BMW 6 series F06/F13/F12 facelift (2015-2018) rear axle king pin inclination control actuator shield Wiring diagram
This page shows the only wiring diagram for the component.rear axle king pin inclination control actuator shield, which is found in the car BMW 6 series F06/F13/F12 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear axle king pin inclination control actuator shield (1 of 1)
4.4L TURBO
ACTIVE CRUISE CONTROL
ACTIVE STEERING SERVO MOTOR SHIELD
AIR COOLER CHARGE COOLANT PUMP
AIR COOLER CHARGE COOLANT PUMP 2
AUXILIARY WATER PUMP
BATTERY
BLK WIRE
BONNET CONTACT SWITCH
BRN WIRE
BRN/BLK WIRE
CAPACITOR BOX
CENTER WASHER NOZZLE HEATER
HIGH HORN
IGNITION COIL CYLINDER 2
IGNITION COIL CYLINDER 3
IGNITION COIL CYLINDER 4
IGNITION COIL CYLINDER 5
IGNITION COIL CYLINDER 6
INDEPENDENT AUXILIARY HEATER
INDEPENDENT HEATING COOLANT CHANGE OVER VALVE
INTEGRATED SUPPLY MODULE
INTELLIGENT BATTERY SENSOR
LEFT FOG LIGHT
LEFT FRONT BREAK PAD WEAR SENSOR
LEFT FRONT DAMPER SATELLITE
LEFT FRONT DIRECTION INDICATOR REPEATER LIGHT
LEFT HEADLIGHT
LEFT INNER TAIL- LIGHT
LEFT TARGETED ILLUMINATION
LEFT WASHER NOZZLE HEATER
LOW HORN
NCA WIRE
OIL LEVEL SWITCH
RADIATOR SHUTTER DRIVE UNIT
REAR AXLE KING PIN INCLINATION CONTROL ACTUATOR SHIELD
RIGHT FOG LIGHT
RIGHT FRONT DAMPER SATELLITE
RIGHT HEADLIGHT
RIGHT INNER TAIL LIGHT
RIGHT STEERING WHEEL MULTI-FUNCTION SWITCH BLOCK
RIGHT TARGETED ILLUMINATION
RIGHT WASHER NOZZLE HEATER
STEERING COLUMN SWITCH CLUSTER
TRUNK LID ACTUATION W/ REVERSING CAMERA
WATER VALVES ASSEMBLY
WIPER MODULE
Go to component -> Ground distribution circuit (5 of 6) -> REAR AXLE KING PIN INCLINATION CONTROL ACTUATOR SHIELD
