Wiring diagram: Navigation — Navigation circuit, basic BMW 6 series F06/F13/F12
All systems — 36 systems
- Active bodyworks 2
- Air conditioning 5
- Anti-lock brakes
- Anti-theft 4
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers 2
- Electronic power steering 3
- Electronic suspension 2
- Engine performance 3.0l turbo
- Engine performance 4.4l twin turbo
- Exterior lights 4
- Ground distribution
- Headlights
- Horn
- Instrument cluster 2
- Interior lights 4
- Memory systems 4
- Navigation 6
- Passive restraints
- Power distribution
- Power door locks 3
- Power mirrors 2
- Power seats 6
- Power top/sunroof 2
- Power windows 2
- Radio 6
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 3
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer
Navigation
# Navigation circuit, basic
# Navigation circuit, basic (1 of 2)
Components on the diagram
# Navigation circuit, basic (2 of 2)
Components on the diagram
Components on these wiring diagrams 29
Click a component to highlight it on every diagram it appears on.
