BMW 6 series F06/F13/F12 facelift (2015-2018) driver seat belt tensioner generator Wiring diagram
This page shows the only wiring diagram for the component.driver seat belt tensioner generator, which is found in the car BMW 6 series F06/F13/F12 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat belt tensioner generator (1 of 1)
AIR BAG
AIR BAG SENS
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CENTER PEDESTRIAN SENSOR
COMPUTER DATA LINES SYSTEM
CONVERTIBLE COUPE, GRAN COUPE
CRASH SAFETY MODULE (UNDER RIGHT SIDE OF DASH)
DRIVER RETRACTOR TENSIONER
DRIVER SEAT BELT TENSIONER GENERATOR
DRIVER SIDE AIR BAG INFLATOR ASSEMBLY
FRONT PASSENGER RETRACTOR TENSIONER
GRN/RED WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/WHT WIRE
LEFT "B" PILLAR AIR BAG SENSOR
LEFT FRONT PEDESTRIAN GUARD ACTUATOR
LEFT FRONT SEAT BELT FORCE LIMITER GENERATOR
LEFT HEAD AIR BAG INFLATOR ASSEMBLY
LEFT ROLLOVER ALTERNATOR PROTECTION
NCA WIRE
PASSENGER SIDE AIR BAG INFLATOR ASSEMBLY
PDSTRN SENS +
PT-CAN BUS SIG
RIGHT "B" PILLAR AIR BAG SENSOR
RIGHT FRONT PASSENGER GUARD ACTUATOR
RIGHT FRONT SEAT BELT FORCE LIMITER GENERATOR
RIGHT HEAD AIR BAG INFLATOR ASSEMBLY
RIGHT REAR PEDESTRIAN GUARD ACTUATOR
RIGHT ROLLOVER ALTERNATOR PROTECTION
TENSIONER +
TENSIONER - TENSIONER +
TRIGGERING +
TRIGGERING + AIR BAG +
TRIGGERING - (PINS: 74 TO 77 NOT USED)
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/YEL WIRE
WK UP SIG TERM 15
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> DRIVER SEAT BELT TENSIONER GENERATOR
