BMW 6 series F06/F13/F12 facelift (2015-2018) prk bk bus sig Wiring diagram
This page shows the only wiring diagram for the component.prk bk bus sig, which is found in the car BMW 6 series F06/F13/F12 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram prk bk bus sig (1 of 1)
BLU/BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
COUPE, GRAN COUPE W/ BASIC VARIANT
COUPE, GRAN COUPE W/ HIGH VARIANT
DYNAMIC STABILITY CONTROL (DSC)
FUSE 167
FUSE 32
FUSE 60
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
JUNCTION BOX
LED IND
PARK BRK SIG
PARKING BRAKE BUTTON
PARKING BRAKE CONTROL MODULE
POWER DISTRIBUTION SYSTEM
PRK BK BUS SIG
PT-CAN BUS SIG
PWR SPLY
PWR SUPLY
RAIN/LIGHT/ SOLAR/CONDENSATION SENSOR
REAR FUSE HOLDER
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
ROOF FUNCTION CENTER
SPEED SIG
SW SIG
TERM 30
WHL SPD SIG
YEL/VIO WIRE
Go to component -> Headlights circuit (3 of 3) -> PRK BK BUS SIG
