ENGINE COMPARTMENT
The integrated supply module (A6009) is located in right rear of engine compartment. (Scheme 1) The integrated supply module contains the following fuses
- F001: 30 Amp - Variable valve timing gear control module and fuel injectors 5-8.
- F002: 20 Amp - Fuel tank vent valve, bank 2 camshaft sensors and bank 2 VANOS solenoid valves.
- F003: 20 Amp - Ignition coils 1-4.
- F004: 20 Amp - Ignition coils 5-8.
- F005: 30 Amp - Crankshaft sensor, hot-film air mass meter, bank 1 camshaft sensors, characteristic map thermostat, and bank 1 VANOS solenoid valves.
- F006: 20 Amp - Fuel injectors 1-4.
- F007: 20 Amp - Sequential Manual Transmission (SMG).
- F008: 30 Amp - Oil quality sensor and oxygen sensors.
- F009: 10 Amp - Fuel pump relay, exhaust flap, radiator shutter solenoid switch, E-box fan, fuel tank leakage diagnostic module and secondary air pump relay.
- F010: 40 Amp - Relay 1 variable valve timing gear control module.
- F011: 40 Amp - Relay 2 variable valve timing gear control module.
Scheme 1
PASSENGER COMPARTMENT
For location of passenger compartment front fuse holder (A41a) (Scheme 2) For fuse identification, amperage and components covered (Scheme 3)
Scheme 2
Scheme 3
LUGGAGE COMPARTMENT
Rear fuse holder (A46) is located in luggage compartment. (Scheme 4) To access fuse holder (A46) (Scheme 2) For fuse identification, amperage and components covered (Scheme 5)
Scheme 4
Scheme 5
Rear fuse holder fuses F90-F92 protect the following
- F90: 200 Amp - Front fuse holder.
- F91: 100 Amp - Integrated supply module, valve timing.
- F92: 100 Amp - Electric auxiliary heater.
FUSE SYMBOL DEFINITIONS
For help determining the meaning of the symbols on fuse assignment legends, see FUSE ASSIGNMENT SYMBOL DEFINITIONS.
