BMW 6 series F06/F13/F12 facelift (2015-2018) roof functions center Wiring diagram
This page shows the only wiring diagram for the component.roof functions center, which is found in the car BMW 6 series F06/F13/F12 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram roof functions center (1 of 1)
3.0L TURBO
4.4L TURBO
AUC SENSOR
AUTOMATIC TRANSMISSION
BOOT LID/ TAILGATE LOCK
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CAMERA-BASED DRIVER ASSISTANCE SYSTEMS
CENTER CONSOLE OPERATING UNIT
CENTRAL GATEWAY MODULE
CONVERTIBLE TOP CONTROL SWITCH
COUPE, GRAN COUPE
COUPE, GRAN COUPE W/ BASIC VARIANT
COUPE, GRAN COUPE W/ HIGH VARIANT
CRASH SAFETY MODULE
DIAGNOSIS PLUG
DIGITAL MOTOR ELECTRONICS
DRIVER'S SEAT BELT BUCKLE CONTACT
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
EXTERIOR BOOT LID BUTTON
FOOTWELL MODULE
HOTEL POSITION SWITCH
IGNITION COIL CYLINDER 1
INTEGRATED CHASSIS MANAGEMENT
LANE CHANGE WARNING
LEFT FRONT VANITY MIRROR SWITCH
LEFT INNER TAIL- LIGHT
LEFT LICENSE PLATE LIGHT
NCA WIRE
PARK DISTANCE CONTROL
PARKING BRAKE BUTTON
PARKING BRAKE CONTROL MODULE
PARKING MANEUVERING ASSISTANCE
PASSENGER'S SEAT BELT BUCKLE CONTACT
PASSENGER'S SEAT OCCUPANCY DETECTION
REAR COMPARTMENT AUTOMATIC CLIMATE CONTROL
REAR DRIVER'S SIDE SEAT HEATING SWITCH
REAR PASSENGER'S SIDE SEAT HEATING SWITCH
REMOTE CONTROL RECEIVER
REVERSE GEAR SWITCH
RIGHT FRONT VANITY MIRROR SWITCH
RIGHT INNER TAIL LIGHT
RIGHT LICENSE PLATE LAMP
ROOF FUNCTION CENTER
ROOF FUNCTIONS CENTER
SIREN W/ TILT ALARM SENSOR
TRANSFER BOX
W/ AUTOMATIC GEAR BOX
W/O AUTOMATIC GEAR BOX
W/O AUTOMATIC SOFT CLOSE SYSTEM W/ AUTOMATIC SOFT CLOSE SYSTEM
WASHER FLUID LEVEL SWITCH
Go to component -> Ground distribution circuit (4 of 6) -> ROOF FUNCTIONS CENTER
