SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Compressor Type | Nippondenso Or Seiko-Seiki | |
| System Oil Capacity | (1) 4.7-6.1 ozs. | |
| Refrigerant (R-134a) Capacity | 53.9-55.5 ozs. | |
| System Operating Pressures (2) | ||
| High Side | 164-215 psi (11.5-15.1 kg/cm 2 ) | |
| Low Side | 36-42 psi (2.5-3.0 kg/cm 2 ) | |
| (1) Use PAG Oil (Part No. 81-22-9-407-724). (2) Specification is with ambient temperature at 80°F (27°C) and relative humidity at 50-70 percent. | ||
| (1) | Use PAG Oil (Part No. 81-22-9-407-724). |
| (2) | Specification is with ambient temperature at 80°F (27°C) and relative humidity at 50-70 percent. |
SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| A/C Compressor Bolt | 16 (22) | |
| Steering Wheel Hub Nut | 58 (80) | |
| Three Way Switch | 18 (25) | |
| INCH Lbs. (N.m) | ||
| Driver-Side Air Bag Module (Torx Screws) | 70 (8) | |
| Filter Cover Screws | 8 (0.9) | |
| Heat Exchanger Studs | 27 (3) | |
| Heater Core Stud Nut | 27 (3) | |
| Heater-To-Body Screw | 40 (4.5) | |
| Pipe Connections | ||
| 5/8" | 15 (20) | |
| 3/4" | 29 (39) | |
| 7/8" | 31 (42) | |
| 11/16" | 35 (48) | |
| Temperature Sensor Screw | 4.4 (0.5) | |
