Electronic Controls: Overview BMW 7 series E38

Automatic Trans 15 illustrations ~409 words

ELECTRONIC CONTROL SYSTEM IDENTIFICATION

See ELECTRONIC CONTROL SYSTEM IDENTIFICATION table and (Scheme 70) - (Scheme 73).

TransmissionEGS System
4HP 22/4HP 24 (Early, Approximately 1987-1988)1.XX
4HP 22/4HP 24 (Later, Aproximately 1988-1994)1.XX

ELECTRONIC CONTROL SYSTEM IDENTIFICATION

Scheme 70

Scheme 70

Scheme 71

Scheme 71

Scheme 72

Scheme 72

Scheme 73

Scheme 73

FUNCTIONAL DESCRIPTION

The A300 control unit monitors engine speed (terminal No. 21), injection signal (terminal No. 11), throttle position (terminal No. 7), road speed (terminal No. 8), kick-down signal (terminal No. 2), gear selector position (terminals No. 30, 28, 29, and 18), and program switch signal (terminals No. 14, 15, and 4). The A300 control unit electronic processing circuit compares this information with the A300 control unit program data. The A300 control unit then selects the correct gear and clutch engagement rate by controlling the shift valve solenoids and the hydraulic pressure regulator. The A300 control unit retards engine time during shifts by grounding terminal 24 for one second when shifting gears. This provides for a smoother shift.

The A4 check control module displays TRANSMISSION if a problem with the control system occurs. If a fault is detected, the transmission emergency problem turns on. Voltage to the Y300 transmission (terminal 1) is turned OFF and the vehicle can be driven only in third and reverse gears. NEUTRAL and PARK retain their functions.

CIRCUIT OPERATION

The Electronic Transmission Control System (AEGS) contains 3 transmission modes to provide smooth refined shifts through the interaction of transmission and engine electronics. Transmission operates the selected gear and does not shift up or down automatically. The Electronic Transmission Control System (AEGS) has the following components

  1. Automatic Transmission Range Switch.
  2. Check Control Module.
  3. Electronic Transmission Control Unit (AEGS).
  4. Instrument Cluster.
  5. Kick-Down Prevent Relay.
  6. Motronic Control Unit.
  7. Program Switch.
  8. Idle Switch.
  9. Transmission.
  10. Transmission Kick-Down Switch.

By operating program switch, driver can select 3 transmission modes: ECONOMY, MANUAL, and SPORT. When E (ECONOMY) is selected, terminal No. 14 of the AEGS is momentarily grounded through the switch to terminal No. 6 of AEGS control unit. When S (SPORT) is selected, terminal No. 4 of control unit is momentarily grounded through the switch to terminal No. 6 of the control unit. Fourth gear is not selected and first, second, and third gears are kept engaged up to a higher engine speed. When ignition switch is turned off, then to run, control unit automatically selects E (ECONOMY).

CONNECTOR IDENTIFICATION

For connector identification (Scheme 74)- (Scheme 77).

Scheme 74

Scheme 74: CONNECTOR IDENTIFICATION

Scheme 75

Scheme 75

Scheme 76

Scheme 76

Scheme 77

Scheme 77

Scheme 78

Scheme 78: WIRING DIAGRAMS

Scheme 79

Scheme 79

Scheme 80

Scheme 80

Scheme 81

Scheme 81

Scheme 82

Scheme 82

Scheme 83

Scheme 83

Scheme 84

Scheme 84
