BMW 6 series F06/F13/F12 facelift (2015-2018) boot lid automatic soft-close drive Wiring diagram

BLK WIRE BLK/BLU WIRE BLK/BLU/YEL WIRE BLU WIRE BLU/WHT WIRE BOOT LID AUTOMATIC SOFT-CLOSE DRIVE BOOT LID/TAILGATE LOCK BRN WIRE BRN/BLK WIRE BRN/GRN WIRE CAR ACCESS SYSTEM COMPUTER DATA LINES SYSTEM CONVERTIBLE EXCEPT CONVERTIBLE DRIVER'S SIDE REAR POWER WINDOW SWITCH ELECTRONICS JUNCTION BOX EXTERIOR BOOT LID BUTTON FUEL FILLER FLAP CENTRAL LOCKING DRIVE FUSE 14 FUSE 15 FUSE 152 FUSE 155 FUSE 38 GRAN COUPE GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/RED/YEL WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ HOTEL POSITION SWITCH INTERFERENCE SUPPRESSOR FILTER 2 INTERIOR REAR LID BUTTON JUNCTION BOX LEFT "C" PILLAR) NCA WIRE NOISE SUPPRESSOR FILTER (CONVERTIBLE) (RIGHT SIDE OF REAR COMPT) ORG/ WIRE REAR FUSE HOLDER REAR LID CENTRAL ARREST BUTTON RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED TRUNK LID ACTUATION W/ REVERSING CAMERA W/O REVERSING CAMERA WHT/RED/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE
