from 01/2005)" 5 = 64 5 104 |
|---|---|
| Series | E32, E34, E36, E38, E39, E46, E53, E64, E83 |
| SI number | 1 17 98(359) |
| Order number | 64 5 100 |
| Set of sealing adapters | |
| Consisting of: 1 = 64 5 101 | Filler adapter |
| Note | Replaced by 64 5 105 (from 01/2005) |
| 2 = 64 5 102 | Sealing adapter |
| Note | For sealing off suction line |
| 3 = 64 5 103 | Sealing adapter |
| Note | For sealing off suction connection on compressor |
| 4 = 64 5 104 | Connecting hose |
| Note | For connecting pressure bottle to filler adapter |
| 5 = 64 5 105 | Filler adapter |
| Note | For sealing off pressure line and connection on connecting hose (has replaced special tool SWZ 64 5 101 since 01/2005) |
| 6 = 64 5 106 | Sealing adapter |
| Note | Sealing adapter for sealing off leak-testing line (from 01/2005 in scope of delivery) |
SET OF SEALING ADAPTERS - GENERAL SPECIFICATION
