BMW 6 series F06/F13/F12 facelift (2015-2018) radiator shutter solenoid Wiring diagrams
This page contains all the electrical diagrams for the component. radiator shutter solenoid, in which he is found in the car BMW 6 series F06/F13/F12 facelift (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
radiator shutter solenoid wiring diagram (1 of 2)
AIR COOLER CHARGE COOLANT PUMP
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CHARACTERISTIC MAP THERMOSTAT
CHARGE AIR COOLER COOLANT PUMP 2
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE
DIGITAL MOTOR ELECTRONICS 2
ELECTRIC FAN CUT OUT RELAY
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
ENGINE COOLANT TEMPERATURE SENSOR
FLEXRAY BUS SIG
FUSE 111
FUSE 137
FUSE 33
FUSE 35
FUSE 46
FUSE 505
FUSE 59
FUSE BOX
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ TERMINAL
INTERCOOLER COOLANT PUMP
JUNCTION BOX
NCA WIRE
POWER DISTRIBUTION SYSTEM
PT-CAN BUS SIG
RADIATOR OUTLET TEMPERATURE SENSOR
RADIATOR SHUTTER DRIVE UNIT
RADIATOR SHUTTER SOLENOID
REAR FUSE HOLDER
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RELAY ENERGIZED
TURBOCHARGER COOLANT PUMP
VIO WIRE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> RADIATOR SHUTTER SOLENOID
