BMW 6 series F06/F13/F12 facelift (2015-2018) tweeter speaker Wiring diagram
This page shows the only wiring diagram for the component.tweeter speaker, which is found in the car BMW 6 series F06/F13/F12 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tweeter speaker (1 of 1)
ACTUATOR DRIVE
BLK/BRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
COUPE, GRAN COUPE
EXTENDABLE DASHBOARD SPEAKER
GRAN COUPE COUPE, CONVERTIBLE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
LEFT FRONT LIGHTING MID-RANGE SPEAKER
LEFT FRONT LIGHTING TWEETER
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT WOOFER
LEFT REAR LIGHTING SPEAKER
LEFT REAR LIGHTING SPEAKER 2
LEFT REAR MID- RANGE SPEAKER 2
LEFT REAR MID-RANGE SPEAKER
LIGHTING
MID-RANGE SPEAKER
PREMIUM TOP HIFI AMPLIFIER
RIGHT FRONT LIGHTING MID RANGE SPEAKER
RIGHT FRONT LIGHTING TWEETER
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT WOOFER
RIGHT REAR LIGHTING SPEAKER
RIGHT REAR LIGHTING SPEAKER 2
RIGHT REAR MID- RANGE SPEAKER 2
RIGHT REAR MID-RANGE SPEAKER
TWEETER SPEAKER
VIO/BRN WIRE
VIO/RED WIRE
VIO/YEL WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Top hifi radio circuit, premium (3 of 3) -> TWEETER SPEAKER
