BMW 6 series F06/F13/F12 facelift (2015-2018) w/ seat switch cluster on driver's door Wiring diagram
This page shows the only wiring diagram for the component.w/ seat switch cluster on driver's door, which is found in the car BMW 6 series F06/F13/F12 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ seat switch cluster on driver's door (1 of 1)
3.0L TURBO
4.4L TURBO
ACTIVE CRUISE CONTROL (ACC)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CONVERTIBLE TOP MODULE
CONVERTIBLE, GRAN COUPE
DIGITAL MOTOR ELECTRONICS
DOUBLE CLUTCH TRANSMISSION
DRIVER'S DOOR SWITCH BLOCK
ELECTRONIC TRANSMISSION CONTROL
FUEL PUMP CONTROL (EKPS)
GEAR SELECTOR SWITCH
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HIGH VERSION
INTEGRATED CHASSIS MANAGEMENT
INTELLIGENT BATTERY SENSOR
LEFT FRONT FOOTWELL FLAP MOTOR
LOW VERSION
NCA WIRE
PARKING BRAKE CONTROL UNIT
PARKING MANEUVERING ASSISTANT
PNK WIRE
PNK/WHT WIRE
RADIATOR SHUTTER DRIVE UNIT
RED WIRE
RED/GRN WIRE
RIGHT EXTERIOR MIRROR
RIGHT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
SERVOTRONIC CONTROL UNIT
SIREN, TILT SENSOR
TRAILER MODULE
W/ LANE CHANGE W/O LANE CHANGE W/ TWIN-CLUTCH GEAR BOX
W/ SEAT SWITCH CLUSTER ON DRIVER'S DOOR
W/ SEAT SWITCH CLUSTER ON FRONT PASSENGER'S DOOR
W/O TWIN-CLUTCH GEAR BOX
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/BRN/YEL WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Computer data lines circuit (6 of 6) -> W/ SEAT SWITCH CLUSTER ON DRIVER'S DOOR
