BMW 6 series F06/F13/F12 facelift (2015-2018) pass seat backrest Wiring diagram
This page shows the only wiring diagram for the component.pass seat backrest, which is found in the car BMW 6 series F06/F13/F12 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass seat backrest (1 of 1)
BRN WIRE
BRN/RED WIRE
BUS SIG
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BACKREST HEATING ELEMENT
DRIVER'S SEAT CUSHION HEATING ELEMENT
DRIVER'S SEAT MODULE
ELECTRONICS JUNCTION BOX
FUSE 11
FUSE 52
FUSE 53
GRN WIRE
HEATING/AIR CONDITIONING SYSTEM
HOT W/ BI-STABLE RELAY ENERGIZED
JUNCTION BOX
NCA WIRE
ORG/GRN WIRE
PASS SEAT BACKREST
PASS SEAT CUSHION
PASSENGER'S SEAT BACKREST HEATING ELEMENT
PASSENGER'S SEAT CUSHION HEATING ELEMENT
PASSENGER'S SEAT MODULE
PWR SPLY
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
SEAT BACKREST)
SEAT CUSHION)
SIG TEMP SENS
VOLT SPLY
W/ 2 CIRCUIT SEAT HEATING SYSTEM
W/ LUMBAR SUPPORT
W/O LUMBAR SUPPORT
Go to component -> Front heated seats circuit -> PASS SEAT BACKREST
