BMW 6 series F06/F13/F12 facelift (2015-2018) throttle vlv gnd 2 Wiring diagram
This page shows the only wiring diagram for the component.throttle vlv gnd 2, which is found in the car BMW 6 series F06/F13/F12 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram throttle vlv gnd 2 (1 of 1)
BLK/VIO WIRE
BLU WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
CAR ACCESS SYSTEM
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS 2
ELECTROMOTIVE THROTTLE ACTUATOR 2
FLEXRAY BUS SIG
FOOTWELL MODULE
GEAR SELECTOR SWITCH
GRN/RED WIRE
K-CAN BUS SIG
PNK WIRE
PT-CAN BUS SIG
RED WIRE
RED/BLU WIRE
SW SIG
THROTTLE VLV ACTIV 2
THROTTLE VLV GND 2
THROTTLE VLV SIG 2
THROTTLE VLV SPLY 2
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Cruise control circuit (2 of 2) -> THROTTLE VLV GND 2
