24 0 120 Attachment for trolley

Note	For removing and installing transmission / Replaced by 24 0 130, March 87
Transmission	4 HP 22
Order number	24 0 120
Attachment for trolley

ATTACHMENT FOR TROLLEY - GENERAL SPECIFICATION

Identifying Take-Up Support For Transmission. Scheme 213

Scheme 213: Identifying Take-Up Support For Transmission

In conjunction with	00 2 030 (not included in minimum kit)
Note	For removal and installation
Transmission	4 HP 22, 4 HP 24
SI number	1 02 87(721)
Order number	24 0 130
Take-up support for transmission

TAKE-UP SUPPORT FOR TRANSMISSION - GENERAL SPECIFICATION

Identifying Pipe Manifold. Scheme 214

Scheme 214: Identifying Pipe Manifold

In conjunction with	13 3 061, 24 0 021, 24 0 022, 13 6 051, 13 6 052, 24 5 190
Note	For pressure gauge 13 3 061 and BMW DIS for measuring oil pressure in transmission
Transmission	A4S 270R, A4S 310R, A5S 310Z, A5S 560Z
Storage location	C3
SI number	1 01 92(469)
Order number	24 0 140
Pipe manifold

PIPE MANIFOLD - GENERAL SPECIFICATION

Identifying Mounting Bracket. Scheme 215

Scheme 215: Identifying Mounting Bracket

In conjunction with	00 1 450
Note	For mounting transmission on assembly stand
Transmission	3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, A4S 270R, A4S 310R, A5S 310Z
Order number	24 0 150
Mounting bracket
Consisting of
2 = 24 0 152	Base frame
3 = 24 0 153	Spindle with rotary handle
6 = 24 0 156	Spindle
Note: With thrust piece, transmission: all
In conjunction with: 00 1 450

MOUNTING BRACKET - GENERAL SPECIFICATION

Identifying Support. Scheme 216

Scheme 216: Identifying Support

In conjunction with	00 2 030 (not included in minimum kit)
Note	For removing and installing transmission
Transmission	A5S 560Z
SI number	1 06 92(509)
Order number	24 0 170
Support
Consisting of
24 0 171	Adjusting screw

SUPPORT - GENERAL SPECIFICATION

Identifying Support. Scheme 217

Scheme 217: Identifying Support

In conjunction with	00 1 450
Note	For mounting transmission on assembly stand
Transmission	A5S 310Z, A5S 325Z, A5S 360R, A5S 440Z, A5S 560Z, GA6 HP26Z
SI number	1 06 92 (509)
Order number	24 0 180
Support
Consisting of
1 = 24 0 181	Base frame
2 = 24 0 182	Pressure spindle with star handle
3 = 24 0 183	Spindle
Note: Replaced by 24 0 184
4 = 24 0 184	Spindle, long (2 x)

SUPPORT - GENERAL SPECIFICATION

Identifying Holding Fixture. Scheme 218

Scheme 218: Identifying Holding Fixture

Note	For output flange of propeller shaft while releasing and tightening slotted nut
Transmission	A5S 560Z
SI number	1 06 92(509)
Order number	24 0 190
Holding fixture

HOLDING FIXTURE - GENERAL SPECIFICATION

Identifying Take-Up Support For Transmission. Scheme 219

Scheme 219: Identifying Take-Up Support For Transmission

In conjunction with	24 5 301 and 00 2 030 (not included in minimum tool kit)
Note	For removal and installation
Transmission	A5S 440Z
SI number	1 08 96(080)
Order number	24 0 250
Take-up support for transmission

TAKE-UP SUPPORT FOR TRANSMISSION - GENERAL SPECIFICATION

Identifying Installation Sleeve. Scheme 220

Scheme 220: Identifying Installation Sleeve

Note	For removing disc pack (4th gear) as well as fitting needle bearing in oil pump housing (A5S 560Z)
Transmission	4 HP 22, 4 HP 24, A5S 560Z
Storage location	A18
Order number	24 1 010
Installation sleeve

INSTALLATION SLEEVE - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 221

Scheme 221: Identifying Impact Bush

Note	For fitting rotary shaft seal for torque converter in oil pump housing
Transmission	3 HP 20, 3 HP 22
Storage location	C29
Order number	24 1 050
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 222

Scheme 222: Identifying Impact Bush

Note	For fitting rotary shaft seal for torque converter in oil pump housing and on output flange
Transmission	3 HP 20, 3 HP 22, A5S 300J, BW 65
Storage location	B29, C29
Order number	24 1 060
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 223

Scheme 223: Identifying Impact Bush

Note	For fitting rotary shaft seal in oil pump housing
Transmission	A5S 325Z
Storage location	B36
SI number	1 03 98(303)
Order number	24 1 070
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Bush (Aluminum). Scheme 224

Scheme 224: Identifying Bush (Aluminum)

In conjunction with	00 5 010
Note	For fitting on input shaft while removing rotary shaft seal from oil pump housing
Transmission	A5S 325Z
Storage location	A36
SI number	1 03 98(303)
Order number	24 1 080
Bush (aluminum)

BUSH (ALUMINUM) - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 225

Scheme 225: Identifying Impact Bush

Note	For installing rotary shaft seal on output flange
Transmission	A5S 390G
SI number	1 08 98(333)
Order number	24 1 090
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 226

Scheme 226: Identifying Impact Bush

Note	For fitting rotary shaft seal for output flange in transmission extension
Transmission	3 HP 12, 3 HP 20, 3 HP 22
Order number	24 1 100
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Socket With Magnet. Scheme 227

Scheme 227: Identifying Socket With Magnet

Note	For loosening and tightening converter mounting
Transmission	3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 200R, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 390R, A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z
Storage location	B19
SI number	1 04 86 (566)
Order number	24 1 110
Socket with magnet

SOCKET WITH MAGNET - GENERAL SPECIFICATION

Identifying Gauge. Scheme 228

Scheme 228: Identifying Gauge

Note	For adjusting position switch in "P" position during assembly / Model year: As from 03/96
Transmission	A4S 270R
SI number	1 07 96(068)
Order number	24 1 120
Gauge

GAUGE - GENERAL SPECIFICATION

Identifying Pin Wrench. Scheme 229

Scheme 229: Identifying Pin Wrench

Note	For releasing and tightening slotted nut on output flange
Transmission	A5S 310Z
Storage location	A35
SI number	1 09 90(282)
Order number	24 1 170
Pin wrench

PIN WRENCH - GENERAL SPECIFICATION

Identifying Fixture. Scheme 230

Scheme 230: Identifying Fixture

In conjunction with	24 1 080 (A5S 325Z)
Note	For removing and installing oil pump
Transmission	A5S 310Z, A5S 560Z
Storage location	B18
SI number	1 09 90(282)
Order number	24 1 180
Fixture
Consisting of
1 = 24 1 181	Retaining tube
2 = 24 1 182	Thread spindle
3 = 24 1 183	Retaining ring, inner
Note: (not shown)

FIXTURE - GENERAL SPECIFICATION

Identifying Drift. Scheme 231

Scheme 231: Identifying Drift

In conjunction with	00 5 500
Note	For fitting rotary shaft seal in front section of transmission casing
Transmission	A5S 310Z
Storage location	B28
SI number	1 09 90(282)
Order number	24 1 190
Drift

DRIFT - GENERAL SPECIFICATION

Identifying Installation Sleeve. Scheme 232

Scheme 232: Identifying Installation Sleeve

Note	For preventing damage to rotary shaft seal while fitting on gearshift shaft
Transmission	A5S 310Z
Storage location	B18
SI number	1 09 90(282)
Order number	24 1 200
Installation sleeve

INSTALLATION SLEEVE - GENERAL SPECIFICATION

Identifying Retaining Plate For Disc Package. Scheme 233

Scheme 233: Identifying Retaining Plate For Disc Package

Note	Not required as from transmission No. 11 2 300
Transmission	A5S 310Z
Storage location	B22
SI number	1 09 90(282)
Order number	24 1 210
Retaining plate for disc package

RETAINING PLATE FOR DISC PACKAGE - GENERAL SPECIFICATION

Identifying Take-Up Support For Drive Flange. Scheme 234

Scheme 234: Identifying Take-Up Support For Drive Flange

In conjunction with	24 1 170 (A5S 310Z), 24 4 110 (A5S 440Z)
Note	When loosening slotted nut
Transmission	A5S 310Z, A5S 440Z
SI number	1 09 90(282)
Order number	24 1 220
Take-up support for drive flange

TAKE-UP SUPPORT FOR DRIVE FLANGE - GENERAL SPECIFICATION

Identifying Pressing Tool. Scheme 235

Scheme 235: Identifying Pressing Tool

Note	For removing and installing piston (cover) on brake Ct
Transmission	A5S 310Z
Storage location	B20
SI number	1 14 93(718)
Order number	24 1 230
Pressing tool

PRESSING TOOL - GENERAL SPECIFICATION

Identifying Measuring Device. Scheme 236

Scheme 236: Identifying Measuring Device

Note	For determining spacers on brake C
Transmission	A5S 310Z
Storage location	B20
SI number	1 14 93(718)
Order number	24 1 240
Measuring device

MEASURING DEVICE - GENERAL SPECIFICATION

Identifying Lifting Gear. Scheme 237

Scheme 237: Identifying Lifting Gear

Note	For removing and installing brake clutch unit D/G incl. sprag wheel
Transmission	A5S 310Z
Storage location	B11, C11
SI number	1 14 93(718)
Order number	24 1 250
Lifting gear

LIFTING GEAR - GENERAL SPECIFICATION

Identifying Removal And Mounting Fixture. Scheme 238

Scheme 238: Identifying Removal And Mounting Fixture

Note	For removing and installing cylinder D/E with planetary gear train
Transmission	A5S 560Z
Storage location	C1, C2
SI number	1 01 95(892)
Order number	24 1 260
Removal and mounting fixture
Consisting of
1 = 24 1 261	Handle
2 = 24 1 262	Spindle with knurled nut
3 = 24 1 263	Centering bush

REMOVAL AND MOUNTING FIXTURE - GENERAL SPECIFICATION

Identifying Removal And Mounting Fixture. Scheme 239

Scheme 239: Identifying Removal And Mounting Fixture

Note	For removing and installing clutch A/B/C
Transmission	A5S 560Z
Storage location	B14, B15, B3
SI number	1 01 95(892)
Order number	24 1 270
Removal and mounting fixture
Consisting of
1 = 24 1 271	Lifting tube with eye bolt
2 = 24 1 272	Lock pin

REMOVAL AND MOUNTING FIXTURE - GENERAL SPECIFICATION

Identifying Removal And Mounting Fixture. Scheme 240

Scheme 240: Identifying Removal And Mounting Fixture

Note	For removing and installing brake clutch F
Transmission	A5S 560Z
Storage location	C20
SI number	1 01 95(892)
Order number	24 1 280
Removal and mounting fixture
Consisting of
1 = 24 1 281	Handle with spindle
2 = 24 1 282	Knurled nut
3 = 24 1 283	Centering handle

REMOVAL AND MOUNTING FIXTURE - GENERAL SPECIFICATION

Identifying Wedges. Scheme 241

Scheme 241: Identifying Wedges

Note	For fixing disc pack C in position while securing retainer tabs
Transmission	A5S 560Z
Storage location	C17
SI number	1 01 95(892)
Order number	24 1 290
Wedges

WEDGES - GENERAL SPECIFICATION

Identifying Impact Tool. Scheme 242

Scheme 242: Identifying Impact Tool

Note	For securing retainer tabs on disc pack C
Transmission	A5S 560Z
Storage location	C17
SI number	1 01 95(892)
Order number	24 1 300
Impact tool

IMPACT TOOL - GENERAL SPECIFICATION

Identifying Releasing Tool. Scheme 243

Scheme 243: Identifying Releasing Tool

Note	For releasing retainer tabs on disc pack C
Transmission	A5S 560Z
Storage location	C2
SI number	1 01 95(892)
Order number	24 1 310
Releasing tool
Consisting of
1 = 24 1 311	Profile section (slide)
2 = 241 312	Basic body

RELEASING TOOL - GENERAL SPECIFICATION

Identifying Tool. Scheme 244

Scheme 244: Identifying Tool

Note	For compressing disc spring
Transmission	4 HP 22, 4 HP 24
Storage location	C32
Order number	24 2 020
Tool

TOOL - GENERAL SPECIFICATION

Identifying Tool. Scheme 245

Scheme 245: Identifying Tool

Note	For compressing disc spring
Transmission	3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location	C32
Order number	24 2 030
Tool

TOOL - GENERAL SPECIFICATION

Identifying Tool. Scheme 246

Scheme 246: Identifying Tool

Note	For compressing disc spring
Transmission	3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Storage location	C32
Order number	24 2 040
Tool

TOOL - GENERAL SPECIFICATION

24 2 050 Extractor grip

Note	For sealing plugs in transmission case lower section / Replaced by 24 0 050
Order number	24 2 050
Extractor grip

EXTRACTOR GRIP - GENERAL SPECIFICATION

Identifying Tensioning Tool. Scheme 247

Scheme 247: Identifying Tensioning Tool

Note	For removing and installing snap ring in front of centering plate of ZF transmissions
Transmission	3 HP 12, 3 HP 20, 3 HP 22
Order number	24 2 140
Tensioning tool

TENSIONING TOOL - GENERAL SPECIFICATION

Identifying Tool Kit For Removing And Installing Reverse Gear Piston. Scheme 248

Scheme 248: Identifying Tool Kit For Removing And Installing Reverse Gear Piston

Note	For disassembling and assembling transmission for "Sealing intermediate plate" job
Transmission	A4S 270R, A4S 310R
SI number	1 22 97(239)
Order number	24 2 310
Consisting of
Tool kit for removing and installing reverse gear piston
1 = 24 2 311	Pressure plate
Note: For removing and installing spring retainer
2 = 24 2 312	Spindle with pressure plate
Note: Spindle M14x1.5, nut M14, pressure plate and washer / For removing and installing spring retainer
3 = 24 2 313	Guide pin (2)
Note: For fixing gaskets and intermediate plates on intermediate housing
4 = 24 2 314	Slip bush
Note: For removing piston in cylinder of intermediate plate

TOOL KIT FOR REMOVING AND INSTALLING REVERSE GEAR PISTON - GENERAL SPECIFICATION

Identifying Box Spanner. Scheme 249

Scheme 249: Identifying Box Spanner

In conjunction with	24 2 330
Note	For 3/16" socket head cap screw with 1/4" socket for adjusting brake band
Transmission	A4S 270R, A4S 310R
SI number	1 24 97(257)
Order number	24 2 320
Box spanner

BOX SPANNER - GENERAL SPECIFICATION

Identifying Open-Ended Spanner. Scheme 250

Scheme 250: Identifying Open-Ended Spanner

In conjunction with	24 2 320
Note	For adjusting brake band
Transmission	A4S 270R, A4S 310R
SI number	1 24 97(257)
Order number	24 2 330
1/2" open-ended spanner

1/2" OPEN-ENDED SPANNER - GENERAL SPECIFICATION

Identifying Drift. Scheme 251

Scheme 251: Identifying Drift

Note	For fitting radial seal on torque converter
Transmission	GA6 HP26Z, GA6 HP32Z
Storage location	B46
SI number	1 14 01 (766)
Order number	24 2 360
Drift

DRIFT - GENERAL SPECIFICATION

Identifying Gauge. Scheme 252

Scheme 252: Identifying Gauge

Note	For adjusting restrictor piston when installing gearshift unit
Transmission	3 HP 12, 3 HP 20, 3 HP 22
Order number	24 3 040
Gauge

GAUGE - GENERAL SPECIFICATION

Identifying Gauge. Scheme 253

Scheme 253: Identifying Gauge

Note	For aligning hydraulic gearshift unit in transmission
Transmission	3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24
Order number	24 3 050
Gauge

GAUGE - GENERAL SPECIFICATION

Identifying Drive Bush. Scheme 254

Scheme 254: Identifying Drive Bush

Note	For checking smooth movement of oil pump
Transmission	3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A5S 560Z
Storage location	A20
Order number	24 3 140
Drive bush

DRIVE BUSH - GENERAL SPECIFICATION

Identifying Drive Bush. Scheme 255

Scheme 255: Identifying Drive Bush

Note	For checking smooth movement of oil pump
Transmission	3 HP 20, 3 HP 22
Storage location	A20
Order number	24 3 150
Drive bush

DRIVE BUSH - GENERAL SPECIFICATION

Identifying Assembly Grip (2). Scheme 256

Scheme 256: Identifying Assembly Grip (2)

Note	For removing and installing torque converter
Transmission	A4S 200R, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 390R, A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z
Storage location	C18
Order number	24 4 000
Assembly grip (2)

ASSEMBLY GRIP (2) - GENERAL SPECIFICATION

Identifying Fixture. Scheme 257

Scheme 257: Identifying Fixture

Note	For checking torque converter for leaks
Transmission	3 HP 20, 3 HP 22, 4 HP 22
Order number	24 4 070
Fixture

FIXTURE - GENERAL SPECIFICATION

Identifying Fixture. Scheme 258

Scheme 258: Identifying Fixture

Note	For firmly holding torque converter in position while removing and installing transmission
Transmission	4 HP 22, 4 HP 24
Storage location	Single
Order number	24 4 080
Fixture

FIXTURE - GENERAL SPECIFICATION

Identifying Drift. Scheme 259

Scheme 259: Identifying Drift

In conjunction with	00 5 500
Note	For fitting rotary shaft seal on output end
Transmission	A5S 440Z, A5S 560Z
Storage location	B28
SI number	1 06 92(509)
Order number	24 4 090
Drift

DRIFT - GENERAL SPECIFICATION

Identifying Drift. Scheme 260

Scheme 260: Identifying Drift

Note	For fitting rotary shaft seal on drive side (behind converter)
Transmission	A5S 440Z, A5S 560Z
Storage location	C29
SI number	1 06 92(509)
Order number	24 4 100
Drift

DRIFT - GENERAL SPECIFICATION

Identifying Spanner. Scheme 261

Scheme 261: Identifying Spanner

Note	For releasing and tightening slotted nut on output flange
Transmission	A5S 440Z, A5S 560Z
Storage location	A23
SI number	1 06 92(509)
Order number	24 4 110
Spanner

SPANNER - GENERAL SPECIFICATION

Identifying Fixture. Scheme 262

Scheme 262: Identifying Fixture

Note	For firmly holding torque converter in position while removing and installing transmission. Replaced by 24 4 130.
Order number	24 4 120
Fixture

FIXTURE - GENERAL SPECIFICATION

Identifying Locating Tool. Scheme 263

Scheme 263: Identifying Locating Tool

Note	For firmly holding torque converter in position while removing and installing transmission
Transmission	A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 440Z, A5S 560Z, GA6 HP26Z, GA6 HP32Z
Storage location	A33
SI number	1 05 97(181)
Order number	24 4 130
Locating tool
Consisting of
1 = 24 4 131	Base unit
2 = 24 4 132	Blade
Note: Transmission: A5S 440Z, GA6HP26Z (N62)
3 = 24 4 133	Blade
Note: Transmission: A4S 310R and A5S 390G
4 = 24 4 134	Blade
Note: Transmission: A5S 310Z, A5S 560Z, A5S 300J and A5S 325Z
5 = 24 4 135	Blade
Note: Transmission: A5S 560Z, GA6 HP26Z (M67), GA6 HP32Z (N73)
6 = 24 4 136	Counter plate
7 = 24 4 137	Blade
Note: Transmission: A5S 360R

LOCATING TOOL - GENERAL SPECIFICATION

Identifying Drift And Slip Bush. Scheme 264

Scheme 264: Identifying Drift And Slip Bush

Note	For driving in shaft seal on drive shaft.
Transmission	GACVT16Z
Order number	24 4 200
Drift and slip bush
Consisting of
1 = 24 4 201	Drift
2 = 24 4 202	Slip bush

DRIFT AND SLIP BUSH - GENERAL SPECIFICATION

Identifying Tool. Scheme 265

Scheme 265: Identifying Tool

Note	For centering converter bell housing with respect to oil pump during assembly
Transmission	A4S 270R, A4S 310R
Storage location	B2
SI number	1 04 95(906)
Order number	24 5 120
Tool
Consisting of
1 = 24 5 121	Centering bush
2 = 24 5 122	Centering pin (3)

TOOL - GENERAL SPECIFICATION

24 5 140 Centering pin

Note	For transfer plate and gasket to shift unit (2x)
Transmission	A4S 310R
Order number	24 5 140
Centering pin

CENTERING PIN - GENERAL SPECIFICATION

Identifying Centering Pin With Thread (2). Scheme 266

Scheme 266: Identifying Centering Pin With Thread (2)

Note	For centering gearshift unit in transmission during assembly
Transmission	A4S 270R, A4S 310R
Storage location	A2
SI number	1 03 90(184)
Order number	24 5 150
Centering pin with thread (2)

CENTERING PIN WITH THREAD (2) - GENERAL SPECIFICATION

Identifying Centering Pins. Scheme 267

Scheme 267: Identifying Centering Pins

Note	For centering main housing with respect to intermediate and converter housing (2)
Transmission	A4S 270R, A4S 310R
Storage location	A2, B2
SI number	1 03 93(663)
Order number	24 5 160
Centering pins

CENTERING PINS - GENERAL SPECIFICATION

Identifying Adapter. Scheme 268

Scheme 268: Identifying Adapter

In conjunction with	13 3 061, 13 3 067, 24 0 021, 24 0 023, 24 0 140
Note	For pressure gauge 133 061 for checking oil pressure in transmission
Transmission	A4S 270R, A4S 310R
Storage location	C20
SI number	1 03 90(184)
Order number	24 5 190
Adapter

ADAPTER - GENERAL SPECIFICATION

Identifying Impact Bush. Scheme 269

Scheme 269: Identifying Impact Bush

Note	For driving in radial seal of selector lever shaft / Replaced by 24 5 360
Transmission	A4S 270R, A4S 310R
SI number	1 03 90(184)
Order number	24 5 200
Impact bush

IMPACT BUSH - GENERAL SPECIFICATION

Identifying Holder. Scheme 270

Scheme 270: Identifying Holder

Note	For loosening and tightening gearshift cable
Transmission	4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 310Z
Storage location	B19
SI number	1 04 91(372)
Order number	24 5 210
Holder

HOLDER - GENERAL SPECIFICATION

Identifying Holder. Scheme 271

Scheme 271: Identifying Holder

Note	For loosening and tightening gearshift cable
Transmission	A5S 300J, A5S 310Z
Storage location	B19
SI number	1 04 91(372)
Order number	24 5 220
Holder

HOLDER - GENERAL SPECIFICATION

Identifying Assembly Ring. Scheme 272

Scheme 272: Identifying Assembly Ring

Note	For fitting rotary shaft seal on gearshift shaft
Transmission	4 HP 22, 4 HP 24, A5S 310Z
Storage location	B19
SI number	1 04 91(372)
Order number	24 5 230
Assembly ring

ASSEMBLY RING - GENERAL SPECIFICATION

Identifying Holder. Scheme 273

Scheme 273: Identifying Holder

Note	For releasing and tightening gearshift cable / transmission with position switch
Transmission	A5S 310Z, A5S 560Z
Storage location	B19
SI number	1 06 92(509)
Order number	24 5 240
Holder

HOLDER - GENERAL SPECIFICATION

Identifying Bush. Scheme 274

Scheme 274: Identifying Bush

In conjunction with	24 5 490
Note	For fitting rotary shaft seal on selector shaft
Transmission	A5S 310Z, A5S 560Z
Storage location	B19
SI number	1 02 95(896)
Order number	24 5 250
Bush

BUSH - GENERAL SPECIFICATION

Identifying Extractor Tool. Scheme 275

Scheme 275: Identifying Extractor Tool

Note	For removing rotary shaft seal of selector shaft / transmission with position switch
Transmission	A5S 310Z, A5S 440Z, A5S 560Z
Storage location	B19
SI number	1 02 95 (896)
Order number	24 5 260
Extractor tool
Consisting of
1 = 24 5 261	Insert
2 = 24 5 262	Bushing

EXTRACTOR TOOL - GENERAL SPECIFICATION

Identifying Bush. Scheme 276

Scheme 276: Identifying Bush

In conjunction with	24 5 490
Note	For fitting rotary shaft seal on selector shaft
Transmission	A5S 440Z
Storage location	B18
SI number	1 08 96(080)
Order number	24 5 270
Bush

BUSH - GENERAL SPECIFICATION

Identifying Take-Up Support For Automatic Transmission. Scheme 277

Scheme 277: Identifying Take-Up Support For Automatic Transmission

Note	Miscellaneous: Japan and South Africa only
Transmission	A5S 300J
Order number	24 5 350
Take-up support for automatic transmission

TAKE-UP SUPPORT FOR AUTOMATIC TRANSMISSION - GENERAL SPECIFICATION

Identifying Drift. Scheme 278

Scheme 278: Identifying Drift

In conjunction with	00 5 500
Note	For drive shaft seal.
Transmission	GACVT16Z
Order number	24 5 400
Drift

DRIFT - GENERAL SPECIFICATION

Identifying Slip Sleeve (5). Scheme 279

Scheme 279: Identifying Slip Sleeve (5)

Note	For preventing damage to rotary shaft seal while fitting on gearshift shaft
Transmission	A5S 310Z, A5S 440Z, A5S 560Z
SI number	1 02 95 (896)
Order number	24 5 490
Slip sleeve (5)

SLIP SLEEVE (5) - GENERAL SPECIFICATION

Identifying Test Cable, 8-Pin. Scheme 280

Scheme 280: Identifying Test Cable, 8-Pin

In conjunction with	Test box 88-pin 614410
Note	For automatic transmission (EH transmission)
Transmission	4 HP 22, 4 HP 24
Storage location	A 101
SI number	2 03 91(313)
Order number	24 6 000
Test cable, 8-pin

TEST CABLE, 8-PIN - GENERAL SPECIFICATION

Identifying Test Cable, 9-Pin. Scheme 281

Scheme 281: Identifying Test Cable, 9-Pin

In conjunction with	Test box 88-pin 614410
Note	For automatic transmission (EH transmission)
Transmission	A4S 270R, A4S 310R
Storage location	A 102
SI number	2 03 91(313)
Order number	24 6 010
Test cable, 9-pin

TEST CABLE, 9-PIN - GENERAL SPECIFICATION

Identifying Test Cable, 14-Pin. Scheme 282

Scheme 282: Identifying Test Cable, 14-Pin

In conjunction with	Test box 88-pin 614410
Note	For automatic transmission (EH transmission)
Transmission	A5S 310Z
Storage location	A 103
SI number	0 02 99 (399)
Order number	24 6 020
Test cable, 14-pin
Consisting of
24 6 029	Operating instructions

TEST CABLE, 14-PIN - GENERAL SPECIFICATION

Automatic Transmission - Special Tools - E38: Other BMW 7 series E38 facelift

24 0 120 Attachment for trolley

Identifying Take-Up Support For Transmission. Scheme 213

Identifying Pipe Manifold. Scheme 214

Identifying Mounting Bracket. Scheme 215

Identifying Support. Scheme 216

Identifying Support. Scheme 217

Identifying Holding Fixture. Scheme 218

Identifying Take-Up Support For Transmission. Scheme 219

Identifying Installation Sleeve. Scheme 220

Identifying Impact Bush. Scheme 221

Identifying Impact Bush. Scheme 222

Identifying Impact Bush. Scheme 223

Identifying Bush (Aluminum). Scheme 224

Identifying Impact Bush. Scheme 225

Identifying Impact Bush. Scheme 226

Identifying Socket With Magnet. Scheme 227

Identifying Gauge. Scheme 228

Identifying Pin Wrench. Scheme 229

Identifying Fixture. Scheme 230

Identifying Drift. Scheme 231

Identifying Installation Sleeve. Scheme 232

Identifying Retaining Plate For Disc Package. Scheme 233

Identifying Take-Up Support For Drive Flange. Scheme 234

Identifying Pressing Tool. Scheme 235

Identifying Measuring Device. Scheme 236

Identifying Lifting Gear. Scheme 237

Identifying Removal And Mounting Fixture. Scheme 238

Identifying Removal And Mounting Fixture. Scheme 239

Identifying Removal And Mounting Fixture. Scheme 240

Identifying Wedges. Scheme 241

Identifying Impact Tool. Scheme 242

Identifying Releasing Tool. Scheme 243

Identifying Tool. Scheme 244

Identifying Tool. Scheme 245

Identifying Tool. Scheme 246

24 2 050 Extractor grip

Identifying Tensioning Tool. Scheme 247

Identifying Tool Kit For Removing And Installing Reverse Gear Piston. Scheme 248

Identifying Box Spanner. Scheme 249

Identifying Open-Ended Spanner. Scheme 250

Identifying Drift. Scheme 251

Identifying Gauge. Scheme 252

Identifying Gauge. Scheme 253

Identifying Drive Bush. Scheme 254

Identifying Drive Bush. Scheme 255

Identifying Assembly Grip (2). Scheme 256

Identifying Fixture. Scheme 257

Identifying Fixture. Scheme 258

Identifying Drift. Scheme 259

Identifying Drift. Scheme 260

Identifying Spanner. Scheme 261

Identifying Fixture. Scheme 262

Identifying Locating Tool. Scheme 263

Identifying Drift And Slip Bush. Scheme 264

Identifying Tool. Scheme 265

24 5 140 Centering pin

Identifying Centering Pin With Thread (2). Scheme 266

Identifying Centering Pins. Scheme 267

Identifying Adapter. Scheme 268

Identifying Impact Bush. Scheme 269

Identifying Holder. Scheme 270

Identifying Holder. Scheme 271

Identifying Assembly Ring. Scheme 272

Identifying Holder. Scheme 273

Identifying Bush. Scheme 274

Identifying Extractor Tool. Scheme 275

Identifying Bush. Scheme 276

Identifying Take-Up Support For Automatic Transmission. Scheme 277

Identifying Drift. Scheme 278

Identifying Slip Sleeve (5). Scheme 279

Identifying Test Cable, 8-Pin. Scheme 280

Identifying Test Cable, 9-Pin. Scheme 281

Identifying Test Cable, 14-Pin. Scheme 282

More articles — Automatic Transmission - Special Tools - E38

Login / Signup

Enter the code

You have successfully logged in!
