BMW 6 series F06/F13/F12 facelift (2015-2018) left turn signal light Wiring diagram
This page shows the only wiring diagram for the component.left turn signal light, which is found in the car BMW 6 series F06/F13/F12 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left turn signal light (1 of 1)
ACTIVE BODYWORKS SYSTEM
AUTOMATIC TOWING HITCH
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE LIGHT
BRAKE LIGHT ACTIVATION
BRN WIRE
CAN BUS SIGNAL
COMPUTER DATA LINES SYSTEM
DIRECTION IND
FLASHING INDICATOR LAMP
FUSE 100
FUSE 145
FUSE 148
FUSE 19
GRN/GRY WIRE
GROUND
GRY/BLK WIRE
GRY/RED WIRE
GRY/YEL WIRE
HALL SENSOR SIGNAL
HOT W/
HOT W/ BI-STABLE RELAY ENERGIZED
JUNCTION BOX
LED ACTIVATION
LEFT TAILLIGHT
LEFT TURN SIGNAL LIGHT
LIGHT
NCA WIRE
REAR FOG LIGHT
REAR FUSE HOLDER
RED/BLK WIRE
RED/BRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY ENERGIZED
REVERSING LIGHT
RIGHT FRONT DIRECTION INDICATOR REPEATER LIGHT
RIGHT OUTER TAILLIGHT
RIGHT TAILLIGHT
RIGHT TURN SIGNAL LIGHT
SIDE MARKER
SWITCH SIGNAL
TAILLIGHT
TRAILER MODULE (IF EQUIPPED)
TRAILER SOCKET
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Exterior lamps & trailer connector circuit (3 of 3) -> LEFT TURN SIGNAL LIGHT
