11 0 000 Engine Lifter For Removing And Installing Engines
Minimum set: Mechanical tools
Engine: M10, M47T2, M47TU, M52, M52TU, M54, M56, M60, M62, M67, M70, M73, N52, N62, N62TU, N73, S14, S54, S62, W10, W11
SI number: 1 13 94 (888)
Order number: 11 0 000
Engine lifter for removing and installing engines
Consisting of
1 = 11 0 001 Lifting beam
2 = 11 0 002 Chain, long
3 = 11 0 003 Chain, short
4 = 11 0 009 Shackle (2 x)
Scheme 407
11 0 020 Engine Hoist For Removing And Installing Engines
Minimum set: Mechanical tools
Engine: M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M47T2, M47TU, M50, M51, M52, M54, M57, M57D25, M57D30, M57T2, M57TU, N52, N62, N62TU, N73, S38, S50B30, S50B32, S50US, S85
SI number: 1 13 94 (888)
Order number: 11 0 020
Engine hoist for removing and installing engines
Consisting of
1 = 11 0 021 Lifting beam
2 = 11 0 022 Chain, medium
3 =11 0 023 Chain, long
4 = 11 0 024 Chain, short
5 = 11 0 029 Shackle (2 x)
Scheme 408
11 0 070 Engine Hoist
Note. For removing and installing engines
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M67TU, M70, M73, M88, N40, N42, N43, N45, N45T, N46, N46T, N52, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
SI number: 1 16 96 (107)
Order number: 11 0 070
Engine hoist
Consisting of
1 = 11 0 071 Lifting beam
2 = 11 0 072 Carrying chain, long
3 = 11 0 073 Carrying chain, short
4 = 11 0 079 Shackle (2 x)
Scheme 409
11 0 240 Coupling
In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225
Note: For adapting test probes to pressure gauge 11 0 162
Engine: All models
Order number: 11 0 240
Coupling
Scheme 410
11 0 270 Holder
Minimum set: Mechanical tools
Note. For holding central bolts during loosening and tightening operations
Engine: S62, S85
Storage location: A40
SI number: 1 23 98 (390)
Order number: 11 0 270
Holder
Scheme 411
11 0 280 Holder
Minimum set: Mechanical tools
Note. For holding central bolts during loosening and tightening operations
Engine: S54, S85
SI number: 1 15 00(609)
Order number: 11 0 280
Holder
Scheme 412
11 1 210 Extractor
Minimum set: Mechanical tools
In conjunction with: 11 2 383
Note. For rotary shaft seal in timing case cover
Engine: M47T2, M47TU, M57, M57D25, M57D30, M57T2, M57TU, M70, M73, S85
Storage location: B34, C27
SI number: 1 02 87(721)
Order number: 11 1 210
Extractor
Consisting of
1 = 11 1 211 Extractor
2 = 11 1 212 Thrust piece
Note. For insertion into crankshaft when removing shaft seal from gear case cover / Engine: M57
Scheme 413
11 2 000 Puller
Minimum set: Mechanical tools
Note: For crankshaft sprocket
Engine: M10, M30, M50, M52, M60, M62, M70, M73, N62TU, N73, S14, S38, W10, W11
Storage location: B9, C42
Order number: 11 2 000
Puller
Consisting of
1 = 11 2 001 Bell housing
2 = 11 2 002 Plate
Note: Engine: M10, M30, S14, S38, N73
3 = 11 2 003 Spindle
Note: Engine: M10, M30, M70, M73, S14, S38, N73
4 = 11 2 004 Plate
Note: Engine: M50, M52, M60, M62
5 = 11 2 005 Spindle 165 mm
Note: Engine: M50, M52, M60, M62
6 = 11 2 006 Plate
Note: Engine: M70, M73, N73
7 = 11 2 007 Thrust piece
Note: Engine: N73
Scheme 414
11 2 010 Extractor
Minimum set: Mechanical tools
Note. For removing guide bearing in crankshaft, stem diameter 12 mm
Engine: M10, M20, M21, M30, M40, M42, M50, M60, M62, S14, S38, S62, S85
Storage location: C25
Extractor
Consisting of
1 = 11 2 011 Extractor claw I
Note. With threaded bush - Engine: except M60, M62
2 = 11 2 012 Extractor claw II
Note. Engine: except M60, M62
3 = 11 2 013 Pressure spindle
Note. Engine: except M60, M62
4 = 11 2 014 Sleeve
Note. Engine: except M60, M62
5 = 11 2 015 Threaded bush
Note. Engine: except M60, M62
6 = 11 2 016 Pressure spindle
Note. Engine: M60/B30, M62, S62
Scheme 415
11 2 250 Torx Socket E12
Minimum set: Mechanical tools
Note. With 1/2" extension for releasing and tightening cylinder head bolts
Engine: M42, M43, M44, M50, M52, M60, M62, S85
Storage location: A22
SI number: 1 05 89(099)
Order number: 11 2 250
Torx socket E12
Scheme 416
11 2 340 Extractor
Minimum set: Mechanical tools
In conjunction with: 11 2 016 (M60, M62)
Note. For guide bearing in crankshaft, stem diameter 15 mm
Engine: M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57TU, M60, M62, M70, M73, N40, N42, N43, N45, N45T, N46, N46T, S50B30, S50B32, S54, S62, S85
Storage location: C11
SI number: 1 05 90 (207)
Order number: 11 2 340
Extractor
Consisting of
1 = 11 2 341 Extractor claw with threaded bush
2 = 11 2 342 Extractor claw
3 = 11 2 343 Pressure spindle
4 = 11 2 344 Sleeve
Scheme 417
11 2 350 Drift
Minimum set: Mechanical tools
Note. For fitting guide bearing of crankshaft
Engine: M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M57, M57TU, M60, M62, M70, M73, N40, N42, N43, N45, N45T, N46, N46T, S50B30, S50B32, S52US, S54, S62, S85
Storage location: A15
SI number: 1 05 90 (207)
Order number: 11 2 350
Drift
Scheme 418
11 2 380 Puller
Minimum set: Mechanical tools
Note. For removing rotary shaft seal from timing case cover
Engine: M41, M47, M50, M51, M52, M52TU, M54, M56, M60, M62, S50B30, S50B32, S54, S62, S65, S85, W10, W11
Storage location: A38, C25
SI number: 1 05 92 (507)
Order number: 11 2 380
Puller
Consisting of
1 = 11 2 381 Threaded bell housing
2 = 11 2 382 Spindle
3 = 11 2 383 Thrust piece
Note. Engine: M41, M47, M50, M51, M52, M60, M62, PENT
11 2 384 Thrust piece
Note. Engine: S50, S54
11 2 385 Spacer bushing
Note. Engine: M41, M50, M51, M52
11 2 386 Thrust piece
Note. Engine: S62, S65, S85
Scheme 419
11 3 460 Protractor
Minimum set: Mechanical tools
In conjunction with: 11 2 450
Note: For fitting on brace 11 2 450 when tightening central bolt using torsion angle tightening method
Engine: M60, M62, M73, N62, N62TU, N73
Storage location: C10
SI number: 1 08 92 (555)
Order number: 11 3 460
Protractor
Scheme 420
11 4 180 Screwdriver Socket Torx T60
Minimum set: Mechanical tools
Note. For releasing and tightening dual-mass flywheel - model year: from Jan 94
Engine: M57T2, M57TU, M60, M62, N43, N45T, N46T, N47, N52, N53, N54, S62, S85
Storage location: B8
SI number: 1 02 94 (777)
Order number: 11 4 180
Screwdriver socket Torx T60
Scheme 421
11 4 190 1/4" Extension Piece
Minimum set: Mechanical tools
In conjunction with: 11 3 390, 00 2 050
Note: M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit
Series: All models
Storage location: B6
SI number: 1 06 94(801)
Order number: 11 4 190
1/4" extension piece
Scheme 422
11 4 370 Pressing Fixture
Note. For pressing out sealing compound for bedplate.
Engine: N43, N45T, N51, N52, N53, N54, S85
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 4 370
Pressing fixture
Scheme 423
11 5 210 Protective Cover
Note. For injection nozzle bores on cylinder head.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 210
Protective cover
Scheme 424
11 5 220 Protective Covers
Note. For throttle valve intake assembly (10 x)
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 220
Protective covers
Scheme 425
11 5 240 Press-Down Device
Note. For pressing down camshafts during removal and installation.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 240
Press-down device
Consisting of
1 = 11 5 241 Basic body
2 = 11 5 242 Set of screws (2 x)
3 = 11 5 243 Set of adapters
Scheme 426
11 5 250 Guide Mandrels (2)
Note. For installing and removing connecting rods with pistons.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 250
Guide mandrels (2)
Scheme 427
11 5 260 Engine support plate
In conjunction with: 00 2 300
Note. For accommodating engine on assembly stand.
Engine: S65, S85
SI number: 1 02 05 (173)
Order number: 11 5 260
Engine support plate
Consisting of
1 = 11 5 261 Basic body
2 = 11 5 262 Set of screws (10 x)
Scheme 428
11 5 270 Drift
Note. For fitting valve stem seal.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 270
Drift
Scheme 429
11 5 280 Valve Spring Basket
In conjunction with: 11 9 000
Note. For removing and installing valves.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 280
Valve spring basket
Consisting of
1 = 11 5 281 Removal tool
2 = 11 5 282 Installation tool
3 = 11 5 283 Installation aid
Scheme 430
11 5 300 Gauge
Note. For locating camshaft in TDC position.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 300
Gauge
Consisting of
1 = 11 5 301 Gauge, cylinders 1-5
2 = 11 5 302 Gauge, cylinders 6-10
Scheme 431
11 5 310 Installer
Minimum set: Mechanical tools
Note. For installing rear shaft seal on crankshaft.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 310
Installer
Consisting of
1 = 11 5 311 Basic body
2 = 11 5 312 Thrust sleeve
3 = 11 5 313 Nut with bearing
4 = 11 5 314 Set of screws (3 x)
Scheme 432
11 5 320 Plug Mandrel
Minimum set: Mechanical tools
Note. For blocking crankshaft in TDC position.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 320
Plug mandrel
Scheme 433
11 5 350 Retaining Fixture
Note. For holding and pretensioning timing chains.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 350
Retaining fixture
Consisting of
1 = 11 5 351 Retaining fixture, cylinders 1-5
2 = 11 5 352 Retaining fixture, cylinders 6-10
Scheme 434
11 5 360 Adapter
Note. For VANOS oil pressure measurement.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 360
Adapter
Consisting of
1 = 11 5 361 Banjo bolt with ring connection
2 = 11 5 362 Set of screw plugs (2 x)
3 = 11 5 363 Set of cap nuts (2 x)
Scheme 435
11 5 370 Locating Tool
Note. For VANOS exhaust camshaft gear setting.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 370
Locating tool
Scheme 436
11 5 380 Gauge
Note. For VANOS basic setting.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 380
Gauge
Consisting of
1 = 11 5 381 Gauge, cylinders 1-5
2 = 11 5 382 Gauge, cylinders 6-10
Scheme 437
11 5 390 Protective Covers (10 X)
Note. For spark plug holes in cylinder heads.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 390
Protective covers (10 x)
Scheme 438
11 5 400 Torx Bit T20
Note. For screw connection of VANOS solenoid valves.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 400
Torx bit T20
Scheme 439
11 5 410 Gauge
Note. For VANOS removal.
Engine: S85
SI number: 1 02 05 (173)
Order number: 11 5 410
Gauge
Scheme 440
11 5 430 Piston Ring Pliers
Note. Diameter 93 mm N62TU B48 engine
Engine: N62TU
Storage location: A20, B20
Order number: 11 5 430
Piston ring pliers
Scheme 441
11 5 450 Mounting Sleeve
Note: For installing piston (dia. 87 mm) with connecting rod. Engine: M67TU" N62TU B40"
Engine: M67TU, N62TU
SI number: 1 14 05 (198)
Order number: 11 5 450
Mounting sleeve
Scheme 442
11 6 250 Lever Gauge (Puppitast)
Minimum set: Mechanical tools
Note. With small stand for measuring tooth backlash and axial clearance at balancing shafts, camshafts and crankshafts.
Engine: M43TU, M47T2, M57T2, M67TU, S85
SI number: 1 04 98(304)
Order number: 11 6 250
Lever gauge (Puppitast)
Consisting of
1 = 11 6 251 Lever gauge
Note. With 0.8 mm measuring range in each direction
2 = 11 6 252 Hydraulic small stand with magnetic foot
4 = 11 6 254 Support plate
Note. Engine: M47T2" M57T2" S85
Scheme 443
11 6 360 Extractor
Minimum set: Mechanical tools
In conjunction with: 11 2 383, 11 2 386
Note. For removing rotary shaft seal from timing case cover
Engine: M47, M47TU, S65, S85
Storage location: B11
SI number: 1 06 98 (306)
Order number: 11 6 360
Extractor
Consisting of
1 = 11 6 361 Threaded bell housing
2 = 11 6 362 Spindle M12 x 100
Scheme 444
11 7 030 Socket Wrench Socket WAF 22
Minimum set: Mechanical tools
In conjunction with: 11 9 150
Note: For loosening and tightening oxygen sensor
Engine: M40, M43, M43TU, M44, M52, M52TU, M54, M56, M62, N40, N42, N45, N46, N53, N54, N62, N62TU, N73, S54, S62, S85
Storage location: B15
SI number: 1 06 95 (963)
Order number: 11 7 030
Socket wrench socket WAF 22
Scheme 445
11 7 230 Slip Bush
Note. For installing shaft seal in crankcase - crankshaft at front
Engine: S62, S85
Order number: 11 7 230
Slip bush
Consisting of
1 = 11 7 231 Slip bush
Note. Diameter 49 mm
Scheme 446
11 9 000 Cylinder Head Expander Tool
Minimum set: Mechanical tools
In conjunction with: Assembly stand 00 1 450
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42 M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N12, N14, N40, N42, N45, N46, N51, N52, N53, N54, N62, N62TU, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Storage location: Single
SI number: 1 03 02 (833)
Order number: 11 9 000
Cylinder head expander tool
Consisting of
1 = 11 9 001 Fixture
2 = 11 9 002 Rod
3 = 11 9 003 Sliding block with M10 thread
4 = 11 9 004 Tab
5 = 11 9 005 Quick tensioner
6 = 11 9 006 Aluminium profile insert
7 = 11 9 007 Slide
8 = 11 9 008 Profile plastic part
9 = 11 9 009 Lever
10 = 11 9 011 Hook
11 = 11 9 012 Valve spring cage
Note: Engine M41, M51, S50
12 = 11 9 013 Valve spring cage
Note: Engine M43, M73
13 = 11 9 014 Valve spring cage
Note: Engine M44, M52, M54, M56, M62, S52, S54, S62
14 = 11 9 015 Valve spring cage
Note: Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73
15 = 11 9 016 Valve spring cage
Note: Engine M21, M40
16 = 11 8 421 Valve spring cage
Note: Engine: W10, W11, W17
17 = 11 9 017 Valve spring cage
Note: Engine N52
Scheme 447
11 9 150 Special Wrench
Minimum set: Mechanical tools
In conjunction with: 11 7 030
Note: For releasing and tightening down oxygen sensors
Engine: M54, M56, N12, N14, N42, N45, N46, N53, N54, N62, N62TU, N73, S54, S85
Storage location: A42
SI number: 01 15 00 (609)
Order number: 11 9 150
Special wrench
Scheme 448
11 9 190 Plug Mandrel
Minimum set: Mechanical tools
Note: For locking flywheel in TDC position
Engine: N40, N42, N62, N62TU, N73
Storage location: B43
SI number: 1 01 01(662)
Order number: 11 9 190
Plug mandrel
Scheme 449
11 9 260 Counter Support With Screw Connection
Minimum set: Mechanical tools
Note. For locking flywheel with transmission removed
Engine: M47TU, M54, M57T2, M57TU, N40, N42, N43, N45, N45T, N46, N46T, N51, N52, N53, N54, N62, N73, S85, W17
Storage location: B43
SI number: 1 01 01 (662)
Order number: 11 9 260
Counter support with screw connection
Consisting of
1 = 11 9 261 Counterholder, individual
2 = 11 9 262 Bolt (M10 thread) with washer
Note. For bolting down counterholder
3 = 11 9 263 Sleeve for counterholder
Note. For counterholder for locking flywheel with transmission removed engine: N62, N73
4 = 11 9 264 Bolt (M12 thread)
Note. For counterholder for locking flywheel with transmission removed
5 = 11 9 265 Sleeve
6 = 11 9 266 Sleeve
Note. For counterholder for locking flywheel with transmission removed Engine: M57TU2
Scheme 450
11 9 360 Drift
Minimum set: Mechanical tools
Note. For driving valve into engine block (sealing compound)
Engine: N40, N42, N43, N45, N45T, N46, N46T, N51, N52, N53, N54, S85
Storage location: A43
SI number: 1 01 01(662)
Order number: 11 9 360
Drift
Scheme 451
11 9 410 Puller
Minimum set: Mechanical tools
Note: For pulling radial seal out of engine block at front
Engine: N62, N62TU, N73
Storage location: A45
SI number: 1 14 01(766)
Order number: 11 9 410
Puller
Scheme 452
11 9 420 Installer
Minimum set: Mechanical tools
Note: For drawing in radial shaft seal in gearcase cover at bottom
Engine: N62, N62TU, N73
Storage location: C45
SI number: 1 14 01(766)
Order number: 11 9 420
Installer
Scheme 453
11 9 450 Counter Holder W/ Socket & Pointer
Minimum set: Mechanical tools
Note: For gripping crankshaft when releasing/tightening central bolt
Engine: N62, N62TU, N73
Storage location: A45, C42
SI number: 1 14 01 (766)
Order number: 11 9 450
Counter holder w/ socket & pointer
Consisting of
1 = 11 9 451 Lever
2 = 11 9 452 Disk
Note: Height 22.5 mm with hexagon screw
3 = 11 9 453 Pointer
4 = 11 9 454 Socket WAF 27
5 = 11 9 455 Disk
Note: Height 10 mm with hexagon screw
Scheme 454
11 9 460 Gauge
Minimum set: Mechanical tools
Note: For locating camshaft in TDC position
Engine: N62, N62TU, N73
Storage location: B45
SI number: 1 14 01 (766)
Order number: 11 9 460
Gauge
Consisting of
1 = 11 9 461 Gauge, inlet camshaft
2 = 11 9 462 Gauge, exhaust camshaft
3 = 11 9 463 Holder with screw
Scheme 455
11 9 470 Support
Minimum set: Mechanical tools
Note: For installing/removing bearing bracket (Camcarrier)
Engine: N62, N62TU, N73
SI number: 1 14 01(766)
Order number: 11 9 470
Support
Consisting of
1 = 11 9 471 Base plate
2 = 11 9 472 Shaped section
3 = 11 9 473 Knurled nut
4 = 11 9 474 Retaining screws (2 x)
5 = 11 9 475 Guide bushes (2 x)
6 = 11 9 476 Shaped section
Note: For securing inlet camshaft during installation in bearing bridge - Engine: N73
Scheme 456
11 9 480 Lever
Minimum set: Mechanical tools
Note: For pretensioning / relieving tension on torsion spring
Engine: N62, N62TU, N73
Storage location: B46
SI number: 1 14 01(766)
Order number: 11 9 480
Lever
Scheme 457
11 9 490 Holding Sleeve
Minimum set: Mechanical tools
Note: For protecting camshaft against damage by torsion spring (1 set = 20 pcs.)
Engine: N62, N62TU, N73
Storage location: C45
SI number: 1 14 01(766)
Order number: 11 9 490
Holding sleeve
Scheme 458
11 9 500 Pliers
Note. For mounting pistons in engine block - 92 mm dia.
Engine: M62, N62, N73, S85
Storage location: A46
SI number: 1 14 01(766)
Order number: 11 9 500
Pliers
Scheme 459
11 9 811 Holder
Order number: 11 9 811
Holder
Scheme 460
11 9 812 Screw
Order number: 11 9 812
Screw
